Linear Positioning System

This document outlines the critical components of a high-precision linear positioning system designed by Tony Swanson and Chris Biedrzycki. Key elements include a lead screw paired with a lead nut featuring a reflecting plate for accurate positioning. The system utilizes an ultrasonic sensor capable of measuring distances from 4 to 30 inches and ensures repeatability within 1/16 inch. A robust 24V DC gear motor, offering a maximum speed of 115 RPM and a stall torque of 214 in-lb, drives the system, supported by durable ball bearings and vertical supports.

major
Télécharger la présentation

Linear Positioning System

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Linear Positioning System Tony Swanson Chris Biedrzycki

  2. Key Components • Lead screw • Lead nut with reflecting plate • Supports • Ultrasonic sensor • Motor • Circuitry

  3. Ultrasonic Sensor • Range: 4 – 30 in • “Pings” target • Repeatable to within 1/16”

  4. Lead Nut • Slides on 2 ball bearings • Supported with two vertical supports • Bolt through reflective plate

  5. Motor • 24V DC gear motor • Max 115 rpm, no load @ 24V • 214 in-lb stall torque

  6. Circuitry

  7. QUESTIONS?
