Slide 1:Timbre perception
Slide 2:Objective
Timbre perception and the physical properties of the sound on which it depends Formal definition: that attribute of auditory sensation in terms of which a listener can judge two sounds similarly presented and having the same loudness and pitch as being dissimilar.
Slide 3:Timbre
Related to musical instrument / object recognition To distinguish between the same note played on different instruments perceived quality of a sound Some sound quality descriptors: mellow, rich, harsh, shrill etc. Judgments of timbre subjective
Slide 4:Timbre
Pitch and loudness related to the physical properties of frequency and amplitude may be considered as one dimensional attributes of sound can be ordered on a single scale pitch (from low to high); loudness (from quiet to loud) Timbre is a multidimensional attribute of sound no single scale along which we can order the timbre of sounds
Slide 5:Timbre
Timbre depends on: Spectral envelope patterning of energy as a function of frequency Temporal properties fluctuations over time
Slide 6:Spectral envelope
A major determinant of timbre Overall distribution of energy over frequency e.g. Strong lower harmonics dark, mellow e.g. Strong higher harmonics bright, shrill More specifically timbre is related to the relative level in each critical band rem: The critical bandwidth variation with frequency this dscribes the spectral analysis carried out by the ear.
Slide 7:Spectral envelope
In a complex sound the partials are described as either resolved (lower components) or unresolved (high components) by the auditory system. Resolved and unresolved - related to the critical bands Timbre depends on whether most of the energy lies in resolved or unresolved components.
Slide 8:Spectral envelope example
The effect of spectrum on timbre asa demo 28, trk 53 recognise the musical instrument Listen and note the following: the point where you can identify each sound the point where recognition of the sound becomes unambiguous
Slide 9:Temporal properties
Timbre recognition may also depend on: whether a sound is periodic; waveform changes over time; spectral changes over time; preceding and following sounds (e.g. masking). The frequency components in a sound change over time - described by the temporal envelope Attack (onset) increase in amplitude Steady state Decay portion (offset) amplitude decreases
Slide 11:Temporal envelope
Diagram indicates different attacks for a plucked vs. a bowed violin string, also speech sounds ba wa have different attacks Plucked strings attack followed by decay the onsets (attacks) of sounds can be used to identify them recognition depends strongly on onsets and temporal structure of sound envelope
Slide 12:Effect of temporal envelope
Piano tone rapid onset and gradual decay Effect of temporal envelope in timbre perception - asa demo 29 (trk 54-56) Chorale played on piano and recorded Chorale played from end to beginning and recorded The recording of the backward chorale is played out in reverse causing each note to be reversed in time.
Slide 14:Effect of temporal envelope
Reversed piano tone completely different timbre no longer sounds like a piano Spectral energy distribution is unchanged by this time reversal temporal envelope changed
Slide 15:Some instruments have noise like qualities that influence their perceived timbre At the start of a flute note Important for the synthesis of a convincing flute sound To create a realistic synthesis of a sound spectral envelope and the variation in time of the components some harmonics may have different time envelopes
Slide 16:Some timbre measures
Spectral centroid related to the subjective brightness of a sound - measures the frequency at which the energy of the sound is centred.
Slide 17:Tristimulus
a measure of tone colour, calculates the proportion of energy in the fundamental, mid and high frequency components Tristimulus1 the amplitude of the first harmonic divided by the sum of all the amplitudes of all the harmonics Tristimulus2 the sum of the amplitudes of the 2-4th harmonics divded by sum of all amplitudes Tristimulus3 sum of amplitdues from the 5th upwards divided by the sum of all the amplitudes
Slide 18:Irregularity
variation in energy between the partials A value close of zero indicates little variation between the amplitudes of adjacent frequency components A value close to 1 large difference in amplitude between adjacent frequency components
Slide 19:Next masking and sound localisation
