Presentation Transcript

  1. importance of Compression Ionit Technologies Understanding the

  2. Analog to digital converter Compression engine Hard disk drive Digital Recording Basics Standard Digital Video Recorder Computer

  3. Video Data Size Size of uncompressed video in gigabytes at 30fps image size of video 640x480 1280x720 320x240 160x120

  4. Compression at work Storage for 1 hour of compressed video in megabytes at 30 fps

  5. What types are there… • JPEG - Joint Photographic Experts Group • Still image compression, intraframe picture technology • Motion JPEG (MJPEG) is sequence of images coded with JPEG • MPEG - Moving Picture Experts Group • Defined by ISO/IEC, several standards MPEG1, MPEG2, MPEG4 and now MPEG4-10/H.264 • H.261/H.263/H.263+ - Videophone/conferencing • Low to medium bit rate, quality. • Ionit: • Intelligent foreground and background algorithm utilizing DSP chip technology. • Designed for video surveillance

  6. Compressed (50)(22 KB, 12:1) Uncompressed(262 KB) Compressed (1)(6 KB, 43:1) Frame to frame technology Each frame taken as a whole, and stripping out the “less important information”, letting your eye fill in the details. Results: “Boxy effect”

  7. What is Dynamic? • Non Dynamic Compression: complete scene The 1st frame is 3 Kbytes; the 2nd Frame is 3 Kbytes; the 3" Frame is 3 Kbytes This stores a total of 9 Kbytes • Dynamic Compression: what’s changing The 1st frame is 3 Kbytes; the 2nd is only 0.6 Kbytes; the 3rd is only 0.6 Kbytes.3Kb + 0.6 KB + 0.6KB = 4.2 Kbytes, important for storage, streaming & processing

  8. No Compression = Big problems Problem: How to store 11,520 hours of video 16 cameras 24/7 recording 15 fps for 30+ days Large file sizes = Increased system & network failure Clearly the need to compress video!

  9. Superior Compression Compression is needed to do the following • Increase System stability Less data= less work • Increase video storage • Lower bandwidth usage & protect the network. • Faster search & retrieval: files are smaller/less taxing on the system ionit MPEG4 MPEG2/ JPEG Real solutions for your customers. Not problems. Compression Ratio

  10. Why Ionit? • STORAGE: MINIMUM of 30 days of 24/7 recording at 640x480 and 240 ips, GUARANTEED! • Why record 24/7? It’s just as important to prove nothing happened as it is to prove something did. • STREAMING: send video over I.T.'s bandwidth, they don’t mind. • STABILITY: less processing, less hardware, less heat = less failure, period. • SERVICE: 3 Year advanced parts warranty.

  11. Products • DVR’s • Embedded solution • Windows Based solution • Cameras: PTZ’s • Accessories, enclosures, UPS’s...

  12. i-Cube • Compact and Affordable • A non-expandable 4, 8, 16 channel recorder that is fully network able.  Typical setup: • Locations looking for simple solution, while allowing for growth with multiple units in remote locations, with remote access via LAN/WAN

  13. Ion • Compact and Affordable • A non-expandable 4 or 8 channel recorder that is fully networkable.  Typical setup: • Multiple units in remote locations, recording continuously with periodic remote access via LAN/WAN Ion-Covert ion

  14. ionitPRO+ • Enterprise solution • 4, 8, 12 or 16 camera solution • Removable/ swappable drives • Industrial/Secure chassis • Typical setup: • One or more units, recording 4-16 cameras continuously with LAN/WAN access to multiple remote users 3U or 4U aluminum chassis

  15. ionitRT • High frame rate and high quality video • A high performance DVR that delivers high frame rate and high quality video. • All removable/ swappable hard drives • Typical setup: • Multiple units with 16 cameras, recording mission critical areas requiring high frame rates. 4U aluminum chassis

  16. i-Server • High frame rate and high quality video, record YEARS of 24/7 video. • A high performance DVR that delivers high frame rate and high quality video. • Custom built to your customers specs. Any RAID level. • Typical setup: • Recording mission critical areas requiring high frame rates. 3U, 4U, 5U, 8U aluminum chassis

  17. Sample browser page

  18. Ionit Technologies Who & where we are • US. Government, Defense, Coast Guard, NASA • Southwest Airlines, Alaska Airlines • Ernst & Young, Fuji Securities, Cole Taylor • General Motors, Ford, US Steel, Corning, Broadcom, Cargill Steel, AK Steel, Wheeling Pit Steel, Mittal Steel, Henkel, Welch’s, Gtech, Kohler, AM General….. • Police Stations, Court Houses, Airports • Education/Universities, hospitals, warehouses, office building, theaters • Public Health facilities, Energy Departments • Restaurants: Preferred product for Subway, C-Stores • Committed to providing state-of-the-art digital video surveillance today and in the future
