  8. CRIS SERIESChip Resistor Inspection on Substrate Key benefits • Inspects wide range of packages • High throughput up to 2.5 secs / substrate • Mark inspection using stroke analysis • High accuracy measurement and comprehensive package dimensions selectable by user • Propreitary lighting design to enhance hard to see defects • Immediate quality assurance cost effectively and flexible configuration • Consolidated inspection report and comprehensive reporting format • Ease of use and fast learning curve

  9. Vision Inspection

  10. Vision Inspection One click to auto segment and learn the characters !! Good System detects broken 0 and extra ink on 5 !! Bad

  11. Vision Inspection Darker defect Lighter defect Darker defect

  12. Vision Capabilities

  13. Laser Cut

  14. Process Vision Inspection Pass ? Yes Inspect Print Registration Inspect Mark Quality Inspect Surface Defects Produce Report No Laser Cut Yes Any bad resistors ? Fail Bins Laser cut bad resistors No Pass Bin Cycle Time = 2.5 secs / substrate
