  1. Network Layer (4)

  2. host part network part 11001000 0001011100010000 00000000 200.23.16.0/23 Classless Addressing • Addresses allocated in contiguous blocks • Number of addresses assigned always power of 2 • Network portion of address is of arbitrary length • Address format: a.b.c.d/x • x is number of bits in network portion of address

  3. Classless addressing • Example. • Cambridge 194.24.0.0/21 194.24.0.0 -- 194.24.7.255 • Edinburgh 194.24.8.0/22 194.24.8.0 -- 194.24.11.255 • (Available) 194.24.12.0/22 194.24.12.0 -- 194.24.15.255 • Oxford 194.24.16.0/20 194.24.16.0 -- 194.24.31.255

  4. 223.1.1.1 223.1.2.1 223.1.1.2 223.1.2.9 223.1.1.4 223.1.2.2 223.1.3.27 223.1.1.3 LAN 223.1.3.2 223.1.3.1 IP Addressing first 24 bits are network address

  5. 223.1.1.2 223.1.1.1 223.1.1.4 223.1.1.3 223.1.7.0 223.1.9.2 223.1.9.1 223.1.7.1 223.1.8.1 223.1.8.0 223.1.3.27 223.1.2.6 223.1.3.1 223.1.3.2 223.1.2.1 223.1.2.2 IP Addressing Interconnected system consisting of six networks

  6. CIDR • A router keeps routing table with entries • IP address, 32-bit mask, outgoing line • When an IP packet arrives, the router checks its routing table to find the longest match.

  7. CIDR • Example. • Cambridge 194.24.0.0/21 194.24.0.0 -- 194.24.7.255 • Edinburgh 194.24.8.0/22 194.24.8.0 -- 194.24.11.255 • (Available) 194.24.12.0/22 194.24.12.0 -- 194.24.15.255 • Oxford 194.24.16.0/20 194.24.16.0 -- 194.24.31.255 • When a packet addressing to 194.24.17.1 arrives, where should it be sent to?

  8. CIDR – Entry aggregation • How does a router in Tallahassee route packet to C,E and O, assuming that he has only two outgoing links? • All to New York. • Can he reduce the size of his routing table? C E N O H T

  9. CIDR Entry Aggregation • From 194.24.0.0 to 194.24.31.255, all to N. • So aggregate the three entries into one 194.24.0.0/19. • The N router can do the same thing. C E N O H T

  10. CIDR • If later the free address space 194.24.12.0/22 194.24.12.0 -- 194.24.15.255 is assigned to Pittsburgh and has to go through Houston, what should the router at Tallahassee do? C E N P O H T

  11. CIDR • When a packet arrives addressing 194.24.15.8, the router checks the routing table and there will be two matches: 194.24.12.0/22 and 194.24.0.0/19. Pick the longest match.

  12. NAT – Network Address Translation • IP address is a scarce resource. • So, give a company only one or a few IP addresses used by the gateway router. • Within the company, each machine has an unique IP address, chosen from • 10.0.0.0/8 • 172.16.0.0/12 • 192.168.0.0/16 • These addresses can only appear within a company but never on the outside Internet

  13. NAT • Whenever a machine wants to send a packet to the outside, the packet will be sent to the NAT box. • The NAT box will convert the internal IP address to the real IP address of the company, and pass the packet to the gateway router. • When there is a packet destined for an internal machine arrived at the router, what should the router and NAT box do? • For IP packets carrying TCP or UDP, use port number. Other protocols are much more compliated.

  14. NAT • For IP packets carrying TCP or UDP, use port number. • When an outgoing packet arrives at the NAT box, • The IP address is replaced • The source port number is replaced • Header checksum is recomputed • When a reply came for this process, use the replaced source port number as index to find the correct IP address and original port number.

  15. ICMP • ICMP – Internet Control Message Protocol • Each ICMP message is encapsulated in an IP packet • Treated like any other datagram, but no error message sent if ICMP message causes error • Some interesting messages: • Time exceeded: When an IP packet arrived at a router is dropped because the TTL field becomes 0, the router will send an ICMP TIME EXCEEDED message back to the source. Used in traceroute. • Echo and Echo reply: ping.

  16. Address Resolution • IP address is virtual • Not understood by underlying the hardware of physical networks • IP packets need to be transmitted by the underlying physical network • Address resolution • Translating IP address to physical address • Address Resolution Protocol (ARP) Computer Science, FSU

  17. ARP Example Computer Science, FSU

  18. ARP Cache • Each computer maintains a cache table • IP address  hardware address mapping • Only about computers on the same network • Exchanges ARP messages • To resolve IP addresses with unknown hardware addresses Computer Science, FSU

  19. ARP Protocol • When a node sends an IP packet • To another node on the same physical network • Look up destination address in the ARP table • If not found • Broadcast a request to the local network • Whose IP address is this? Computer Science, FSU

  20. ARP Response • The target node responds to sender (unicast?) • With its physical address • Adds the requester into its ARP table (why?) • On receiving the response • Requester updates its table • Other nodes upon receiving the request • Refresh the requester entry if already there • No action otherwise (why?) • Table entries deleted if not refreshed for a while Computer Science, FSU

  21. DHCP • DHCP – Dynamic Host Configuration Protocol • A new machine asks for an IP address • Broadcast DHCP DISCOVER packet • A DHCP relay agent got this packet and relay it to the DHCP server • The DHCP server assigns an IP address • Periodically renew

