  1. Wakefield effect 20130708 K.Kubo

  2. Transverse, dipole Wakefield Wakepotentialis integral of wakefunction for point charge x charge distribution Wake for point charge For very long bunch, compared with size of wake source, Wakepotential is almost resistive. For very short bunch, Wakepotential is capacitive z=0 ~ size of structure

  3. Transverse, dipole Wakefield Particle at position z change transverse momentum as Ignoring y difference along bunch (bunch shape distortion) Kick angle

  4. For 7 mm Gaussian bunch Calc. by A. Lyapin

  5. Effect of wake • Average kick • Orbit change kick angle of center of mass • Particles at different z are kicked differently. Induce z-correlated transverse motion. • Beam size increase Spread of kick angle

  6. Resulted particle position distribution at IP (~Projection of wakepotential) Wakepotential

  7. Effect of single wake source • Center of mass position change • Beam size increase Average of wake potential Spread of wake potential

  8. Wake potential Effect of single wake source at the mover, beta=6260 m, offset 1 mm, bunch charge 1 nC.

  9. IP beam size vs. mover position experiment Effect of offset 1 mm, bunch charge 1 nC. IP beam size increase (nm/nC/mm) Experimental data analyzed by Okugi 1 ref.cav. : 157-102=55 2 no mask def bellows: 102-55= 47 Assume 2 masked deforming bellows = 1 masked bellows 1 masked bellows: 14.5/2=7 1 no mask def bellows: 57-7=50 2 no mask deforming bellows ~ 1 no mask bellows

  10. IP beam size vs mover position experiment and calc. Effect of wake source at the mover, offset 1 mm, bunch charge 1 nC. IP beam size increase (nm/mm/nC) More discussion later by Jochem

  11. Effect of many wake sources • Can be estimated by adding effect of each source. • Depend on sinf but almost +1 or -1 for all structures in large beta region • Random misalignment • Effects are random • Proportional to sqrt(beta) • Orbit deviation: • Effect of every source is added with the same phase. • Proportional to beta. • Depend on phase of orbit

  12. beam size increase by random misalignment mean 77 mean 160 Experiment: ~120 nm/ nC(?) No clear improvement after mask bellows . (?)  random misalignment 1.3 mm and 0.6 mm. For bellows, 1 mm does not seem too large. But they were shielded in May-June. mover position was optimized in most cases (fixed offset was compensated?).

  13. Wake of fixed offset can be corrected by on-mover wake source at other place (If shape of wake potential is same). Phase advance p/2 kick Phase advance p/2 Phase advance p/2 Phase advance p/2

  14. Simulation of beam size increase by orbit distortion Orbit of angle-at-IP phase Experiment: ~120 nm/ nC(from IPBSM 30 deg mode measurements For explaining by orbit, need orbit distortion >2-sigma of nominal (no bellows), ~1 sigma (with bellows) (if assuming calculated wakepotentials)

  15. Simulation of beam size increase by orbit distortion Orbit of position-at-IP. Orbit of position-at-IP does not induce significant wakefieldeffect.

  16. Summary of this talk • Experiments of on-mover wake source • Suggested larger wake than calculation • Factor 1.7 for C-band reference cavity • Factor 2 for no mask bellows • Wake of masked bellows was about 1/7 times of no mask bellows • Beam size dependence on intensity ~120 nm/nC • Wake of cavity BPM, bellows or wake of similar shape cannot explain observations • Orbit distortion 1-sigma of y at IP phase may explain, assuming wake of cavity BPM + 2 bellows at every cavity BPMs (Much larger than expected from calculation with most of bellows are masked.) • Other wake sources with much different wakepotential shape???? • More discussions by Jochem.
