1. GPUs and Accelerators Jonathan Coens Lawrence Tan Yanlin Li

2. Outline •  Graphic Processing Units • Features • Motivation • Challenges •  Accelerator • Methodology • Performance Evaluation • Discussion •  Rigel • Methodology • Performance Evaluation • Discussion •  Conclusion

3.   Graphics Processing Units (GPU) • GPU • Special purpose processors designed to render 3D scenes • In almost every desktop today • Features • Highly parallel processors • Better floating point performance than CPUs • ATI Radeon x1900 - 250 Gflops • Motivation • Use GPUs for general purpose              programming • Challenges • Difficult for programmer to program • Trade off between programmability              and performance GeForce 6600GT (NV43) GPU

4. Accelerator: Using Data Parallelism to Program GPUs for General Purpose Uses • Methodology • Data Parallelism to program GPU (SIMD) • Parallel Array C# Object  • No aspects of GPU are exposed to the programmer • Programmer only needs to know how to use the Parallel Array • Accelerator takes care of the conversion to pixel shader code • Parallel programs can be represented as DAGs Simplified block diagram for a GPU Expression DAG with shader breaks marked

5. Accelerator: Using Data Parallelism to Program GPUs for General Purpose Uses Performance Evaluation Performance of Accelerator versus hand coded pixel shader programs on a GeForce 7800 GTX and an ATI x1800. Performance is shown as speedup relative to the C++ version of programs Speedup of Accelator programs on various GPU compared to C++ programs running on a CPU

6. Rigel: 1024-core Accelerator Specific Architecture • SPMD programming model • Global address space • RISC instruction set • Write-back cache • Cores laid out in clusters of 8, each cluster with local cache • Custom cores (optimized for space / power) Hierarchical Task Queueing • Single queue from programmer's perspective • Architecture handles distributing tasks • Customizable via API • Task granularity • Static vs. dynamic scheduling

7. Rigel's Performance Fairly Successful • Achieved speedup utilizing all 1024 cores • Hierarchical task structure effectively scaled to 1024 Issues • Cache coherence! • Memory invalidate broadcasts slow system down  • Barrier flags • Task enqueue / dequeue variables •  Not done in hardware... • Lazy-evaluation write-through barriers at cluster level

8. Improving Rigel • Will the hierarchical task structure continue to scale? If not, when will the boundary be? (Think multiple cache levels but with processor tasks) • How could we implement barriers or queues to avoid contention, but still scale? (Is memory managed cache coherence appropriate?) • Is specialized hardware the way to go (clusters of 8 custom cores), or can this be replaced by general purpose cores?

9. Generic and Custom Accelerators • Difficult to make generic enough programming interface between programmer and multi-core system • GPUs are limited by SIMD programming model • Specific hardware platforms still have issues for SPMD • Efficiently scaling for more cores is still an issue     How do we solve these issues?
