  1. Numbers and number systems Lecture 2

  2. Some material from the last lecture • Electronic computers represent information as voltage levels. • To make the computer hardware simple and reliable, computers represent information in binary form. • example: voltages greater than 3V are interpreted as representing one value (called “1”), voltages less than 2V are interpreted as representing another value (called “0”). • In principle, could use more voltage levels. • example: 0 to .75V represents “0”, 1 to 1.75V represents “1”, 2 to 2.75V represents “2”, and so forth. • In practice, this is rarely done. • requires more complex circuits • circuits are more susceptible to noise, hence less reliable

  3. 5v 4v 3v 2v 1v 0v Undefined High Undefined High Low Low noise margin 3 V noise margin 1 V Some material from the last lecture • Computers, like all electronic systems, are affected by noise. • noise has various sources (nearby signal changes, thermal vibrations of molecules in semiconductor materials, . . . ) • in computers, noise can cause binary signals to be misinterpreted • The noise margin is the amountof noise that a system cantolerate and still correctlyidentify a logic high or low.

  4. Radix number systems • Some number of positions and some number of symbols • The number of positions varies by context • The number of symbols is a property of the number system • Decimal -- 10 symbols • Binary -- 2 symbols • Octal -- 8 symbols • Hexadecimal -- 16 symbols

  5. Start with whole numbers • Each position has a value • Each symbol has a value • Multiply the value of the symbol by the value of the position, then add • In decimal, 3874 means • 3 times 1,000 • plus 8 time 100 • plus 7 times 10 • plus 4 times 1

  6. Decimal, binary, octal, hex • In decimal there are 10 symbols (0..9) and the value of each position is a power of 10. • 100 = 1 = value of the units position • 101 = 10 = value of next position to the left • etc. • In binary, there are 2 symbols, 0 and 1, and the value of each position is a power of 2. • In octal, 8 symbols, and powers of 8 • In hexadecimal, 16 symbols, and powers of 16

  7. Most Significant digit Decimal Number: 378.4 Least Significant digit . is called the radix point 3 is the MSD 4 is the LSD

  8. Least Significant bit Most Significant bit 110010012 = 127+ 126 + 123 + 120 = 201 Least Significant bit Most Significant bit 110010.012 = 125+ 124 + 121 + 12-2 = 50.25

  9. K, M and G • 210 is referred as K (kilo) • 220 is referred as M (mega) • 230 is referred as G (giga)

  10. Trinary Numbers Trinary number : 110010023 110010013 = 137+ 136 + 133 + 230 = 2945

  11. Octal Numbers Octal number : 127.48 110010013 = 182+ 281 + 780 + 48-1 = 87.5

  12. Hexadecimal Numbers Hexadecimal number :FA9H FA9H = 15162 + 10161 + 9160 = 4009

  13. Things to do • Review from your class notes what we discussed today. • Conversions between Number Systems • Binary, octal and hexadecimal • Solve 1-6 before coming to the class
