  1. Update on ISO 17078 Standards Wayne Mabry Coordinator - Gas Lift Manufacturing Leader of ISO Task Group 17078

  2. Objectives • Review situation of ISO 17078.1 • Side Pocket Mandrels Specification • Review situation of ISO 17078.2 • Flow control devices • Review situation of ISO 17078.3 • Latches and KOT Specification • Time Line

  3. ISO 17078-1 ISO/WD 17078‑1 Petroleum and Natural Gas Industries  Down hole equipment  Part 1: Side Pocket Mandrels Violators may be prosecuted.

  4. Environmental service grades Characteristics Grade El -- Standard service Non-sour service Grade E2 -- Stress corrosion cracking service H2S (sour) service1 Grade E3 -- CO2 service CO2 service2 Grade E4 -- Special service Special service requirements defined by the user/purchaser Environmental Service Grade Environmental service grades Table A-1 ____________________ 1Per NACE MR-01-75 2There are no published international standards for CO2 service. Each individual situation shall be evaluated on a case-by-case basis.

  5. Design Verification Grade Table B-1 D1 D2 D3 Documentation Hist. Record Required Required See B.1 -- 1 See B.2 -- 1 See B.3 – 1 Design review (burst, Required Required Required collapse, tolerance) See B.1 -- 2 See B.2 -- 2 See B.3 – 2 Burst & collapse pressure Not required Burst & collapse Not required test to destruction @ See B.1 -- 3 See B.2 -- 3 See B.3 – 3 ambient temperature Pressure testing @ rated Required Required Required temperature See B.1 -- 4 See B.2 -- 4 See B.3 – 4 Internal pressure cycles Not required 10 cycles 10 cycles See B.1 -- 5 See B.2 -- 5 See B.3 – 5 Finite element analysis / Not required Not required Burst & collapse strain gauge See B.1 – 6 See B.2 -- 6 See B.3 – 6 Flow control – install/pull @ 12 o'clock @ 12,3,6 o'clock @ 12,3,6 o'clock with kick-over tool See B.1 -- 7 See B.2 -- 7 See B.3 – 7 Slick line operational test Not required Not required Required with kick-over tool See B.1 -- 8 See B.2 -- 8 See B.4 - 8

  6. Product Validation Grade Table C-1 V1 V2 V3 Internal pressure test 100% 100% 100% See C.1 -- 1 See C.2 -- 1 See C.3 -- 1 External pressure test 0% 5% 100% See C.1 -- 2 See C.2 -- 2 See C.2 -- 2 Internal diameter drift test 100% 100% 100% See C.1 -- 3 See C.2 -- 3 See C.2 -- 3 External diameter drift test 100% 100% 100% See C.1 -- 4 See C.2 -- 4 See C.2 -- 4 Installation/removal method – 0% 5% 100% kick-over tool See C.1 -- 5 See C.2 -- 5 See C.2 -- 5

  7. Quality Control Grade Table D-1 Q1 Q2 Q3 Hardness testing 100% 100% 100% See D.1 -- 1 See D.2 -- 1 See D.3 -- 1 Non-destructive examination Not required 5% 100% See D.1 -- 2 See D.2 -- 2 See D.3 -- 2 For Q2, select one preferred method from the four listed methods of non-destructive testing. For Q3, radiographic examination is required. Surface magnetic particle examination. Liquid penetrant examination. Radiographic examination. Ultrasonic examination. Documentation 100% coc 100% coc plus 100% coc plus See D.1 -- 3 See D.2 -- 3 See D.3 -- 3

  8. ISO 17078-2 ISO/WD 17078‑2 Petroleum and Natural Gas Industries Down hole equipment Part 2: Flow control devices Violators may be prosecuted.

  9. Environmental service grades Characteristics Grade El -- Standard service Non-sour service Grade E2 -- Stress corrosion cracking service H2S (sour) service1 Grade E3 -- CO2 service CO2 service2 Grade E4 -- Special service Special service requirements defined by the user/purchaser Environmental Service Grade Environmentalservice grades Table A-1 ____________________ 1Per NACE MR-01-75 2There are no published international standards for CO2 service. Each individual situation shall be evaluated on a case-by-case basis.

  10. Design Verification Tests

  11. Design Verification Tests

  12. ISO 17078.3 ISO/WD 17078‑3 Petroleum and Natural Gas Industries Down hole equipment Part 3: Latches and KOT’s Violators may be prosecuted.

  13. ISO 17078-3

  14. ISO Gas-Lift Standard Meeting Schedule Time Line 1998 1999 2000 2001 2002 2003 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 1920 • Meeting Topics to be Addressed • No. Location Date Host General 17078.1 17078.2 17078.1 • 1Houston, TX 02/05/98 Camco Organize ISO Gas-Lift Committee • 2 Houston, TX 05/04/98 Camco Draft Outline for ISO Gas-Lift Standard Document • 3 Houston, TX 05/10/99 Shell Review Plan for ISO Gas-Lift Documents • 4 Houston, TX 11/15/99 Shell Review Plan for ISO Gas-Lift Documents • 5 Houston, TX 03/01/00 Shell Review Plan for ISO Gas-Lift Documents • 6 Houston, TX 05/02/00 Shell Review Plan for ISO Gas-Lift Documents • 7 Atlanta, GA 07/25/00 Decker Tech Review ISO 17078.1 Clauses 3 - 5 • 8 Dallas, TX 10/06/00 Decker Tech Review ISO 17078.1Clauses 6 & 7 • 9 Houston, TX 02/08-09/01 Weatherford Review Entire ISO 17078.1 • Houston, TX 05/22-24/01 Schlumberger Complete (Almost) ISO 17078.1, Begin Work on ISO 17078.2 • Houston, TX 07/18/01 Chevron Complete 1st Draft of ISO 17078.1 for WG #4 Review • Austin, TX 09/04/01 OAC Prepare 1st Draft of ISO 17078.1 for Delivery to WG #4 • Austin, TX 10/08-09/01 Univ. of Texas Review 1st Draft of ISO 17078.2 • 14 Aberdeen, UK 11/14-15/01 Shell EXPRO Continue Review of ISO 17078.2 • 15 Houston, TX 2/07-08/02 Prod. Assoc. Continue Review of ISO 17078.2 , Address WG #4 Comments on 17078.1 • 16 Houston, TX 5/09-10/02 BPComplete 1st Draft of ISO 17078.2 for WG #4 Review, Review ISO 17078.3 • 17 San Antonio, TX 10/03-04/02 SwRI Continue Review of ISO 17078.3 • 18 Houston, TX TBD TBD • 19 Houston, TX TBD TBD • 20 TBD TBD TBD Blue Completed Rust Scheduled Black To Be Scheduled
