  1. IT 20303 • Relational Database Theory

  2. Relational Database Theory • The Relational Theory • Ways of working with data • Types of “Models” • File database model • Hierarchical database model • Network database model • Relational database model

  3. Relational Database Theory • The Relational Theory • Meaning of database model • The way data is organized & stored • The way data is manipulated

  4. Relational Database Theory • Relational Model of Data • Published in 1970 by Dr. Edgar (Ted) Codd – IBM • “A Relational Model of Data for Large Shared Data Banks”

  5. Relational Database Theory • Relational Model of Data • Purpose • Achieve program/data structure independence • Treat data in a disciplined way • Apply rigor of mathematics • Uses Set Theory – sets of related data • Improve programmer productivity

  6. Relational Database Theory • The Relational Model • Relational uses familiar concepts • The data is perceived as organized in tables • Relational also incorporates the rigor of mathematics • Rows of the table are treated as elements in a set • Manipulation of rows is based on set operations – (Vinn Diagrams) • User works with a set of rows at a time

  7. Relational Database Theory • Relational also impacts Data Design • Files were often constructed to support an application • Tables are designed to describe one thing or Entity in the database

  8. Relational Database Theory • Example of a Relation: • ANIMAL – Entity (Relation)

  9. Relational Database Theory • Definition of a Relation • Data is organized & stored in structures called relations • A relation is a table that adheres to certain rules • A relation can be called a table

  10. Relational Database Theory • Definition of a Relation • A relation is a table containing all the data about some entity • An entity is a thing or object that is important in this application area • Data items in the table are related

  11. Relational Database Theory • Relational Data Structure Name Species Weight Domains Attributes Primary Key Tuples Relation

  12. Relational Database Theory • Relational Data Structure Definitions • Relation • The Table • Tuple • A Row • Attribute • A Column

  13. Relational Database Theory • Relational Data Structure Definitions • Primary Key • A unique identifier for the table • Domain • A pool of legal values from which an attribute value is selected • Related to meaning • Has a Data Type

  14. Relational Database Theory • Relational Data Structure Definitions • Degree • The number of attributes • Cardinality • The number of tuples

  15. Relational Database Theory • Relational Table Rules • A Relation is a table that adheres to the following rules: • There are No Duplicate Tuples in the table • The tuples in the table are treated as a mathematical set

  16. Relational Database Theory • Relational Table Rules • By definition, a set is a collection of unique elements • There must be a primary key (unique identifier) for each tuple

  17. Relational Database Theory • Relational Table Rules • There is no order to the tuples (top to bottom) • There is no order to the attributes (left to right) • By convention, the primary key attribute is usually the first one on the left side of the table

  18. Relational Database Theory • Attributes • Each attribute has a datatype • Examples: Integer, character, date, user-defined • The data value of an attribute can be null

  19. Relational Database Theory • Attributes • Each attribute value is atomic • There is One & Only One data value in each cell of the table • There are no Lists or Arrays • One fact per field, one field per fact • Can be called a Field (MS Access)

  20. Relational Database Theory • Relational Data Structure: Design • Each relation contains data about only one entity • Each row corresponds to one unique occurrence of the entity • A relation does not contain arrays, lists or repeating groups • No multi-valued attributes

  21. Relational Database Theory • Tables are designed according to Rules of Normalization • Each data item in the table is determined • By the Primary Key • By the Whole Primary Key • Only by the Primary Key

  22. Relational Database Theory • Normalization avoids well-known update problems • Optimizes design to minimize redundancy & storage requirements

  23. Relational Database Theory • Example: Table with repeating group • Animal

  24. Relational Database Theory • Example: Table with no repeating group Animal-Food Animal

  25. Relational Database Theory • A Database Models the Real World • A Database represents Reality • The database is a collection of relations • A relation represents an entity type • Each tuple represents one occurrence of that entity type • Each occurrence of an entity is unique

