  1. 研華工業級數位影像監控系統解決方案 IO Information On Screen & Intelligent Video Analysis .

  2. 現在影像監視的現況 “people concentration can’t focus on one target longer than 20 minutes” Sandia National Laboratories • Keep high Concentration on target! Security guard won’t need to concentrate on too many cameras, keep highly concentrated on target! Alarm! Progress

  3. 研華工業應用的影像三大技術 • Video Technology Trend • Explosive growth on new video compression technologies : MPEG4/H.264 • High-quality images Full DI ( Resolution : 720*480) • PC-based & IP-based transmission with low levels of video streaming data • Intelligent video content analysis technologies fast growth Mjpeg (2000-2004) H.263/ MPEG-2Wavelet (2001-2004) MPEG-4 Part 2 (2003-2005+) DVD MPEG-4 Part10 H.264/ (2005) H.264 DI Full quality MPEG4 DI quality 24 Weeks Storage capability 6 Weeks 3 Weeks 1 Week Hard-disk exchanged ( 120GB)

  4. 研華工業應用的影像三大技術 • Integration with SCADA • Video onto HMI : Integrated with SCADA S/W by Video OCX driver • Information On Screen : Combine ADAM or others IO devices into Video • Combined HMI S/W and Powerview into one platform monitoring by IE explorer EMS FA FMS ITS

  5. 研華工業應用的影像三大技術 • 3rd Party Device Integration • Support OCX and API libraries • NI Labview OCX supported • Support OPC server of Modbus , Modbus/TCP and ADAM • Example & Demo program ready • Integrated with 3’rd devices thr. Ethernet or RS232/485 Door Access ADAM Series Module I/O Card PLC , Temp Controller LabView Bar Code Reader POS ATM Receipt Printer

  6. Intelligent Transportation : • 道路監控 • 影像監視 • 違規停車 • 執法系統 • 超速拍照 • SCADA 整合

  7. Facility Management CAMERA Powerview 6000 Boiler Thermometer ADAM-4000

  8. Facility Management應用:影像與IO整合 Application Requirements : Filed Site : • DAQ Device • Facility Equipment • Video Surveillance • Communication Device • Central Control Room : • SCADA HMI system • Video Central Monitoring System • Video Storage System • Communication Device LCD Display RAID Recorder Operator Station Database Server Router Fire wall Broadcasting System Central Control Room Internet Camera DVR Field Site Temp. Pressure Flow Level

  9. Factory Automation : 設備操作資訊整合: • Shop Flow Data : • Good : 2000 pcs • Bad : 12 pcs Duty time schedule is 20 hr Average Downtime is 18 hours Production goods : Metal type Total Production : 28000 pcs

  10. 工廠製程&維護資訊整合 • 維護資訊: • Next shut down time is 2009 , 01,25 • Check water inlet , outlet control valve , • Clear burner , air source compressor • 製程資訊整合 • Liquid material : Steam • Recipe code : process 1 • Outdoor Temperature is 5oC • Flow rate is 500 liter per second • Pipe pressure is 50Kg /CM2 • Total flow volume is 5000 Ton • Working duty cycle is 36 hours , • Totally consumption volume is 300 l/h

  11. SCADA 圖控與影像整合

  12. 3’rd Party devices application POS Application Day : 2008,10,10 Time : 10:00:10 Noodle : 20 Egg : 10 Eraser : 10 Pay : 40 ID Card : A12345 Cash : 500 Day : 2008,10,10 Time : 10:00:10 ATMapplication

  13. Advantech New Video System Central Room SCADA S/W : WebAccess DVS CMS Internet Web-based Remote backup EKI series IP network EKI series DVS DVR DVS 16-Ch. DVR DVS IVS UNO-2000 WebAccess PowerView 6000 Analog camera Analog camera Video Surveillance SCADA system Intelligent Video ADAM-4000

  14. DVS Information-enable DVR Platform Disk On Module XPe Two LAN Ports 4- HD Hot SWAP Easy Install camera Temp : 50 degC Vibration : 500Hz More Com ports

  15. DVS CMS (Central Monitoring System) DVR1 VGA Output PowerView 6000 CMS Software • Support Twin-Monitor( 2 VGA ports) • eMap Function • Up to 128 cameras monitoring • Able to see 64 cameras on one screen • Able to connect 256 DVRs and Remote control • Triple-Monitor ( 3 VGA ports , By project) DVR2 Intranet DVR3 DVS CMS DVR

  16. DVS IVS ( Intelligent Video System) • PowerView IVS software • Support 6 video object behavior analysis • Unattended Object • Lost Object • Stopped Vehicle/ Virtual Fence • Car wrong direction • People/car Counting • Loitering • Support 4 video input • Event trigger to DVR thru. Ethernet • Support action mode in DVR • Video Recoding • Snapshot one picture • Send SMS to mobile phone • Send a eMail • Alarm out to buzzer • …etc • Smart search by time , objects DVS DVR Ethernet DVS IVS

  17. Unattended Object / Lost Object • Application Field: • Airport • Bus stop • Indoor environment • Museum • Smart detection of Unattended Object & Lost Object • Automatic Alarm: DI/O, SMS, eMail • Risk-prevented Surveillance System: analyze and detect object at live video frames • Connection with DVR simultaneously • Event Recording

