Design and Fabrication of Power Generation Using Alternate Sources at SCAD Engineering College

This project focuses on generating power using alternate sources, specifically through a mechanical system involving gears. By placing a shaft at the center of a gate and connecting spur and compound gears to the shaft, we harness mechanical energy caused by the rotation of the gates. This rotational force drives a dynamo, producing electric current that can be stored in a battery. Our goal is to effectively utilize previously wasted mechanical work to generate electricity. Materials used include copper, cast iron, and steel components, showcasing innovative engineering.

loring
Télécharger la présentation

Design and Fabrication of Power Generation Using Alternate Sources at SCAD Engineering College

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. WELCOME

  2. SCAD ENGINEERING COLLEGE CHERANMAHADEVI

  3. TOPIC DESIGN AND FABRICATION OF POWER GENERATION BY USING ALTERNATE SOURCE.

  4. PRESENTED BY M.BALASUBRAMANIAN (952911114013) J.BASKAR (952911114014) G.VEL MARIAPPAN (952911114309) T.B.GODSON SMILE (952911114018)

  5. ABSTRACT:- • To produce power by using alternate source • The alternate source we used here is gear

  6. INTRODUCTION: We are placing a shaft on the centre of the gate. • Gears are kept on the bottom of the shaft. • When the shaft rotates gear will also rotates. • The dynamo which is in contact with the gear will produce electric current .

  7. MATERIALS USED: • COPPER • BEARINGS • CAST IRON • CIRCULAR STEEL PLATE • HOLLOW PIPE • SPUR AND COMPOUND GEAR

  8. PURPOSE:- Since the mechanical work is wasted, we are using it to produce electricity

  9. CONSTRUCTION:- • Four gates are attached to the centre of the shaft • Spur gear and compound gear are attached to the bottom of the shaft • Dynamo is attached to the gear

  10. EXPLANATION:- • When the gate rotates, the shaft will also rotates • Gear which is attached to the bottom of the shaft will also rotates , inturn dynamo also rotates, by the way current is produced • current is stored in battery.

  11. ADVANTAGES:- • Mechanical work is used • Power is produced
