  1. Trigger Querying Orna Kupferman Yoad Lustig

  2. ? Motivation

  3. Model exploration • In model exploration, the objective is to explore and understand the model. • Contrast this with model checking, in which the objective is to verify that the model satisfies the specification. • Model exploration was formalized as a problem by Chan (CAV 2000) who introduced query checking.

  4. Query Checking • Query checking is based on CTL. • In CTL model checking we get a Kripke structure M and a formula, say AG[ p ], and ask whether M ² AG[ p ]. • In query checking, a Boolean subformula is replaced by “?”, and one may ask M ²AG[?]. • The solution is the “strongest” Boolean expression that can replace the “?”.

  5. Query Checking - shortcoming • In query checking we search for a Boolean expression (that can replace the “?”). • A Boolean expression is evaluated at a state, and therefore refers to one point in time. • No temporal dynamics. • The user is usually interested in scenarios. • Example: what scenarios lead to the calling of the function.

  6. Triggers semantics • We use the temporal operator triggers (a.k.a. suffix implication) to describe scenarios. • M ² r triggers means:for every computation  of M and index i,If [1..i]2 L(r) then i2 L(). i  [1..i] i

  7. p Triggers semantics - example • In this model • Does M ² p¢q triggers next p • ALL computations inducing p¢q must be considered. • Does M ² p¢p triggers next q q p q p p,q q ? ?

  8. Trigger Querying - Definition • In the trigger query M ² ? triggers we ask which words trigger , orwhat is { u2* | M ² u triggers  }? • The solution is the set of scenarios that trigger . • The solution is guaranteed to be a regular set, and can be represented as a regular expression or a DFA.

  9. q2 q1 q3 q8 q4 q4 q1 q0 q7 q1 q8 q7 q5 q2 q5 q7  w Trigger Querying technical characterization • Trigger querying: do all paths that induce a word does (w) µ []M? are followed by ? (w) []M []M : states from which all paths satisfy . (w) : states a computation inducing w might end in.

  10. Trigger Querying branching-time view • M ² u triggers  iff (u) µ []M. • In other words, the query is about states (rather than infinite words / computations). • M ² w triggers is equivalent toM ² A[ w triggers  ]and toM ² A[ w triggers A[  ] ].

  11. Solving Trigger Querying • The problem of identifying the set []M is the well studied problem of global model checking. • The problem of computing (u) is easily solvable by a type of subset construction on the states of M. • Construct a DFA AM, with state space 2Q, such that AM visits state (u) after reading u, and the accepting states of AM are sets contained in []M.

  12. Complexity of Trigger Querying • Computing both []M and AM can be done in PSPACE. • For []M, the dependency on || is polyspace, but the dependency on |M| (structure complexity) is only polytime. • For AM, however, the dependency on M is also polyspace. Unfortunately, this is unavoidable.

  13. w Complexity of Trigger Querying - lower bound idea. • Trigger querying: do all paths that induce a word • NFA complementation: do all runs on a word end in some set? are followed by ? end in some set? []M

  14. Variants of trigger querying • Partial trigger querying. • Relevant trigger querying. • Constrained trigger querying. • Observable trigger querying. • Search for necessary conditions.

  15. Partial Trigger Querying • Motivation: trying to overcome high complexity demands. • In partial trigger querying, we search for a subset of the solution to M ² ? triggers that is not empty unless so is the solution. • Simplest case: find a single word, of length bounded by a unary parameter, that trigger . This case is NP hard.

  16. [1..i] i Relevant Trigger Querying M ² r triggers  means: 8 computation  8 i≥0 If[1..i]2 L(r) theni2 L(). • Words that are not a prefix of any computation are solutions to M ² r triggers . • In relevant trigger querying we do not accept such vacuous solutions. • Technical solution: remove ; from AM’s set of accepting states.

  17. Constrained Trigger Querying • Sometimes a user would like to have a dialog with the query-checking tool. • Example: • What are the solutions in which the signal xis initially 0? Solutions in which x is initially 0 but then turns to 1? • In constrained trigger querying the user provides a query as well as a constraint; the solution set is intersected with the constraint.

  18. Observable trigger querying • Sometimes a user would like to see solutions that refer only to a subset of “observable” signals. • Examples: • A user that doesn’t want to hear about internal signals used in the implementation. • A user that want to know if there is a way to control input signal x that will force the system to behave in some way.

  19. Necessary conditions • When M ² r triggers , the language of r can be seen as a sufficient reason for . • If a word from L(r) “happens” then  will inevitably “happen”. • What about necessary conditions? • Informally: what “event” always precedes ?

  20. Necessary conditions (cont’)  • 8 computation  8 i≥0 If i2 L() then [1..i]2 L(r) . • No unique solution. In fact, * is always a solution. • A solution r1 is stronger than r2 iff L(r1)µ L(r2). • A unique stronger solution exists. [1..i] i

  21. Necessary conditions - technical • Similar technical details: • Set G = { s | Ms ² : }. • Necessary condition is { u2* | (u)Å G ; }. • The complexity is polynomial space in ||, but only nondeterministic logspace in |M|.

  22. Queries? A query A trigger(fish)
