  1. NETWORK SECURITY

  2. Public-Key Cryptography and Message Authentication OUTLINE • Approaches to Message Authentication • Secure Hash Functions and HMAC • Public-Key Cryptography Principles • Public-Key Cryptography Algorithms • Digital Signatures • Key Management

  3. What Is Message Authentication • It’s the “source,” of course! • Procedure that allows communicating parties to verify that received messages are authentic（可信的） • Characteristics: • source is authentic – masquerading • contents unaltered – messagemodification • timely sequencing – replay

  4. Approaches to Message Authentication • Authentication Using Conventional Encryption • Assume only sender and receiver share a key • Then a correctly encrypted message should be from the sender • Usually also contains error-detection code, sequence number and time stamp

  5. Message Authentication • Without Encryption • No confidentiality is preferred when: • Same message is broadcast to many destinations • Heavy load and cannot decrypt all messages – some chosen at random • No danger in sending plaintext Append authentication tag to each message

  6. Approaches to Message Authentication • Message Authentication without Message Encryption • An authentication tag is generated and appended to each message－Message Authentication Code (MAC) • MAC is generated by using a secret key • Assumes both parties A,B share common secret key KAB • Code is function of message and key MACM= F(KAB, M) • Message plus code are transmitted

  7. Using Symmetric Ciphers for MACs • can use cipher block chaining mode and use final block as a MAC密码分组链接模式中最后一组输出作为MAC码 • Data Authentication Algorithm (DAA) is a widely used MAC based on DES-CBC • using IV=0 and zero-pad of final block • encrypt message using DES in CBC mode • and send just the final block as the MAC • or the leftmost M bits (16≤M≤64) of final block

  8. Data Authentication Algorithm (DAA)

  9. One-way HASH function • Alternative to Message Authentication Code • Accepts a variable size message M as input and produces a fixed-size message digest H (M) as output

  10. One-way HASH function

  11. One Way Hash Function Ideally We Would Like To Avoid Encryption • Encryption software is slow • Encryption hardware costs aren’t cheap • Hardware optimized toward large data sizes • Algorithms covered by patents（专利） • Algorithms subject to exportcontrol

  12. One-way HASH function • Secret value is added before the hash and removed before transmission.

  13. Secure HASH Functions • Purpose of the HASH function is to produce a “fingerprint”. • Properties of a HASH function H : • H can be applied to a block of data at any size • H produces a fixed length output • H(x) is easy to compute for any given x. • For any given block h, it is computationally infeasible to find x such that H(x) = h • For any given block x, it is computationally infeasible to find with H(y) = H(x). • It is computationally infeasible to find any pair (x, y) such that H(x) = H(y)

  14. 每一位产生一个简单的奇偶校验 Simple Hash Function • General principle • Input is a sequence of n-bit blocks • Input is processed one block at a time to produce an n-bit hash function • A simple example is the bit-by-bit XOR of each block Ci = bi1 ⊕bi2⊕ … ⊕bim Ci is ith bit of hash code 1 <= i <= n m is number of n-bit block in input bij is ith bit in jth block ⊕ is the XOR operation

  15. SHA-1 Secure Hash Function • The Secure Hash Algorithm( SHA) was developed by the National Institute of Standards and Technology and published in 1993. SHA-1 is 1995 revised version (修订版). • It takes as input a message with maximum length < 264 bits and produces a 160-bit message digest. • It is processed in 512-bit blocks.

  16. SHA-1 Secure Hash Function K

  17. SHA-1 Processing of single 512-Bit Block

  18. SHA-1 － Kt

  19. SHA-1 －Creation of 80-word Wt=(Wt-16Wt-14 Wt-8 Wt-3) <<1

  20. Other Secure HASH functions

  21. Public-Key Cryptography Principles • The use of two keys has consequences in: key distribution, confidentiality and authentication. • The scheme has six ingredients (see Figure 3.7) • Plaintext • Encryption algorithm • Public and private key • Ciphertext • Decryption algorithm

  22. Encryption using Public-Key system Encryption

  23. Authentication usingPublic-Key System Authentication

  24. Applications for Public-Key Cryptosystems • Three categories: • Encryption/decryption: The sender encrypts a message with the recipient’s public key. • Digital signature: The sender ”signs” a message with its private key. • Key echange: Two sides cooperate two exhange a session key.

