DNA Structure and Replication

DNA Structure and Replication. Lifespan Gene In The News. Chromosomes . Contain all information for an organism Karyotype = arrangement of chromosomes. Eukaryotic Chromosomes. Chromatin = DNA Histone proteins condenses to form strands called chromosomes,

navid
Télécharger la présentation

DNA Structure and Replication

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. DNA Structure and Replication

  2. Lifespan GeneIn The News

  3. Chromosomes • Contain all information for an organism • Karyotype = arrangement of chromosomes

  4. Eukaryotic Chromosomes • Chromatin = • DNA • Histone proteins • condenses to form strands called chromosomes, • Strands occur just prior and during cell division

  5. DNA • Double stranded, coiled molecule

  6. Discovery of Hereditary Material • Friedrich Miescher (1869) • Isolates “nuclein” from nucleus • was not called DNA until the 1920’s • No notion it contained hereditary material • Gregor Mendel (late 1800s) • Pioneering work in genetics • Traits are inherited discrete factors

  7. Discovery of Hereditary Material • Walter Sutton (early 1900s) • Suggested chromosomes held hereditary factors • No direct evidence for support • Thomas Hunt Morgan (1910) • Provided experimental evidence to support Sutton • Identified X (sex) hormone • worked with chromosomes of fruit flies and eye color

  8. Discovery of Hereditary Material • Phoebus Levene (1920s) • Two types of nucleic acid in cells, composed of repeating nucleotides • Both types with nearly identical structures • DNA & RNA are the 2 types

  9. Nucleotide Structure • Three different components • Phosphate group • Nitrogen containing base (A,T,G,C,U) • Five-carbon sugar (ribose or deoxyribose)

  10. Nitrogen Containing Bases

  11. Discovery of Hereditary Material • Oswald Avery (early 1940s) • Preliminary evidence for DNA as hereditary material • Transformed bacteria by transferring DNA

  12. Discovery of Hereditary Material • Edwin Chargaff (late 1940s) • Proportion of bases varies in the DNA of different type organisms • Portions of bases roughly equal, (A=T & C =G) • Purines = pyrimidines (A + G = C + T)

  13. Discovery of Hereditary Material • George Beadle & Edward Tatum (1950s) • One-gene-one-enzyme theory • Enzyme production under control of genes • Alfred Hershey & Martha Chase (1952) • Building of Avery’s work, confirmed DNA as hereditary material

  14. Discovery of Hereditary Material • Rosalind Franklin & Maurice Wilkins (1953) • Developed double helix model for DNA • Evidence from X-ray diffraction

  15. Discovery of Hereditary Material • James Watson & Francis Crick (1953) • Structure of DNA • Synthesized previous research • Nobel Prize in 1962, along with Wilkins, Franklin died before nominations were made

  16. Structure of DNA

  17. Discovery of Genetic Code

  18. DNA is Self-Replicating • Before Cells divide • Enzymes break bonds between bases • Complementary strands separate • Complementary bases are added to strands • Copy of DNA results

  19. Replication Mechanisms • Replication begins at various points • Proceeds in both directions

  20. Replication Mechanisms • DNA molecule separates at its bases • Forms split, or replication fork • Each strand acts as a template

  21. Replication Mechanisms • Replication proceeds from 5‘ to 3‘ end

  22. Genes • One-gene-one-enzyme theory • Production of a given enzyme is under control of a specific gene • Production of a given peptide is under control of a single gene (revised statement)

  23. Gene • The unit of heredity • Is a sequence of nucleotides • Codes for amino acid sequences of polypeptides or for RNA

  24. DNA Sequences • Genome = all genetic information • Promoters = “start here” part of sequence • Introns = extra sequences between polypeptide-specifying portions, are not expressed, interrupt most eukaryotic genes • Exons = portions of a gene that are expressed

  25. Repeated Sequences • Repetitive DNA • 20-50% of eukaryotic DNA • May play structural roles in chromosomes

  26. Repeated Sequences • Telomeres • At ends of chromosomes • Shorten as cell replicates • Cells do not function when telomeres become too short Telomeres in yellow

  27. Mutations • Change can occur in DNA • Point mutation or gene mutation • Change in genetic message • Chromosome mutation

  28. Sources of Mutation • Ionizing radiation • Ultraviolet radiation • Some chemicals • Transposable elements

  29. Transposable Elements • “jumping genes” • Some DNA sequences move from one position to another • Make up more than 40% of human genome • First reported by Barbara McClintock

  30. Transposable Elements • Significance • Contribute to rate of mutation • May cause visible changes • Example: mottling in corn

  31. End Chapter 9
