  1. Tutorial 10 Heap&Priority Queue

  2. Heap – What is it? • Specialcomplete binary tree data structure • Complete BT: no empty node when checked top-down (level by level), left to right! • We actually implement this using compact array (or vector for size flexibility) • One to one mapping between complete binary tree and compact array! • We have a very efficient Heap manipulation using array/vector • Index start from 0 • Parent(i): floor((i-1)/2) • Left(i): 2i+1 • Right(i): 2i+2 • Special because it must satisfy recursive heap property for each node x: • The node x is larger than any of its left/right children (MaxHeap), or • The node x is smaller than any of its left/right children (MinHeap) • PS: Compare this with BST property! • Discussed in q2.

  3. Heap – Operations • Note: some other lecture notes/text books use different terms! • Two key operations: bubble up or bubble down • Fix heap property by bubbling a node upwards (exchange with parent) or downwards (exchange with one of the largest/smallest child). • Standard operations • Insertion: HeapInsert() a.k.a: fixHeap(), BubbleUp() • Insert to last, then bubble up  O(log n), see q1 • Deletion: HeapDelete() a.k.a: ExtractMax(), ExtractMin() • Take the root, replace with last, and then bubble down  O(log n) • For deleting non-root nodes, see q1 • No default searching operation: • We usually only access root (max/min) in O(1) • Accessing any other node will normally incur O(n) cost, but see q3 • Updating a node value requires bubble up or bubble down, see q3 • Special operation • ArrayHeap: Heapify() a.k.a: HeapConstruction()  O(n), not O(n log n), see q1

  4. Heap - Usage • Heap can be used as an efficient Priority Queue • Items are inserted as per normal O(log n) • But these items will come out (de-queued) based on their priority value!As we perform ExtractMax() or ExtractMin() from a max (or min) heap! O(log n) • Faster than using other data structure, e.g. sorted array • Heap can also be used for sorting (discussed in q3): • HeapSort() – O(n log n) • Or even for “partial sort” – O(k log n), e.g. Google default top 10 search results • The term “Barack Obama” on 6 Nov 08 produces 83 million hits • Sorting (80m log 80m) and display top 10 is “slow” • Create heap O(80m) + take top-10 in O(10 log 80m) is much faster • Heap can be built beforehand and stored in Google server, so it is just O(10 log 80m) • However, we can do better by mapping search query into an “answer page” in O(1)… • Only possible if we have large storage space. • Other sorting algorithms can do partial sort, but not natural • Quick sort can stop processing right part if pivot > k • Partitioning algorithm will ensure everything on the left side of pivot is the top k…

  5. Student Presentation • Gr3 (average: 2 times) • Rebecca Chen or Cao Hoangdang orDing Ying Shiaun or Du Xin • Nur Liyana Bte Roslieor Jashan Deep Kaur • Huang ChuanxianorLeow Wei Jieor Tan Kar Ann • Gr4 (average: 3 times) • Cynthia TanorTan Peck Luan • Liew Hui Sunor Hanyenkno Afi • Goh Khoon HiangorJasmine Choy Overview of the questions: • Trace Heap Operations (1 or 2 students) • IsHeap(Array) (1 student) • FindKthBest (1, 2, or 3 students) • Gr5 (average: 4 times) • Zheng Yang • Stephanie Teo • Tan Yan Hao • Gr6 (average: 3 times) • Koh Jye YiingorWang Shuling • SiddharthaorLaura Chua • RasheillaorBrenda Koh or Gary Kwongor Low Wei Chen

  6. Q1 – Trace Heap Operations • Insert 3, 1, 4, 1, 5, 9, 2, 6, 4 to empty max heap, delete 5, O(n log n) • Heapify array 3, 1, 4, 1, 5, 9, 2, 6, 4 to max heap, delete 6, O(n) • The resulting max heap (before deleting 5 and 6, respectively) are different but both are valid. However, Heapify() is faster as it is O(n). Link

  7. Q2 –IsHeap(Array)? class BinaryHeap { int currentSize; //maintain the number of elements in the heap Comparable[] array; //stores the heap elements BinaryHeap() { //constructor currentSize = 0; array = new Comparable[ DEFAULT_CAPACITY ]; } // with other standard heap methods ... } • Give code for checking if the heap is a valid max-heap:(is a complete tree and maintains heap property)