  25. Public-Key Cryptographic Algorithms • RSA - Ron Rives, Adi Shamir and Len Adleman at MIT, in 1977. • RSA is a block cipher • The most widely implemented • based on exponentiation求幂in a finite field over integers modulo a prime • uses large integers (eg. 1024 bits) • security due to cost of factoring large numbers 安全性是基于对大数的分解是非常困难的

  26. Prime and Composite Numbers • An integer p is prime if its divisors are 1 and p only.P是素数当且仅当它只有因子1 和 p • Otherwise, it is a composite number. • E.g. 2,3,5,7 are prime; 4,6,8,9,10 are not • List of prime number less than 200: 2 3 5 7 11 13 17 19 23 29 31 37 41 43 47 53 59 61 67 71 73 79 83 89 97 101 103 107 109 113 127 131 137 139 149 151 157 163 167 173 179 181 191 193 197 199

  27. Prime Factorization (因数分解) • To factor a number n is to write it as a product of other numbers: n = a × b × c • The prime factorization of a number n is when it is written as a product of primes • E.g. 91=7×13; 3600=24×32×52 • It is generally hard to do (prime) factorization when the number is large • E.g. factorize 93874093217498173983210748123487143249761

  28. Relatively Prime Numbers & GCD • two numbers a, b are relatively prime互素if have no common divisors公因子apart from 1 • eg. 8 & 15 are relatively prime since factors of 8 are 1,2,4,8 and of 15 are 1,3,5,15 and 1 is the only common factor • conversely can determine the GCD(greatest common divisor) by comparing their prime factorizations and using least powers • eg. 300=21×31×52 18=21×32hence GCD(18,300)=21×31×50=6

  29. The Euler phi Function For n  1, let (n) denote the number of integers in the interval [1, n] which are relatively prime to n. The function  is called the Euler phi function (or the Euler totient function). Fact 1. The Euler phi function is multiplicative. I.e. if gcd(m, n) = 1, then (mn) = (m) x (n). E.g. 91=7×13 (7) =6 (13)=12 (91) = (7) × (13) =6×12＝72

  30. Euler's Theorem • Euler’s Theorem • Let n be a composite. Then b(n) ＝1 (mod n) for any integer b which is relatively prime to n. • E.g. b=3; n=10; (10)=4  34 ＝81 ＝1 (mod 10) • E.g. b=2; n=11; (11)=10  210 ＝1024 ＝1 (mod 11)

  31. RSA Key Generation each user generates a public/private key pair by: • selecting two large primes at random p, q • computing their system modulus N=p.q • note φ(N)=(p-1)(q-1) • selecting at random the encryption key e • where 1<e<φ(N), gcd(e,φ(N))=1 • solve following equation to find decryption key d • e.d=1 mod φ(N) and 0≤d≤N • publish their public encryption key: KU={e,N} • keep secret private decryption key: KR={d,N}

  32. Example of RSA Algorithm

  33. RSA Example • Select primes: p=17 & q=11 Compute n = pq= 187 • Compute φ(n)=(p–1)(q-1)=16×10=160 • Select e : gcd(e,160)=1; choose e=7 • Determine d: de=1 mod 160 and d < 160 Value is d=23 since 23×7=161= 10×160+1 • public key KU=(7,187) private key KR=(23,187) • given message M = 88 ( 88<187) • encryption: C = 887 mod 187 = 11 • decryption: M = 1123 mod 187 = 88

  34. Why RSA Works P & Q PRIME N = PQ ED = 1 MOD (P-1)(Q-1) C = ME MOD N M = CD MOD N because of Euler's Theorem: • aφ(n)mod N = 1 • where gcd(a,N)=1 • in RSA have: • N=p×q • φ(N)=(p-1)(q-1) • carefully chosen e & d to be e×d=1 mod φ(N) • hence e×d=1+k×φ(N) for some k • hence :Cd = (Me)d = M1+k×φ(N) = M1×(Mφ(N))k = M1×(1)k = M1 = M mod N

  35. Why RSA Works • This is true if M is relatively prime to N • (according to Euler’s Generalization). • What if M is not relatively prime to N?

