  1. GUARDIAN General User Alert Display Panel Training Booster for General UsersTom FiliaggiLate Winter, 2009

  2. Agenda • Operational Concept • Basic Components • Message components • Message Responses • Graphical User Interfaces • Popup GUI • Main GUI • Configuration GUI • What you can do • Configuration Summary • Script and command line usage • What you cannot do • Forced Responses

  3. Operational Concept • Guardian auto-starts upon login to the AWIPS LX and XT machine desktops • Guardian’s presence is persistent and unobtrusive (depending on desktop configuration) • Various AWIPS Software sends various messages to Guardian, using standard AWIPS Inter-process Communication methods • Guardian responds, based on message attributes sent and current response configuration • The configuration has a machine default, but can be customized • By each individual user • By Task • The customization can control many aspects of Guardian’s responses

  4. Basic Components:Message Components • Textof Message • Text composed by the sender application • Sourceof Message • Sender application • Must be defined in Guardian • Priorityof Message • Determined by sender application • The goal is to have both the sender and receiver define Priorities the same. This is impossible, but the closer we get, the more mutual understanding we have. • Categoryof Message • Determined by sender application • Determines Text Section • Some special Categories: • LOCAL Response only for one machine • MONITOR Response targeted to a Monitor Button • GDN_ADMIN Internally used by Guardian for administrative purposes • Optional: Machine specific • Can send a message to a single, specified machine.

  5. Basic Components:Message Responses • Text • In Text Sections of GUI • Configurable Text Section Layout • Background and foreground colors • Blink: user defined duration • Pop-up • Sometimes called “red-banners” (but they don’t have to be red anymore) • Background and foreground colors • Image: ie: gif, bitmap (default is Guardian logo) • Small vs. large pop-up • Audio • System beep • Specified sound file • User defined repetition duration • Action • Launch an executable (with standard AWIPS environment)

  6. Basic Components:User Interfaces Main GUI Config GUI Pop-up GUI

  7. Graphical User Interfaces:Pop-up GUI • Pop-up size* • Normal • expanded • Textof Message • May contain * • Source • Priority • Category • Log will show details • Time-stamp • Image* • Default is Guardian logo • Taking cursor focus • This is controlled by the desktop. KDE mouse control should be set to: • Focus Under Mouse OR • Focus Strictly Under Mouse • Acknowledgement • Last message • All # (with confirmation) * = configurable

  8. Graphical User Interfaces:Main GUI

  9. Graphical User Interfaces:Config GUI

  10. What You Can Do: Summary • Almost all of Guardian’s responses are under your control: • Text: blink, colors, include message attributes, targeted Text Section of Main GUI • Pop-up: colors, size, embedded image, include message attributes • Audio: duration, default system beep, custom audio file • Action: anything in the environment’s command path • But these responses are predicated upon the message attributes sent from the client applications: • Priority • Source • Category • Some limitations: • Both software developers and Guardian users need to have the same definitions of the Priorities to help with more useful configurations • The old ANNOUNCER is still only one Source in Guardian, though it should be eliminated to allow all of its client applications to become Guardian clients instead. Thus, the ANNOUNCER is a sort of bottleneck. • The full suite of Guardian capabilities has yet to be realized in operations. Task-based configurations would likely be impossible until the ANNOUNCER is removed

  11. What You Can Do: Local Apps • Currently, the biggest strength of Guardian is to allow the WFOs to set up your own messages and responses • Examples: NIMNAT, Meso alarms, text triggers, forecast reminders • Can create your own Sources and Categories, if need be • Command line, to send a message to Guardian: • sendMsgToGuardian source priority category “text” (local machine) • local machine is optional, do not use parentheses • text should be encapsulated in quotes • source and category must be defined in Guardian • priority must have an integer value from 0 to 5 • Usage in a script, must have the proper AWIPS environment defined. Here is an example of defining the proper environment in a tcsh script: • #!/bin/tcsh • setenv FXA_HOME /awips/fxa • source $FXA_HOME/bin/readenv.csh • $FXA_HOME/bin/sendMsgToGuardian args

  12. What You Cannot Do • Forced Responses • There are some situations where your current Guardian configuration can be overridden. • Those in your office with ‘fxa’ access can define Forced Responses in Guardian. • This can be applied to all potential responses to a given message, or only a few (or one) • Details for overriding are on the GUARDIAN web page, though general users will not need to know the details

  13. What You Cannot Do • The sender of the message cannot dictate a response. The response is under the control of the receiver. • ie: The sender cannot dictate that a certain sound file gets played • ie: The sender cannot dictate that a pop-up gets presented • etc • You cannot turn Guardian completely off (though you can configure it to have no responses at all, but this is not recommended). • You cannot minimize the Main GUI nor lower it in the window stack order.

  14. Guardian Responsible Individuals • Main Developers • Tom Filiaggi - MDL: Lead Tom.Filiaggi@noaa.gov

  15. High Level Data Flow

  16. Forced Responses • If the following file does not exist, create it • cd /data/fxa/workFiles/Guardian • touch GuardianForced.txt • chmod 644 GuardianForced.txt • Entries in the file should look like this: • SourceKey | Priority# | Category | simple_text_match | SettingsList • All pipes are required, whether they contain any text or not • SourceKey and Priority# are required • simple_text_string does not represent a ‘regular expression’ and should not be encapsulated in quotes • SettingsList is one or more configuration settings, separated by commas, with the following format: • attribute:value • Examples • popup:1,background:yellow,text:0 • Full details are available on the Guardian web page in the document “System Manager Overrides” SourceKey | Priority# | Category | simple_text_match | SettingsList
