Multicast In Wireless Mobile Environments

1. Multicast In Wireless Mobile Environments Reporter:江俊毅

2. Introduction • Wireless Network Categories • Multicasting for wireless mobile hosts in an IP network is a challenging task • We first introduce the issues involved in providing multicast in a mobile environment • Discuss details of proposed multicast routing protocols

3. Wireless Network Categories • Infrastructure Wireless: base station network is connected to the wired Internet. • Ad hoc Wireless: wireless nodes communicate directly with one another.

4. Wireless LANs (b)Ad hoc Wireless (a)Infrastructure Wireless

5. Issues In Mobile Environments • Multicast Forwarding Algorithm • A source-based protocol like DVMRP ,DVMRP forwards multicast packets only if it receives them on the correct interface • when mobile host (MH) moves to a new domain , its interface to the multicast router changes , resulting in the packets being dropped

6. Issues In Mobile Environments • Dense or Sparse Model Protocol • The dense mode protocols are useful if there are a lot of users and bandwidth availabilitiy is not a problem, whereas sparse mode protocols are meant for widely distributed users with limited bandwidth.

7. Issues In Mobile Environments • Qos Provisioning • Quality of service (QoS)-based wireless multicasting is an open issue • In this section we first describe Mobile-IP based multicasting protocols

8. Proposals for Multicast over MIP • Remote Subscription • In remote subscription an MH resubscribes to the multicast group each time it moves to a new foreign network. • It is the simplest way of providing multicast through Mobile IP.

9. Remote Subscription

10. Out-of-synch problem

11. Proposals for Multicast over MIP • Bidirectional Tunneling • In this scheme MHs send and receive multicast packets by way of their home agents (HAs), using unicast Mobile IP tunnels from their HAs.

12. Bidirectional Tunneling

13. Tunnel convergence

14. Multicast support using Mobile IP • Multicast support using Mobile IP (MoM) • MoM is based on bidirectional tunneling • MoM selected HA among the given set of HA is called designated multicast service provider (DMSP)

15. MoM

16. DMSP select • Classify • 1.Agent based • 2.Count-based • 3.Proximity-based • 4.Random-based

17. RBMoM • Range-Based Mobile Multicast (RBMoM) • RBMoM provides a trade-off between the shortest delivery path and the frequency of multicast tree reconfiguration • It selects a router called a multicast HA(MHA) • Every MH can have only one MHA • MHA(Multicast HA) is responsible for tunneling multicast data to foreign networks

18. Select the new MHA

19. Proposals for Multicast over MIP • Multicast for Mobility Protocols (MMP) • MMP uses a sparse mode multicast routing protocol Core Base Trees (CBT) to handle the movement of mobile nodes within a foreign network. • This scheme uses a shared-tree, to and from a centre point called the core of the network. • MMP relies on Mobile IP Agent Discovery procedure in order for mobile hosts to discover relevant Mobility Agents and obtain a multicast care-of-address.

20. MMP 1.BS transmit periodic beacons with Agent Advertisement messages 2.MN transmits a Registration Request to the base station 3.BS will send a Join request to the Core and create a permanent group 4.MN moves to another cell, it will initiate handoff when it receives a stronger beacon

21. MobiCast • MobiCast is designed for an internetwork environment with small wireless cells, with many cells grouped together and served by domain FAs (DFAs).

22. Y Y Y 4.X-> DFA-> Y-> all AP MobiCast WHEN MN JOIN GLOUP X 1.MN send IGMP message to DFA 2.DFA instead MN join X 3. Construct multicast group Y and MN join group Y

23. Reliable Wireless Multicast Protocols • Reliable Multicast Data Distribution Protocol (RMDP): • Uses Forward Error Correction (FEC) and Automatic Retransmission reQuest (ARQ) information to provide reliable transfer. Redundant information is inserted into the FEC, often enabling a receiver to reconstruct the original packet. • In the event that such information is not enough, an ARQ is sent to the multicast source which in turn, multicasts the requested packet to all receivers.

24. Reliable Wireless Multicast Protocols • RM2 • RM2 is a reliable multicast protocol that can be used for both wired and wireless environments. • RM2 is a hierarchical protocol that divides a multicast tree into subtrees where subcasting within these smaller regions is applied using a tree of retransmission servers (RSs)

25. Reliable Wireless Multicast Protocols • RS having a retransmission subcast address shared by its members and which may be dynamically configured using the IETF’s Multicast Address Dynamic Client Allocation Protocol (MADCAP). • The receivers are required to send negative acknowledgments (NACKs), pointing out the packets to be retransmitted.

26. RM2

27. compare

28. Conclusion • This article is an attempt to give an overview of current research in wired and wireless multicast field and show that this area is rapidly growing and evolving. • Future directions in wireless multicast need to consider QoS, security, and so on. • Furthermore , a detailed investigation is desirable for both unreliable and reliable environments.

29. END • THANK YOU!