  8. Q2 –IsHeap(Array)? (Answer) bool isHeap() { for (int i = 0; i < currentSize; i++) { if (array[i] == NULL) // check if compact array == complete binary tree return false; // not a complete tree int child = 2 * i + 1; // check heap property if (child < currentSize) { if ((child+1) < currentSize) child = (array[child]>array[child+1])?child:(child+1); if (array[child] > array[i]) return false; } } return true; } Link

  9. Q3 – FindKthBest (1) • findKthBest(int k), which returns the athlete withthe kth least penalty points. What is the complexity? • Take/delete top k-1 items from min heap, so, after k-1 steps, you get the kth one as the root of the remaining min heap (the answer), this is (k-1) log n • Then, restore the deleted k-1 items into the heap again so that the next queries are correct, this is another (k-1) log n • Overall: (2k-2) log n which is O(k log n) • The complexity depends on k and n, ‘k’ cannot be dropped… • update(Athlete, points), which adds the new penalty pointsto Athletes record. What is the complexity? • Use hash table to map Athlete to index in Heap data structure! • Otherwise we need O(n) to scan for the correct index for this Athlete, now just O(1) • When we modify the value (points) in Heap, we need to bubble up/down to fix the heap property, which is maximum O(log n)… Update the corresponding values in Hash Table too, which is O(1) per update. • Overall complexity is O(1) + O(log n) * O(1) = O(log n)

  10. Q3 – FindKthBest (2) • Is there some other data structure which can be usedto give more optimized performance? (findKthBest + update) • If the data is static, we can put the scores in array, sort the arrayone time O(n log n) and return array[k-1] O(1) as the answer,faster than O(k log n) per query in Q3a. • However, the data will be frequently updated,thus, this method will be slow, as re-sorting the array takes O(n log n)! • Since data is going to be frequently updated and we want top k results, we can use an augmented BST instead of a heap to store the Athlete objects! • http://en.wikipedia.org/wiki/Augmenting_Data_Structures • Store the number of nodes in the left and right sub-tree in each node!Thus, we can know where to go (left or right or stay) to find index-k in O(log n)! • BST would take O(n lg n) time to create (one time task),but the query time for findKthBest will be O(log n), faster than O(k log n) • The time for update would remain unchanged, still O(log n),delete old value O(log n) and re-insert new value to BST O(log n).

  11. Homework: Trace Heap Sort • Perform partial sort to get top 3 results on this max heap (from q1)! • Continue all the way to complete the Heap Sort on this max heap! Link

  12. Class Photo  • I usually take class photo every semester • Please move to the center • We will take two photos: • One without me. • One with me (one student will do the photo taking) • After Thursday, you can see our photos here: • http://www.comp.nus.edu.sg/~stevenha/myteaching/myteachingrecord.html

  13. Advertisement • CS1102/C IEEE Revision Series • Conducted by: me… • Very relevant for this module! • Venue: LT 3 • Time: Friday,14 November 2008, 6-9pm • I will discuss past papers and share how to tackle CS1102/C exam! • Be there… you do not want to miss this!

  14. Questions from last semesters • Use them as additional learning materials…

  15. Heap Insert/Delete • Given the minheap h below, • Show what the minheap h would look like after each of the following pseudocode operations one after another: • h.heapInsert(8) • h.heapInsert(5) • h.heapDelete()

  16. Solution • h.heapInsert(8) • h.heapInsert(5) • h.heapDelete()

  17. Extension After these three operations • h.heapInsert(8) • h.heapInsert(5) • h.heapDelete() Continue with this: • h.heapInsert(14) • h.heapInsert(1) // assume this is 1a • h.heapDelete() • h.heapInsert(1) // duplicate, this is 1b • h.heapInsert(15)

  18. Extension – Solution Final heap:

  19. Heap Construction • Show the result of inserting: 12, 10, 1, 14, 6, 5, 8, 15, 3, 9, 7, 4, 11, 13, and 2 • One at a time! • Into an initially empty maxheap... • Then show/compare the result by using the heap construction algorithm instead!

  20. Solution • UsingIndividualInsertions • UsingHeap ConstructionAlgorithm
