How To Connect Aquatrac Training ProMinent Fluid Controls
How to Connect • Applies to: • Multiflex Browser ProMinent Fluid Controls
How to Connect • Applies to: • Multiflex Browser • Trackster 3 ProMinent Fluid Controls
How to Connect • Applies to: • Multiflex Browser • Trackster 3 • Aegis Browser ProMinent Fluid Controls
How to Connect • Applies to: • Multiflex Browser • Trackster 3 • Aegis Browser • Microflex Browser ProMinent Fluid Controls
How to Connect • Applies to: • Multiflex Browser • Trackster 3 • Aegis Browser • Microflex Browser • Slimflex Browser ProMinent Fluid Controls
How to Connect • Ethernet Methods • Direct Connection: Direct from computer to controller • LAN Connection: Connect through site’s network • WAN Connection: Connect through the Internet ProMinent Fluid Controls
How to Connect • Direct Connection • Step 1 – Plug a Crossover Cable into your computer and the Controller Crossover Cable (CAT5) ProMinent Fluid Controls
How to Connect Multiflex Ethernet (RJ45) Jack Ethernet Crossover Cable ProMinent Fluid Controls
How to Connect Laptop Computer Ethernet Crossover Cable ProMinent Fluid Controls
How to Connect • Direct Connection • Step 1 – Plug a Crossover Cable into your computer and the Controller • Step 2 - Determine the IP Address of the Controller ProMinent Fluid Controls
System:2007-04-30 ↵ S/N: M00050005 Alarms: 14:42:03 ↓ F How to Connect • Multiflex example • Go to “System:” System:2007-04-30 ↵ S/N: M00050005 Alarms: 14:42:03 ↓ F ProMinent Fluid Controls
System:2007-04-30 ↵ S/N: M00050005 Alarms: 14:42:03 ↓ F How to Connect • Multiflex example • Go to “System:” • Scroll to “LAN Setup” System: Configure ↑ Time & Date LAN Setup ↵ ProMinent Fluid Controls
System:2007-04-30 ↵ S/N: M00050005 Alarms: 14:42:03 ↓ F How to Connect • Multiflex example • Go to “System:” • Scroll to “LAN Setup” • IP Address is shown System: LAN Setup.......... IP Address 10.10.6.106 ↵↓ ProMinent Fluid Controls
How to Connect • Direct Connection • Step 1 - Plug a Crossover Cable into your computer and the Controller • Step 2 - Determine the IP Address of the Controller • Step 3 – Configure your computer’s IP Address ProMinent Fluid Controls
How to Connect • Go to Start > Run ProMinent Fluid Controls
How to Connect For Windows NT, 2000, XP, & Vista • Go to Start > Run • In the “Run” window, type the appropriate Network Connections command, then click the OK button Note: The commands listed here are simply a “shortcut” way to go directly to the Network Connections window. The alternative method to these shortcuts is to navigate to the Control Panel and open the Network Connections applet. These commands come in handy when you need to open the Network Connections area, but the computer that you are using is different than what you are used to. For Windows 98 For Windows 98
How to Connect • Network Connections Window
How to Connect • Network Connections Window For Windows 98 Hint: The Status of the network connection changes to “Network cable unplugged” if you were to unplug the Crossover Cable from either the Controller or your computer’s network jack (RJ45). This is useful to know if you don’t know which item in the Network Connection list corresponds to the jack that you plugged the Crossover Cable into.
How to Connect • Network Connections Window
How to Connect • Connection Properties
System: LAN Setup.......... IP Address 10.10.6.106 ↵↓ How to Connect • TCP/IP Properties Match the first three numbers of your IP Address with the first three numbers of the controller’s IP Address
System: LAN Setup.......... IP Address 10.10.6.106 ↵↓ How to Connect • TCP/IP Properties • The fourth number of your IP Address must: • Not equal the fourth number of the Controller’s fourth number • Must be a number between 1 - 255
How to Connect • TCP/IP Properties • Set the Subnet mask to 255.255.255.0
How to Connect • Direct Connection • Step 1 - Plug a Crossover Cable into your computer and the Controller • Step 2 - Determine the IP Address of the Controller • Step 3 – Configure your computer’s IP Address Direct Connection Setup Complete ProMinent Fluid Controls
How to Connect • LAN Connection Site Network Straight Cable
How to Connect • LAN Connection • Step 1 – Plug a CAT5 Straight Cable into your computer and the wall jack Straight Cable ProMinent Fluid Controls
How to Connect Network Connection Settings • TCP/IP Properties
How to Connect • Step 1 – Plug your computer into the LAN using a Straight Cable • LAN Connection End User’s IT Dept may need to get involved ? Straight Cable
System:2007-04-30 ↵ S/N: M00050005 Alarms: 14:42:03 ↓ F How to Connect • LAN Connection • Determine the IP Address of the controller System: LAN Setup.......... IP Address 192.168.1.45 ↵↓ ProMinent Fluid Controls
How to Connect • LAN Connection LAN Connection Setup Complete Site Network
How to Connect • WAN Connection • Step 1 – Use a computer that is connected to the Internet
How to Connect • WAN Connection • Step 1 – User a computer that is connected to the Internet • Step 2 – Determine the IP Address of the Controller
How to Connect • WAN Connection • Step 1 – User a computer that is connected to the Internet • Step 2 – Determine the IP Address of the Controller WAN Connection Setup Complete
Getting Connected • How To Determine A Straight Cable • Viewing left-to-right: • Orange/White • Orange • Green/White • Blue • Blue/White • Green • Brown/White • Brown If the colored wires on each end of the CAT5 cable are NOT in the same order, you can assume that the CAT5 cable is a Crossover Cable
Getting Connected • Third Party Tools • USB-Ethernet Adapter A USB Ethernet Adapter is useful to avoid having to change your computer’s network settings (IP Address) every time you connect to a controller.
Questions? ProMinent Fluid Controls
