1. Security in Cloud Srinivasan Narayanamurthy Vineet Pandey University Day Student Workshop dt. March 07, 2013

2. Outline of the talk • Cloud computing • problem with the deployment models • Threats • Attacks • Recent news and techniques • For the break-out session

3. Characteristics Service & Deployment Models Private Partner Community Hybrid Public End Users Software as a Service (SaaS) • Only basic OS-level protections • Easily bypassed by a malware Platform as a Service (PaaS) • Tenants rent VMs • Isolation provided by the Hypervisor Infrastructure as a Service (IaaS) Physical Infrastructure

4. Source: Cloud Security Alliance, 2010 https://cloudsecurityalliance.org/topthreats/csathreats.v1.0.pdf • Could expose more functionality than intended • Policy could be circumvented • Credentials may need to be passed – is the interface secure? Insecure APIs • Password and key cracking • DDoS • Launching dynamic attack points • Hosting malicious data • Botnet command and control • Building rainbow tables • CAPTCHA solving Abuse & Nefarious use Malicious Insiders • Particularly poignant for cloud • Little risk of detection • System administrator qual. and vetting process differ Shared Technology Vuln. • Unknown Risk Profile • Is the cloud maintained? • Companies do not disclose • Is the infrastructure up to date (patches & firmware) • Does the combination of different service providers create previously unseen vulnerabilities? • Underlying architecture (CPU cache, GPU, etc.) not intended to offer strong isolation properties • Virtualization hypervisor used to mediate access between guest OS and physical resources • Exploits exist (Blue Pill, Red Pill) Threats Unknown Risk Profile • Data is outside the owner’s control • Data can be deleted or decoupled (lost) • Encryption keys can be lost • Unauthorized parties may gain access • Caused by • Insufficient authN, authZ, and access controls • Persistence and remanance • Poor disposal procedures • Poor data center reliability Account, Service, Traffic Hijacking Data loss /leakage • Exploits phishing attacks, fraud, or software vulnerabilities • Credential reuse

5. Past Attacks • Blue Pill, Red Pill (Joanna Rutkowska, Black Hat 2006) • Blue Pill – rootkit based on x86 virtualization • Red Pill – detect the presence of a virtual machine • Cloudburst (2009-10) • Enables guest VM to attack its host • US-CERT VU#649219 (CloudBurst) • SYSRET 64-bit operating system privilege escalation vulnerability on Intel CPU hardware

6. Attacks demonstrated • MIT (Ristenpart et al.) demonstrated cross-tenant attacks* • Amazon EC2 • Proof of attacker VM collocation • Side channels in shared hardware (L2 cache) • DoS • WordpressOutage June 2010** • 100s of tenants (CNN,…) down in multi-tenant environment. • Uncoordinated change in database • Amazon, Apple, T-Systems availability issues during 2012 • * Ristenpart, T., Tromer, E., Shacham, H., and Savage, S. Hey, you, get off of my cloud: Exploring information leakage in third-party compute clouds. In Proceedings of the 16th ACM Conference on Computer and Communications Security (Chicago, Nov 9–13). ACM Press, New York, 2009, 199–212 • ** http://smoothspan.wordpress.com/2010/06/11/wordpress-and-the-dark-side-of-multitenancy/

7. Insecure APIs Malicious Insiders Abuse & Nefarious use • Secure REST API with OAuth & OIdentity • CryptDB • 35% IT Sabotage • 18% theft of intellectual property • 40% fraud • Beyond encryption (RSAConf 2013) • Zeus botnet Unknown Risk Profile Shared Technology Vuln. Threats • TPM & vTPM • Side channels by Buffer Overflow • Multiple cloud provisioning(Rightscale) • Key management by the tenant • Crypto shredding • Federated identity management Account, Service, Traffic Hijacking Data loss /leakage

8. For the Break-out Session • Guarantees Required • Security • Encryption (PDP) • Integrity checking (PoR) • Freshness guarantee • Availability • Reliability & Correctness (PoW) • Beyond RAID-5 & RAID-6

10. Cloud computing • Cloud computing is a model for enabling convenient, on-demand network access to a shared pool of configurable computing resources (e.g., networks, servers, storage, applications, and services) that can be rapidly provisioned and released with minimal management effort or service provider interaction • Source: NIST • (http://www.csrc.nist.gov/groups/SNS/cloud-computing/index.html)

11. Characteristics Service & Deployment Models Private Partner Community Hybrid Public End Users - Application as a service - Online CRM (Salesforce CRM), word processing (Google Docs), etc. Software as a Service (SaaS) - Run-time environments - Lifecycle management Software - Google App Engine, Force.com, Azure Platform as a Service (PaaS) - Compute resource as a service - Hardware & OS abstractions - Amazon EC2, S3 Infrastructure as a Service (IaaS) Physical Infrastructure