  18. Virtual Fence & Counting • Application Field: • Traffic • Retailing Store • Highway Surveillance • MRT Station • Department Store • Automatic Alarm: DI/O, SMS, eMail • Risk-prevented Surveillance System: analyze and detect behavior at live video frames • Connect ion with DVR simultaneously • Event Recording

  19. Loitering • Application Field: • Banking • Retailing Store • Highway Surveillance • MRT Station • Automatic Alarm: DI/O, SMS, eMail • Risk-prevented Surveillance System: analyze and detect behavior at live video frames • Connection with DVR simultaneously • Event Recording • Connect with Powerview-ATM

  20. H.264 Compression • High Performance - H/W Compression PCI Interface PV-2000E PV-2100E PV-2200E PCI-104 Interface DVP-2124PV Video Capture Cards function by software Surveillance AP Solution SDK Solution PV Series • MPEG-4 Compression • Low Cost - S/W Compression PCI Interface PV-600E PV-800E PV-1000E DVP Series • MPEG-4 Compression Low Cost - S/W Compression PCI Interface DVP-7010BE DVP-7020BE High Performance - H/W Compression PCI Interface PCI-104 Interface DVP-7421BE DVP-2420E USB Interface DVP-1412E

  21. E化監控

  22. Traffic Needs : Live Video /Restriction area monitoring & Detection Vehicle /people Counting & Detection Virtual Fence function Value Proposition : Provide a intelligent function on Video monitoring & Object analysis Target Market Needs & Value Proposition • Restriction area People detection • Restriction area Vehicle Counting Live monitoring Live monitoring Stopped Vehicle/ Virtual Fence People Counting Live monitoring

  23. Factory / oil pipe / heat oven ….FMS , EMS SCADA Needs : Live Video /Restriction area monitoring & Detection Equipment Information On screen ( Temp. Level , flow..etc) Virtual Fence function Value Proposition : Provide a valuable video with data for monitoring , recording & action Target Market Needs & Value Proposition Temp : 42 degC Level : 12M Temp : 50 degC Vibration : 500Hz Temp : 32 degC Level : 10M Load : 20 Ton Vibration : 1KHz

  24. Target Market Needs & Value Proposition • Others Market : Retail/Building ….. • Needs : • Access control with Live video monitoring , • People/Car parking monitoring/counting • Unattended Object , Loitering • ATM/POS monitoring/recording • Value Proposition : • Provide a control center with intelligent function system People Counting Unattended Object Loitering

  25. New SCADA System With Video Architecture Distributed DA&C System ADAM-5000 Remote DA&C ADAM-4000 Remote DA&C ADAM-4000 Distributed DA&C System ADAM-5000 Analog Dome Cameras For FA , FMS , EMS , Traffic and BAS Market • Operator Station WebAccess /PowerVidew • SCADA/HMI function • Video Surveillance • - Video Recording/Playback • - Camera remote PTZ control • - Intelligent Video Detection CMS System Ethernet 100/1000BaseT Add-in Video Arch. UNO Exist IO Data Arch. EKI RS-485 Facility Manager Video Server RS232 RS-485 DVR-6070 Analog Fixed Camera

  26. Applications With DVR In Hazardous Area : Chemical –Gas Tank • Application overview • Remote Live video monitoring with IO • Measure tank Temp. level , gas pipe flow IO data • Our offering : • Video card DVP-2124PV , Uno-2172 , • ADAM 4017, Powerview 6000 , WebAccess • Winning Factor: • Dust free & Fanless UNO platform • High quality H.264 Hardware Compression • Integrate with Video and IO into one platform • OI information with video into one display via IE explorer at central room • PowerView 6000 Application Ready

  27. Applications In Water industry • Application overview • Live monitoring dam , river and water treatment station for security • Need Video on SACDA HMI WebAccess software • Our offering : • PV-600E , 800E and 2100E , IPPC , Powerview 6000 ,ADAM , WebAccess • Winning Factor: • One brand provide completed system • Easy to integration with SCADA • Remote monitoring via IE • 4 CIF high resolution display • Information OSD (On Screen Display) River level : 10M Bridge Load : 20 Ton

  28. Applications With DVP cards In Paper machine • Application overview • Live monitoring production line • Video with IO control in controller for temperature , process , inspection • Integrate with 3’rd party software and IO controller • Our offering : • DVP-7010E , DVP2420E , IPPC , UNO-2172 • Winning Factor: • Dust free & Fanless UNO platform • H.264 Hardware Compression • Video SKD example program • IO with Video integration

  29. 研華Automation整合的優勢 • Pioneer in video and information integration • Automation & Surveillance Ready Solution & Integration • Surveillance software  Powerview6000 • Central Monitoring System  PowerView CMS & Backup center • Intelligent Video System : Video Object Analysis : PowerView IVS • WebAccess SCADA/HMI Integration • Versatile Industrial-grade platforms & remote IO supporting UNO & TPC & ADAM I/O • More intelligent video surveillance function • Video Analysis, Virtual Fence, • Object Tracking, People counting , Car Wrong Direction

  30. Thank You IAG Video Surveillance IO & S/W Product Div.
