Apparent Weight

Apparent Weight. General Physics. Apparent Weight. Definition: The force exerted by the scale (F N ) Free-body Diagram: Equations: F net = F N + F g ( free-body diagram) F net =ma (Newton’s 2 nd Law) So, ma = F N + F g F g = mg (weight). F N. F g.

mabli
Télécharger la présentation

Apparent Weight

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Apparent Weight General Physics

  2. Apparent Weight • Definition: The force exerted by the scale (FN) • Free-body Diagram: • Equations: • Fnet=FN + Fg ( free-body diagram) • Fnet=ma (Newton’s 2nd Law) • So, ma = FN + Fg • Fg = mg (weight) FN Fg

  3. Problem: Your mass is 60 kg. You stand on a bathroom scale in an elevator. What will the scale read if you are …..at rest Fg -= mg = (60kg)(-9.8 m/s2) = -588 N FN = 588 N FN Fg

  4. accelerating upward at 3.0 m/s2? a Fnet FN Fg = -588 N Fnet= ma= (60kg)(3.0 m/s2) = 180N Fnet=FN +Fg , so FN =Fnet – Fg = 180N – (-588N) = 768 N Fg

  5. moving at a constant velocity? Fnet= 0 Fg = -588 N FN = 588 N FN Fg

  6. accelerating downward at 3.0 m/s2? Fg = -588 N Fnet= ma= (60kg)(-3.0 m/s2) = -180N Fnet=FN +Fg , so FN =Fnet – Fg = -180N – (-588N) = 408 N a Fnet FN Fg

  7. freefalling because cable breaks? FN = 0 Weightlessness Fg