  22. gateway routers Hierarchical Routing • aggregate routers into regions, “autonomous systems” (AS) • routers in same AS run same routing protocol • “intra-AS” routing protocol • routers in different AS can run different intra-AS routing protocol • special routers in AS • run intra-AS routing protocol with all other routers in AS • also responsible for routing to destinations outside AS • run inter-AS routing protocol with other gateway routers

  23. c b b c a C.b A.c A.a B.a Intra-AS and Inter-AS routing • Gateways: • perform inter-AS routing amongst themselves • perform intra-AS routing with other routers in their AS b a a C B d A network layer inter-AS, intra-AS routing in gateway A.c link layer

  24. Inter-AS routing between A and B b c a a C b B b a c d Host h1 A A.a A.c C.b B.a Intra-AS and Inter-AS routing Host h2 Intra-AS routing within AS B Intra-AS routing within AS A

  25. Why different Intra- and Inter-AS routing ? • Policy: • Inter-AS: admin wants control over how its traffic routed, who routes through its net. • Intra-AS: single admin, so no policy decisions needed • Scale: • hierarchical routing saves table size, reduced update traffic • Performance: • Intra-AS: can focus on performance • Inter-AS: policy may dominate over performance

  26. Intra-AS Routing • Also known as Interior Gateway Protocols (IGP) • Most common IGPs: • RIP: Routing Information Protocol • OSPF: Open Shortest Path First • IGRP: Interior Gateway Routing Protocol (Cisco proprietary)

  27. OSPF • Represents the network as a graph, and runs the shortest path algorithm to find the path to any router. • Divide the network into areas for scalability. • The backbone area is called area 0 • Within one area, a router has the same link state database as all other routers. Routers belonging to two areas keeps two databases. Link state in one area is not told to other areas. • Route: local area  backbone  local area

  28. OSPF • Each router knows the shortest path to reach routers within his area. • Backbone routers also accept information from area border routers to compute the shortest path to reach other routers. Then advertise this information to the border routers, who tells routers inside the area. – To be able to select the best exit router in an area

  29. OSPF • To learn the link state, use flooding • Inefficient to talk to every router on the same LAN • So, select a designated router and let it to be adjacent to all other routers on the same LAN. Only exchange link state between the adjecent routers • Messages include • HELLO, LINK STATE UPDATE, LINK STATE ACK, DATABASE DESCRIPTION, LINK STATE REQUEST

  30. Inter-AS routing

  31. Internet Inter-AS routing: BGP • BGP (Border Gateway Protocol): the de facto standard • Path Vector protocol: • similar to Distance Vector protocol • each Border Gateway broadcast to neighbors (peers) entire path (I.e, sequence of ASs) to destination • E.g., Gateway X may send its path to dest. Z: • Path (X,Z) = X,Y1,Y2,Y3,…,Z

  32. Internet Inter-AS routing: BGP • BGP messages exchanged using TCP. • BGP messages: • OPEN: opens TCP connection to peer and authenticates sender • UPDATE: advertises new path (or withdraws old) • KEEPALIVE keeps connection alive in absence of UPDATES; also ACKs OPEN request • NOTIFICATION: reports errors in previous msg; also used to close connection

  33. Internet Inter-AS routing: BGP • Suppose: gateway X send its path to peer gateway W • W may or may not select path offered by X • cost, policy (don’t route via competitors AS), loop prevention reasons. • If W selects path advertised by X, then: • Path (W,Z) = W, Path (X,Z) • Note: X can control incoming traffic by controlling its route advertisements to peers: • e.g., don’t want to route traffic to Z  don’t advertise any routes to Z

  34. NLRI=128.186.0.0/16 ASPATH=[0] NLRI=128.186.0.0/16 ASPATH=[10] NLRI=128.186.0.0/16 ASPATH=[10] NLRI=128.186.0.0/16 ASPATH=[210] NLRI=128.186.0.0/16 ASPATH=[610] NLRI=128.186.0.0/16 ASPATH=[610] NLRI=128.186.0.0/16 ASPATH=[210] NLRI=128.186.0.0/16 ASPATH=[7610] NLRI=128.186.0.0/16 ASPATH=[4210] NLRI=128.186.0.0/16 ASPATH=[3210] BGP: an example [3210]* [4210] [7610] 128.186.0.0/16

  35. BGP C • Line FG goes down. • Node F wants to find path to D. • B: BCD • E: EFGCD • I: IFGCD • F can quickly decide to ignore the paths from I and E. B D A G F H E J I

  36. Virtual Circuit • Destination information is large and the table is large • Consider 32 bit IP address. A full table will have 4G entries. • If an IP packet is 1250 byte long and the link speed is 10Gbps, how much time do you have for this lookup? • (1. You don’t have to implement the full table. 2. You can also use pipeline.)

  37. Virtual Circuit • Circuit means a path between the source and the destination. • Real circuit switching has a physical path set up between the source and the destination, like telephone network • When you dial, a request is sent to the network, network finds if there are free links on the path and reserve that link for you. • Virtual circuit is different – used in packet switching networks. • No real path set up, because it is packet switching (although link bandwidth can be reserved). • But still has the connection phase. The purpose is to let the routers know how to route the packets of this virtual circuit.

  38. Virtual Circuits H2 B D • When setting up the virtual circuit, a VC identifier is picked. The router knows where to forward a packet with a certain VC identifier. • Each packet will carry the VC identifier, which is much shorter than the full destination address, so allows more efficient table lookup. • Resources can also be reserved. QoS. • A practical problem in a distributed environment – different stations may pick the same VC identifier. • Labels can be swapped without causing confusion. A F H3 C H1 E A’s Table In Out H1, 1 C, 1 H2, 1 C, 2 C’s Table In Out A, 1 E, 1 A, 2 D, 1
