Overlapping Orders. Any equivalent m l combinations will share b values. For Example: 1 st Order = 400 nm 2 nd Order = 200 nm 3 rd Order = 133 nm. d(sin a + sin b ) = m . Calculate the free spectral range: Dl f = l /(m+1).

Télécharger la présentation
## Overlapping Orders

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**Overlapping Orders**Any equivalent ml combinations will share b values. For Example: 1st Order = 400 nm 2nd Order = 200 nm 3rd Order = 133 nm d(sin a + sin b) = m Calculate the free spectral range: Dlf = l/(m+1) Douglas A. Skoog and James J. Leary, Principles of Instrumental Analysis, Saunders College Publishing, Fort Worth, 1992.**Blaze Angle (g)**Intensity is highest when b matches the angle of specular reflection. Gratings: often characterized by angular dispersion (Da) 0th order the angular separation corresponding to a wavelength separation Eugene Hecht, Optics, Addison-Wesley, Reading, MA, 1998.**Blaze Angle ()**Blazed gratings direct most of the light towards a higher order band. Optimum Intensity: b = 2 Blaze Wavelength (b): b = dsin2 Efficiency drops to ~50% at 2/3 b and 3/2 b. Ingle and Crouch, Spectrochemical Analysis**Czerny – Turner Monochromator**Slits: determine resolution and throughput Monochromators: often characterized by linear dispersion (Dl) – dx/dl Rd: Reciprocal Dl Ingle and Crouch, Spectrochemical Analysis**Can change angle of grating to focus different on the**exit slit. Take-off angle () is constant. Change q to direct different towards F = a + = b - m = 2 d sincos Ingle and Crouch, Spectrochemical Analysis**Are you getting the concept?**In our monochromator, we have a grating with d = 833.33 nm operating in first order with f fixed at 6.71°. At what angles (q) must the grating be positioned in order to select l = 300 nm or 500 nm? What incident angle (a) is achieved for each l in order to perform wavelength selection? Sketch the geometry around the diffraction grating to check your answers.**Monochromator Characteristics**Czerny – Turner Monochromaor 1. Dispersion, Resolution, and Bandpass 2. Accuracy, Speed 3. Throughput, Imaging Quality 4. Stray Light http://www.jobinyvon.com/usadivisions/osd/product/size_spectrum.pdf**Spectral Bandpass and Slit Function**Spectral bandpass: sg = RdW Ingle and Crouch, Spectrochemical Analysis**Spectral Resolution (l/Dl) with Large W**Ingle and Crouch, Spectrochemical Analysis http://www.jobinyvon.com/usadivisions/osd/product/size_spectrum.pdf**Are you getting the concept?**Calculate the angular dispersion, linear dispersion, and reciprocal dispersion for third order diffraction of l = 650 nm from a diffraction grating 6 cm wide with 3500 grooves/cm rotated 17° from normal. The take off angle to reach the exit mirror is 6.5 ° and the spectrometer focal length is 150 cm.**Others Ways to Separate l**Bandpass Filters High-pass Filters Notch Filters Low-pass Filters www.mellesgriot.com