  36. The Last Step of RSA Correctness Proof P & Q PRIME N = PQ ED = 1 MOD (P-1)(Q-1) C = ME MOD N M = CD MOD N • If gcd(M, N)  1, then M and N share either P or Q as a prime factor. • Not both because M < N and P and Q are the only prime factors of N. • To Show: Mk(N)+1 ＝ M (mod N) • Case 1: Let’s look at p as a factor of M: M=cP. • M(Q) = 1 (mod Q) as gcd(M, Q) = 1. • Raise both sides to kφ(P), [M(Q)]k(P) = Mk(N) =1 (mod Q) • Mk(N) = 1 + iQ for some integer i. • Since M = cP, MMk(N) = M(1 + iQ) = M+cPiQ=M + ciN • Hence Mk(N)+1 = M (mod N) • Case 2: Without loss of generality, this holds for M=cQ.

  37. HMAC • Use a MAC derived from a cryptographic hash code, such as SHA-1. • Motivations: • Cryptographic hash functions executes faster in software than encryptoin algorithms such as DES • Library code for cryptographic hash functions is widely available • No export restrictions from the US

  38. HMAC Structure

  39. Diffie-Hellman Algorithm • First introduced by Diffie-Hellman in 1976 • Mathematical functions rather than simple operations on bit patterns • Allows two separate keys • Exchange keys securely • Compute discrete logarithms

  40. DH details • i.e. if a is a primitive root（本原根）of prime p, • a mod p, a2 mod p, … ,ap-1 mod p are distinct and contain 1 through (p-1) in some order. • Compute the primitive rootof prime 7 3 mod 7=3, 32 mod 7=2, 33 mod 7=6 , 34 mod 7=4, 35 mod 7=5, 36 mod 7=1

  41. DH details continued… • For b less than p and a, find unique exponent i such that b = ai mod p 0 ≤ i ≤ (p-1)i is the discrete logarithm （离散对数） • Denoted inda,p(b), it is hard to calculate given ai mod p (=b)

  42. Diffie-Hellman basics a, p Pick secret, random XB Pick secret, random XA YA= aXAmod p YB= aXBmod p Alice Bob Compute k =(YB)XAmod p =(aXB mod p)XAmod p = (aXB)XAmod p = aXBXA mod p= (aXA) XB mod p = (aXA mod p) XB mod p=(YA) XB mod p

  43. Diffie-Hellman Key Echange

  44. Diffie-Hellman Key Echange • The security of the Diffie-Hellman key exchange lies in the fact that, while it is relatively easy to calculate exponentials modulo a prime, it is very difficult to calculate discrete logarithms, the latter task is considered infeasible. • 公开a , p , YA, YB , 计算XA=inda,p(YA) , XB=inda,p(YB) 是不可行的。

  45. Diffie-Hellman Key Echange • ExampleP=71 a＝7 XA=5 XB=12YA=75mod71＝51 YB=712mod71＝4A: K=(YB)XAmod71=45mod71＝30B: K=(YA)XBmod71＝5112mod71=30

  46. Other Public-Key Cryptographic Algorithms • Digital Signature Standard (DSS) • Makes use of the SHA-1 • Not for encryption or key echange • Elliptic-Curve Cryptography (ECC) • Good for smaller bit size • Low confidence level, compared with RSA • Very complex

  47. Digital signatures • A digital signature is an encryption of a document with the creator’s private key • It is attached to a document that validates the creator of the document • Any one can validate it by decrypting the signature with the claimed creator’s public key

  48. Digital signatures on hashes • A more efficient way for a digital signature is by creating an authenticator of the document first (a hash) • Then sign the hash (i.e. encrypt the hash using private key) • If M is the message (or document), Hash(M) = H • sigPV(A)(H) represents sigining H • i.e. encrypting H with A’s private key

  49. Digital Signatures: The basic idea public key ? public key private key Alice Bob