  26. Relational Database Theory • A Database Models the Real World • A database contains information about • Entities • Relationships between entities • Rules about the entities’ data & the relationships

  27. Relational Database Theory • Relational Databases Support Relationships • Relational databases support relationships between entities • Relationship is established by a Foreign Key • Repeat the Primary Key of one table in the related table(s)

  28. Relational Database Theory • Example: The Zoo has an “Adopt-an-Animal” program • A zoo member can adopt an animal Foreign Key Zoo-Member Animal

  29. Relational Database Theory • Example: Another Relationship Animal-Food Composite Primary Key Animal Foreign Key

  30. Relational Database Theory • Relational Integrity Rules • Entity Integrity • No part of the Primary Key (PK) may be Null • Referential Integrity • The value of a Foreign Key (FK) must either • Be Null or • Be one of the values of the PK in the related table

  31. Relational Database Theory • Keys, Keys, and More Keys • Characteristic of a Primary Key (PK) • Unique • Mandatory • Unchanging • Under the control of IT organization

  32. Relational Database Theory • Keys, Keys, and More Keys • Names or Types of Keys • Candidate Key • A minimal set of attributes that can be used as the unique identifier for a table

  33. Relational Database Theory • Keys, Keys, and More Keys • Names or Types of Keys • Primary Key • One of the candidate keys • Alternate Key • A candidate key that is not the primary key

  34. Relational Database Theory • Keys, Keys, and More Keys • Names or Types of Keys • Foreign Key • A primary key of a related table • Indicates relationships

  35. Relational Database Theory • Keys, Keys, and More Keys • Names or Types of Keys • Composite Key • A key composed of more than one attribute • Search Key • One or more attributes on which a retrieval is based • Indexes

  36. Relational Database Theory • Characteristics of Relationships • Referential integrity applies to the relationship between entities • Also known as an existence constraint or an enterprise rule • For every relationship, referential integrity must be defined

  37. Relational Database Theory • Relationships have Cardinality • One-To-One • One-To-Many • Many-To-Many • Relationships have Optionality • Each entity’s participation is either • Mandatory or • Optional

  38. Relational Database Theory • Cardinality reflects Business Rules • One-To-One Relationship • One animal is cared for by one zoo worker • One zoo worker cares for one animal

  39. Relational Database Theory • Cardinality reflects Business Rules • One-To-Many Relationship • One animal is cared for by many zoo workers • One zoo worker cares for only one animal

  40. Relational Database Theory • Cardinality reflects Business Rules • Many-To-Many Relationship • One animal is cared for by many zoo workers • One zoo worker cares for many animals

  41. Relational Database Theory • Mandatory Relationship • The Foreign Key Cannot be Null • Every purchase order must have a supplier • In the example below the FK, SNO, cannot be Null

  42. Relational Database Theory • Example: PORDER SUPPLIER

  43. Relational Database Theory • Example: FK can be Null Foreign Key ZOO-MEMBER ANIMAL

  44. Relational Database Theory • What happens when a Tuple is deleted? • For every relationship, there are three possible delete options • Cascades • Delete the target tuple and • Delete the related tuples

  45. Relational Database Theory • Restricted • Delete restricted to cases for which there are no related tuples • Nullifies • Delete the target tuple and • Set the FK to null in the related tuples

  46. Relational Database Theory • Relational Algebra Operations • Select • Project • Join • Union • Intersect • Difference

  47. Relational Database Theory • Our Zoo Database Tables ANIMAL-FOOD ANIMAL ZOO-MEMBER

  48. Relational Database Theory • Relational Algebra: SELECT • Extracts specified tuples from a relation (or get rows from a table)

  49. Relational Database Theory • Example: SELECT out from the ANIMAL-FOOD table (display) the rows where FOOD=PEOPLE ANIMAL-FOOD RESULTS

  50. Relational Database Theory • Relational Algebra: PROJECT • Extracts specified attributes(columns) from a relation (or get columns from a table)
