Data Queries Selecting features in ArcMap
Data queries • Important part of a GIS project • Can be a part of your data preparation or final analysis • Data Queries (selecting data based on a question or criteria) • Attribute Query • Spatial Data Query • Raster Data Query
Attribute Data Query • SQL (Structure Query Language) is used select records from an attribute table • Structure (syntax) of the query language • Select <attribute> (select field or column) • From <relationship> (defines a table) • Where <condition> ( some condition or criteria) Selectname Fromcounties Where name= Monterey • Query Expressions • Boolean expressions • Combination of field, a value, and a logical operator (=, +, - , etc..) • Boolean connectors (AND, OR, XOR, NOT) • Connects two expressions Select from the “name” field in the “counties” table, where the values=“Monterey”
Query Expressions • Boolean Expression • Combination of field, value, and an operator • Name = Monterey • Pop2000 >=400,000 • State_Name= Calfornia • Boolean connectors • Keywords that connect two expressions • State_Name = California AND Pop2000>= 400,000 • State_Name = California OR Pop2000>= 400,000
Query Expressions – Boolean Connectors - AND • State_Name = California AND Pop2000 >= 400,000 • AND - satisfy both criteria - intersection
Query Expressions – Boolean Connectors - OR • State_Name = California OR Pop2000 >= 400,000 • OR - satisfy either one or both criteria - union
Spatial Data Query 3 Ways to select features spatially • Feature selection by cursor - (select features tools) • Feature selection by graphic - (draw a graphic and use it to select features) • Feature selection by spatial relationship • Containment (fall within a feature) • Intersect (intersect a feature) • Proximity ( within a specified distance)
Working with selected features • create new selection • add to currently selected features • remove from currently selected features • select from currently selected features You can add, remove or select from currently selected features using location and attribute queries.
Isolating your selected features • Permanently save your selected features • save as new data file (shapefile or geodatabase) • Right-click on layer data Export data • Temporary save your selected features • create a temp layer in your ArcMap project as • Right-click on layer selection create layer from selected features • One extra step …. • --- to create a .lyr file • Right-click on layer Save As Layer File
Summary of selection types • Select by attribute using SQL • In ArcMap you can find this in the: • Selection menu • Attribute table • Definition query – displays data only • Located in the layer’s properties • Spatial Query: • Manually using the cursor • Select by graphics • Select by Location dialog
