This high-speed PCI video capture card supports up to 16 channels of video input, compatible with NTSC and PAL formats. Ideal for Windows 98, 2000, and XP systems, it enables seamless video streaming and recording thanks to its YUV422 digital video format. Features include both front and rear camera connections, automatic monitor output selection, and video brightness control. Easily connect multiple cameras and achieve high performance in video applications. Suitable for a range of surveillance and multimedia tasks.

1 / 9

Télécharger la présentation

Implementation

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Implementation

  2. 1) SPECIFICATION • 120 FRAME/SEWC OUTPUT • HIGH SPEED PCI 2.1 INTERFACE • MAX 16CH VIDEO INPUT • WINDOWS98 2000 XP • NTSC/PAL VIDEO FORMAT • YUV422 FORMAT DIGITAL VIDEO

  3. 1~16CH VIDEO INPUT PORT VIDEO BRIGHT CONTROL 2) FEATURE EXT. MONITOR OUTPUT (RCA) 1CH AUTOSELECT 1~4CH VIDEO INPUT PORT (BNC) Run , Power LED JUMPER Reset JUMPER

  4. 3) CONNECTION(4CH OVER) 1’ST CAM ----------- 16’TH CAM FRONT Video, REAR GND THIS MARK IS VIDEO

  5. 3) CONNECTION(4CH OVER) FRONT Video, REAR GND 1’ST CAM ----------- 16’TH CAM THIS MARK IS VIDEO

  6. 4) CONNECTION(8CH OVER) + Secondary Card Primary Card

  7. 4) CONNECTION(8CH OVER) Primary Card Secondary Card 8CH 1’ST CAM 4’ST CAM 5’ST CAM 8’ST CAM Secondary Primary ※ Primary card should be installed on the slot near CPU however, it is subject to charge in some mainboards CPU

  8. 4) CONNECTION(8CH OVER) Primary Card Secondary Card 1’ST CAM 4’ST CAM 5’ST CAM 8’ST CAM 16CH Secondary Card Primary Card 9’ST CAM 12’ST CAM 13’ST CAM 16’ST CAM

  9. POWER LED LEFT PIN + RESET + - (NO SEQ) RUN LED LEFT +
