  1. Intelligent Shipping Container Project IMPACT & INTEL

  2. S Motivation & Requirements • Motivation • Homeland security requirements (ACSD, MATTs) • Dynamic supply chain • Requirements • RFID, environmental parameter sensing • Communication capability • Critical event reporting: intrusion detection • Lifetime requirements

  3. Intelligent Shipping Container System Architecture Container External Hosts MICAz mote Attached to nearby containers’ external Stargates. Proximity MICAz motes form an ad hoc (multi-hop) inter-container network. Stargate 2.4 GHz internal network MICAz mote 22.4 GHz $100 Access point of internal network and a node of inter-container network. 2.4 GHz GPS Receiver $100 Nearby PC/PDA E.g. computers at checkpoints or the datacenter, handheld devices held by custom officers and load/unload workers. Querying current and history data and downloading database from the internal database. RFID Reader $500 USB 51-pin Stargate $500 Managing Internal network (hardware, power and security); processing data and maintaining database; processing queries from external network; and routing outgoing packets to one of the two wireless interfaces. MICAz mote $100 Ethernet Sensors 802.11 MICAz mote $100 RS232 or Remote Server Computers at the datacenter. Collecting real-time data from containers, managing database and responding to critical event reported by containers. Cellular Network Sensors PCMCIA Compact Flash 802.11 card or GPRS Modem1 $100 Compact Flash Memory Card 2GB+$100 Database MICAz mote $100 • Note: • Constrained by ports provided by the Stargate, only one of the two wireless methods, 802.11 and GPRS, can be installed. • In this single-stargate setting, the mote attached to the Stargate has to be shared by the internal network and external mote network, a.k.a. inter-container network, which will increase contention and collision in both networks. Two antennae (inside and outside container) are required. To alleviate collision, an additional circuit, antenna selector, may help. But still, the mote cannot receive packets from the two network at the same time.

  4. Stargate Demo MicaZ mote & MTS310 sensor boards Query & command Sensed data Query results

  5. Intelligent Container Software Components and Data Flow External Hosts Stargate Internal Network • MICA2 mote (TinyOS) • Ad hoc networking management; • Neighbor discovery; • Routing protocols; • Security protocols. RFID Reader w/ MICAz mote Periodical RFID reading and reporting, event or command triggered RFID reading, and reliable transmission control. MICA2 mote driver Security component Inter-stargate forwarding if needed 802.11 card driver Socket server daemon processing requests (web) Database accessing (web based) Request manager Radio management dynamically determining outgoing wireless interface • PC/PDA (Win/CE/Linux) • Network establishing; • Query generation and display; • Database management; • Socket server daemon processing voluntary reports and alerts; • Security management. Sensor #1 w/ MICAz mote Periodical environmental data sensing and reporting, event or command triggered data sensing and reliable transmission control. GPRS modem driver External network abstract Database GPS receiver driver Data fusion, database management Internal network abstract Voluntary report and alert System configuration, hardware management (self-diagnoses, self-monitoring, watchdog monitoring), power management Serialforwarder (attached to UART) Sensor network management • Remote Server • Query generation and display; • Database management; • Socket server daemon processing voluntary reports and alerts; • Security management. Sensor #n w/ TelosB Periodical environmental data sensing and reporting, event or command triggered data sensing and reliable transmission control Socket server daemon processing sensing data Legend: command done as planed data partially done

  6. Research Topics • Energy efficient internal and external communication • Synchronization • Scalable container network • Dynamic group assignment
