  1. ROMANIAN RIS ACTIVITIES Second EU RIS Common Issues Meeting 2010 Budapest - Hungary, 17th of November, 2010 Teodor TANASESCU - AFDJ Galati, ROMANIA

  2. ROMANIAN RIS ACTIVITIES AGENDA • 1. RoRIS • 2. VTMIS on the Danube-Black Sea Canal • 3. ENC`s • 4. D4D • 5. Projects (NEWADA, IRIS Europe II) • 6. Common working Group • RO – RS; • RO – BG;

  3. ROMANIAN RIS ACTIVITIES 3 1. RoRIS • First phase of the project was finished and is operational (RoRIS I); • Second phase (RoRIS II), the system implement new services; • Interconnection with the similar system from Austria, Ungaria, Slovacia, Bulgaria and Serbia.

  4. ROMANIAN RIS ACTIVITIES 4 1.RoRIS • Component system • AIS Network; • Radar sensor; • Video sensor day/night; • Meteo station; • Network communication for voice VHF; • Software applications; • Interface with other systems / institutions;

  5. ROMANIAN RIS ACTIVITIES 5 1.RoRIS, Component system • AIS Network; • The system - on three levels: • Local base stations, or isolated points along the Danube; • Four regional centers in Drobeta Turnu Severin, Giurgiu, Galati, Tulcea; - A national center in Constanta;

  6. ROMANIAN RIS ACTIVITIES 6

  7. Actual Romanian AIS status Sulina Mahmudia Drobeta TurnuSeverin Giurgiu Constantza

  8. Future Romanian river AIS network Galati Sulina Mahmudia Orsova Moldova Noua Harsova Drobeta Drencova Cernavoda Calafat Calarasi Oltenita Giurgiu Constantza Bechet Corabia TurnuMagurele Zimnicea

  9. Future Romanian river AIS network Galati Tulcea Sulina Mahmudia Orsova Moldova Noua Harsova Drobeta Drencova Trikule Cernavoda Calafat Calarasi Gruia Oltenita Constantza Giurgiu Bechet Corabia TurnuMagurele Zimnicea

  10. Future Romanian AIS Danube – Black Sea Canal network Cernavoda Ovidiu Medgidia Constantza Basarabi Agigea Straja

  11. Future Romanian Full AIS network ( Inland & sea) Galati Tulcea Sulina Mahmudia Orsova Moldova Noua Harsova Drobeta Drencova Cernavoda Trikule Calafat Calarasi Oltenita Constantza Giurgiu Bechet Corabia TurnuMagurele Canal Zimnicea 11

  12. ROMANIAN RIS ACTIVITIES 12 1.RoRIS, Component system • Radar sensor; • 24h / 7 days, monitoring; • New locations: Moldova Veche, Orşova, Drobeta Turnu Severin, Giurgiu, Olteniţa, Călăraşi, Cernavodă, Brăila, Galaţi, Galaţi – Grindu, Galaţi – Vărsare Prut, Tulcea şi Sulina. • Video sensor day/night; • Day / night - distance from 30 - 4000m. • Locations : Moldova Veche, Orşova, Drobeta Turnu Severin, Calafat, Giurgiu, Călăraşi, Cernavodă, Brăila, Galaţi, Galaţi – Grindu, Galaţi – Vărsare Prut, Tulcea, Sulina.

  13. ROMANIAN RIS ACTIVITIES 13 1.RoRIS, Component system • Meteo station; • every location where there ECDIS console operator. • the sensors for measuring, Wind (direction and speed), Air temperature and Visibility. • Network communication for voice VHF; • Information services on the waterways on temporary obstruction of waterways; • Strategic information services; • Support services for disaster situations; • Management services locks and drawbridges; • Trip planning services; • Support Services for the imposition of laws and rules;

  14. ROMANIAN RIS ACTIVITIES 14 1.RoRIS, Component system • Software applications; • upgraded / replaced the following applications: • Application traffic management type ECDIS River Shipyard; • Electronic Reporting of trips (ELECTRONIC SHIP REPORTING); • Notice to skippers; • Service support for disaster mitigation (Calamity ABATEMENT) • Application monitoring ship dangerous goods (Dangerous Goods)

  15. ROMANIAN RIS ACTIVITIES 15 1.RoRIS, Component system • Software applications; • new applications: • Application registration / recording vessel • Application type database for identification of vessels (HULL DATABASE) • Application crew • Synthetic Information on inland water traffic • Interface with other systems / institutions; • Interface for data transfer by the Border Police • Interface VTMIS Danube-Black Sea Canal • Interface AFDJ • Interface for integration with other national centers RIS

