  1. VIBYNET Concept brief for the design of VIBYNET JARROD AVENANT – AVNJAR001 Aileen Seth – STHAIL001 DESMOND VAN WYK – VWYDES001 26 August 2005

  2. Based on the current demand of communication devices there is a need for a compact, light weight and portable communicating device that enables people to locate and communicate with each other without the need for cell phones or other devices that require service charges. (no more bills!!!) **within 2km radius Market Need: End Users: Vibynet caters for every user group with its various flavors (Professional Edition, Fun Edition) It is a multifunctional communications device that can be loaded with different software to meet the diverse needs of its users. • Industrial sites: Track workers and monitor progress by means of msgs. • Teens: Locate friends, Play network games, transfer data. • Corporate Environment: Locate employees, schedule emergency meetings via msgs. • Game Parks: Keep track of tourists in wild life parks!! A.S

  3. Compact, portable and light weight RF transceiver. • Internal antenna. • Short range precision tracking (Locate other Vibynet holders each with unique Vibynet identity codes) • Identify users by means of sound and picture alerts. • USB connection for transferring data (sounds, pictures and software) between pc and device and charging connection. • Message other Vibynet devices. • Play games (java apps) with other users within same area. • Transfer data between devices using low-power radio signals. The System: mmm.. Different flavors!! • Professional Edition. • Fun Edition. • Additional S/W components. A.S

  4. Plastic and protective rubber casing. • Li-on rechargeable battery. • High resolution LCD display (45mm x 70mm) External View: D.V.W

  5. USB Module High-level system model: Touch Screen/ LCD display Flash Memory RTOS RF Transceiver μProc RF Module Embedded Software User Interface Battery Vibration Unit Sound Unit Applications Battery Charging Unit J.A

  6. Portable device • Real-time location system • No continuous costs (one time purchase payment) • Easy to use • “Vibrant look” • Unique device • Fun Use: Play games, send messages. • Business Use: Save time and cut communication costs. Conclusions: A.S J.A D.V.W

  7. VIBYNET Cost effective communication Real-time location service Picture and sound identification alerts Customizable interface Free message and data transfer! A.S J.A D.V.W Get vibrant with VIBYNET!!!
