Analysis of Pressure and Temperature Variations at TDI During Fill 2219

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. TDI with large gaps V. Baglin (21/10/11) CERN TE-VSC, Geneva 1. 2. 3. 4.

  2. Pressure history • The pressure at TDI exhibit a pressure increase characteristic of heating • Since fill 2219 (16/10, PM), the TDI gap was increased in parking position from 22 mm to 55 mm • As a result, the pressure stays in the few 10-8 mbar range

  3. Fills 2218-19-20-21-22 • The pressure at TDI exhibit a pressure increase characteristic of heating • Since fill 2219 (16/10, PM), the TDI gap was increased in parking position from 22 mm to 55 mm • As a result, the pressure stays in the few 10-8 mbar range

  4. Fills 2218 to 2234 • The pressure at TDI exhibit a pressure increase characteristic of heating • Since fill 2219 (16/10, PM), the TDI gap was increased in parking position from 22 mm to 55 mm • As a result, the pressure stays in the few 10-8 mbar range or bellow for lower values of beam current

  5. TDI8R – Pressure and Temperature • The pressure at TDI exhibit a pressure increase characteristic of heating • Since fill 2219 (16/10, PM), the TDI gap was increased in parking position from 22 mm to 55 mm • As a result, the pressure stays in the few 10-8 mbar range but the temperature increase remains 2219

  6. TDI8R – Pressure and Temperature • The pressure at TDI exhibit a pressure increase characteristic of heating • Since fill 2219 (16/10, PM), the TDI gap was increased in parking position from 22 mm to 55 mm • As a result, the pressure stays in the few 10-8 mbar range but the temperature increase remains 2222 2219

  7. TS4-2011 • During the TS 4, wk 35, the TDI.8R and TCTVB.8R were equipped with thermocouples • TC1 and TC2 are located on TCTVB.8R • TC 4 and TC11 are located are located on TDI.8R transitions • TC5,6,9 and 10 are located on TDI.8R extremity • TC 7,8 are located at the centre of TDI.8R • TC3 and TC12 are located at reference vacuum chambers NEG coated. • Pressure is measured at TDI by VGPB.231.4R8.X