  16. ROMANIAN RIS ACTIVITIES 2. Danube Black Sea Canal VTMIS – System structure 16

  17. ROMANIAN RIS ACTIVITIES 2. Danube Black Sea Canal VTMIS – Systemhighlights • AIS network with full coverage of the Danube Canal • VHF network • Data communication network with fiber optic and radio link backbones • Real-time monitoring and diagnostics subsystem 17

  18. ROMANIAN RIS ACTIVITIES 2. Danube Black Sea Canal VTMIS – RIS Services • Electronic Reporting • Notices to Skippers • Calamity abatement • ECDIS with up-to-date charts • Dangerous goods monitoring • Lock management • Automatic invoicing • Statistics 18

  19. Evolution of Romanian ENC`s in 2010 3. The romanian ENC`s In January to April 2010 was completed the whole romanian sector with sector between rkm 375 – rkm 297. In July to September 2010, ENC maps was completed for the sector between rkm 297 to Black Sea. In the same period the entire map was made for the Danube - Black Sea channal and for the entire secondary channel between Poarta Alba to Midia Navodari - Black Sea. Throughout the year 2010 was made monthly updates about the coastal signaling in sector between Chiciu, rkm 375 - Timok, rkm 845. 19

  20. Evolution of Romanian ENC`s in 2010 About ENC software and trainings In the second quarter, in June the entire software package from SevenCs Germany (ENC Designer, ENC Analyzer, ENC Optimizer, ENC Referencer, ENC Manager) was updated and was made training session in Romania. Now we have opportunity to update the ENC`s form version 1.02 to version 2.1 for entire Romanian sector of Danube. 20

  21. Romanian ENC`s Ortofoto image Geometry image ECDIS image 21

  22. ROMANIAN RIS ACTIVITIES 22 4. D4D (Data for Warehouse) • Contract with Geomapping; • Microstation V8i and Bentley Map, achieve and training; • Romanian subdomain: http://ro.d4d-portal.info • Accord with Serbia and Bulgaria, for maintain the database; • D4D Tools, already installed;

  23. ROMANIAN RIS ACTIVITIES 5. PROJECTS IRIS Europe II, started in April 2009, • Activity 1 – Pilot implementation of selected Fairway Information Services (FIS) • Actual depth data provision to fairway users • Provision of water level information based on water level models to fairway users • Enhanced Notices to Skippers • Wireless RIS Services for fairway users based upon wireless broadband technologies

  24. ROMANIAN RIS ACTIVITIES • Activity 2 - Pilot implementation Traffic and Transport related RIS Services • Standardisation; • Enhancement of pilot infrastructures (on shore) • Enhancement of pilot infrastructures (on board) • Romania: already installed 80 Inland AIS transponders (mobile)

  25. ROMANIAN RIS ACTIVITIES • Activity 3 – Pilot implementation Technical and Administrative Agreement) The participating member states of IRIS Europe agreed that a multilateral legal agreement among the member states is recommended as basis for the international data exchange.

  26. ROMANIAN RIS ACTIVITIES NEWADA Partner AFDJ, and Leader of the WP 4 (Ro) • Harmonisation of waterway infrastructure; • Update ENC Tools and training; • Achieve the FME Tools; • Implementation of D4D in Romania; • Preparing the National Strategy Plan for optimisation the waterway maintenance and for hydrology and hydrography;

  27. Evolution of IENC`s working groups 6. Bilateral workgroups Romanian- Bulgarian workging group • The IENC Bilateral Working Group is operational from 2006 was established two meeting per year and every time when is necessary. The results of this working group are to harmonized our objects from IENC cells (marking system, river bank vectors, fairway object, etc.). • Our last bilateral meeting from September 2010 was mainly aimed at harmonizing IENC cells for publication in the D4D application and FIS portal. 27

  28. Evolution of IENC`s working groups • Bilateral workgroup Romanian-Serbian working group In 2006th IENC Bilateral Working Group was established and is still operational. The results of this working group are harmonized Marking system, distant marks and the river bank vector and boundaries of the Fairway and regulating the exchange of information between AFDJ – Romania and PLOVPUT – Republic of Serbia. In June 2010 was the last bilateral working group meeting in Drobeta Turnu Severin, when we established the new directions about common IENC`s for D4D application and FIS portal. 28

  29. ROMANIAN RIS ACTIVITIES • Thank you for your attention . Teodor TANASESCU: tedi_tanasescu@yahoo.com
