1. Software Pipelining in Pegasus/CASH Cody Hartwig Elie Krevat {chartwig,ekrevat}@cs.cmu.edu

2. Software Pipelining • Software pipelining is a method for increasing the available parallelism for instruction scheduling • Data dependencies limit the opportunity for parallel execution • Software pipelining can overlap loop iterations to increase available operations to schedule between dependencies • Many techniques exist [classification by Allan et al.] • Kernel recognition (e.g., Aiken & Nicolau) • Assumes schedule for iterations are fixed, loop is unrolled n times • Pattern recognition identifies a repeating kernel • Modulo scheduling • Analysis of data dependencies (resource/precedence constraints) • Finds minimum initiation interval to use when scheduling

3. Software Pipelining in Pegasus/CASH • Pegasus is an intermediate representation used by the CASH compiler • Pegasus graph models control-flow and data-flow • Our Approach: Apply optimizations to the Pegasus graph, not the generated assembly • Abstracts away resource constraints • Feedback loop possible after scheduler and register allocation (e.g., to implement less aggressive pipelining because of register spilling)

4. How Operations are Pipelined • Our approach computes operation outputs for future loop iterations in the current iteration • Operations are copied into pre-header and the data-flow for values before and after executing that operation are fed into the loop hyperblock • Then each loop iteration uses the value of the operation already computed, and computes the operation value for the next iteration • This approach is analogous to preparing temporary variables of future iterations to make the loop body schedule more efficient

5. Choosing Operations to Pipeline via Pattern Matching • An operation may be pipelined if it matches a number of possible patterns • Patterns depend only on the type of operation and the source of its inputs • Operation type must allow speculative execution (e.g., loads are ok, but not stores) • Operations on the most expensive paths to etas are the first ones moved • The most expensive path is not necessarily the longest (e.g., a single ‘load’ operation is more expensive than two ‘add’ operations)

6. Recognized Patterns Arithmetic Operation Load Operation Cast Operation As operations are moved, new operations will form the recognized patterns

7. Example int i = 0; char a[100]; while(i < 100) { char tmp = a[i]; tmp = tmp * 2; a[i] = tmp; i++; } The load and store are forced to execute in series Operations in red are available to move

8. Step 1 Step 2 Load and store are no longer dependent!

9. Evaluation – Moving Average void move_avg(int *a) { int i = 1; while (i < l00) { int t1 = a[i]; int t2 = a[i-1]; a[i] = (t1+t2)/2; i++; } } Cost of entire function ≈ Cost(Pre-header) + 100*Cost(Loop Body) Cost before Software Pipelining ≈ 2208 Cost after Software Pipelining ≈ 1814 Software Pipelining improves performance here by ≈ 18%

10. Moving Average – Before Software Pipelining

11. Moving Average – After Software Pipelining Pipelined graphs are considerably more complex

12. Conclusion • Software pipelining at the Pegasus level can achieve significant loop improvement • Most regular operation types are pipelinable via our iterative pattern matching algorithm • Cost of improvement is increased register pressure & more complicated Pegasus graphs
