  1. DEBUG EXAMPLE

  2. DEBUG Program DEBUG filename.exe

  3. Question 6 Q4) Write the following program in notepad and save it as P.asm ADD AX,AX MOV BX, 0FFFFH SUB X,BX ADD AX,W NEG AX INC AX ;DOC Exit MOV AH,4CH INT 21H MAIN ENDP END MAIN .MODEL SMALL .STACK 100H .DATA X DW -2 W EQU 7 .CODE MAIN PROC MOV AX,@DATA MOV DS,AX MOV AX,4000H ADD AX,AX MOV BX, 0FFFFH SUB X,BX

  4. Question 6 (continue ) After compiling and execute the program in DOS screen , use the DEBUG program and answer the following: C:\asm> DEBUG P.EXE • Display the register by write command : R • What is the content of AX register ? • What is the offset address of X? • Trace Instructions by typing : T • When you reach INT 21h, press: P after that complete tracing using T command. • Complete execution of the program by typing : G • Exit the DEBUG by typing : Q

  5. Display the register by write command : R

  6. What is the content of AX register ? • 0000 • @Data = 0B8D • The data segment address

  7. What is the offset address of X  ? •  000C Offset address of X Because W is EQU ,here its value instead of its offset address
