  1. Assume/Guarantee Reasoningusing Abstract Interpretation Nurit Dor Tom Reps Greta Yorsh Mooly Sagiv

  2. Limitations of Whole Program Analysis • Complexity of Chaotic Iterations • Not all the source code is available • Large libraries • Software components • No interaction with the client • Program design

  3. A Motivating Example List rev(List x) requires acyclic(x) ensures $$=reverse(x) List rev(List x) { if (x ==null) return null ; return append(rev(xnext), x); } Contract List append(List x, List y) { List e; if (x == null) return y; e = malloc(…); edata = xdata; enext = append(xnext, y); } List append(List x, List y) requires acyclic(x)  acyclic(y) ensures $$= x || y Contract Can also used for runtime testing

  4. Challenges in A/G Reasoning • Specifying procedure contracts • Performing abstract interpretation using contracts

  5. Specifying Contracts • Executable specifications • assert • Can use loops • Expressive • Natural • But what about side-effects • Declarative specifications • Types • First order logic • Z • Hybrid • Larch • Java Modeling Language

  6. Procedure Contracts and Modularity • The postcondition does not reveal the whole story List foo(List x) requires acyclic(x) acyclic(y) ensures true void foo(List x, List z) { List y, t ; y = rev(x); t = rev(z); } List rev(List x) requires acyclic(x) ensures $$=reverse(x)

  7. Procedure Contracts and Modularity • Specify parts of the state which may be modified • But difficult to define potential side-effects • Can use abstract interpretation List foo(List x) requires acyclic(x) acyclic(y) ensures true void foo(List x, List z) { List y, t ; y = rev(x); t = rev(z) } List rev(List x) requires acyclic(x) ensures $$=reverse(x)

  8. Issues in Specifying Contracts • Expressible • Conciseness • Natural • Reuse • Cost of dynamic check (model checking) • Decidability • Cost of abstract interpretation

  9. Plan • CSSV: A tool for verifying absence of buffer overruns (N. Dor) • An algorithm for performing abstract interpretation in the most precise way using specification

  10. CSSV: Towards a Realistic Tool for Statically Detecting All Buffer Overflows in C Nurit Dor, Michael Rodeh, Mooly Sagiv DAEDALUSproject

  11. Null dereference Dereference to unallocated storage Out of bound pointer arithmetic Out of bound update Vulnerabilities of C programs /* from web2c [strpascal.c] */ void foo(char *s) { while ( *s != ‘ ‘ ) s++; *s = 0; }

  12. Is it common? • General belief – yes! • FUZZ study • Test reliability by random input • Tens of applications on 9 different UNIX systems • 18% – 23% hang or crash • CERT advisory • Up to 50% of attacks are due to buffer overflow • COMMON AND DANGEROUS

  13. CSSV’s Goals • Efficient conservative static checking algorithm • Verify the absence of buffer overflow • not just finding bugs • All C constructs • Pointer arithmetic, casting, dynamic memory, … • Real programs • Minimum false alarms

  14. string(src)  string(dst) (size > len(src)+len(dst)) alloc(dst+len(dst)) > len(src)) Verifying Absence of Buffer Overflow is non-trivial void safe_cat(char *dst, int size, char *src ) { if ( size > strlen(src) + strlen(dst) ) { dst = dst + strlen(dst); strcpy(dst, src); } } {string(src)  string(dst)alloc(dst+len(dst)) > len(src)} {string(src)  alloc(dst) > len(src)}

  15. Complex linear relationships Pointer arithmetic Loops Procedures Use Polyhedra[CH78] Pointer analysis Widening Procedure contracts Can this be done for real programs? Very few false alarms!

  16. V = { (1,2) (2,1) } R = { (1,0) (1,1) } 0 1 2 3 y 0 1 2 3 x Linear Relation Analysis • Cousot and Halbwachs, 78 • Statically analyze program variable relations: a1* var1 + a2* var2 + … + an* varn b • Polyhedron y  1 x + y  3-x + y 1

  17. C String Static Verifier • Detects string violations • Buffer overflow (update beyond bounds) • Unsafe pointer arithmetic • References beyond null termination • Unsafe library calls • Handles full C • Multi-level pointers, pointer arithmetic, structures, casting, … • Applied to real programs • Public domain software • C code from Airbus

  18. Plan • Semantics for C program • Contract language • Static analysis algorithm • Implementation

  19. ‘x’ 0x5050510 0x5050518 0 Standard C Semantics dst 0x480580 0x5058510 size 0x480584 125 void safe_cat( char *dst, int size, char *src ) { if ( size > strlen(src) + strlen(dst) ) { dst = dst + strlen(dst); strcpy(dst, src); } } src 0x480588 0x6000009 ‘y’ 0x6000009 0x6000A00 0

  20. dst 0x480580 0x5058510 size 0x480584 125 src 0x480588 ‘x’ 0x5050510 0x5050518 0 ‘y’ 0x6000009 0x6000A00 0 Instrumented C Semantics base asize 4 4 0x6000009 4 130 245

  21. ‘x’ 0x5050510 0x5050518 0 Instrumented C Semantics base asize offset dst 0x480580 0x5058510 4 0 size 0x480584 4 125 src 0x480588 0x6000009 4 9 130 0x6000000 245 ‘y’ 0x6000009 0x6000A00 0

  22. i offset(dst) asize(base(dst)) base(dst) dst Safety • The instrumented semantics checks validity of C expressions • ANSI C • Cleanness • dst = dst + i offset(dst) + i  asize(base(dst))

  23. Contracts • Defined in the instrumented semantics • Specify string behavior of procedures (C expressions) • Precondition • Postcondition • Use of values at procedure entry • Side-effects • Can be approximated from pointed information • No need to specify pointer information • Not aiming for modular pointer analysis

  24. Contracts’ Advantages • Modular analysis • Use contracts on call statements • Not all the code is available • Enable more expensive analyses • User control of the verification • Detect errors at point of logical error • Improve the precision of the analysis • Check additional properties • Beyond ANSI-C

  25. Example char* strcpy(char* dst, char* src) requires mod ensures ( string(src)  alloc(dst) > len(src) ) dst ( len(dst) = = [len(src)]pre return = = [dst]pre )

  26. safe_cat’s contract void safe_cat(char* dst, int size, char* src) requires mod ensures ( string(src)  string(dst) alloc(dst) == size ) dst ( len(dst) <= [len(src)]pre + [len(dst)]pre len(dst) >= [len(dst)]pre )

  27. Contracts and Soundness • All errors are detected • Violation of statement’s precondition • …a[i]… • Violation of procedure’s precondition • Call • Violation of procedure's postcondition • Return • Violation messages depend on the contracts • But may lead to more false alarms (e.g., trivial contracts)

  28. CSSV Static Analysis • Inline contracts • Expose behavior of called procedures • Pointer analysis (global) • Find relationship between base addresses • Integer analysis • Compute offset information

  29. Step 1: Inliner void safe_cat( char *dst, int size, char *src ) requires ( string(src)  string(dst) alloc(dst) == size) mod dst ensures ( len(dst) = = [pre@len(src)]pre + [len(dst)]pre ) void safe_cat( char *dst, int size, char *src ) { … strcpy(dst, src); … } char* strcpy( char *dst, char *src ) requires ( string(src) alloc(dst) > len(src)) mod dst ensures ( len(dst) = = [len(src)]pre return = = [dst]pre )

  30. Step 1: Inliner void safe_cat( char *dst, int size, char *src ) requires ( string(src)  string(dst) alloc(dst) == size) mod dst ensures ( len(dst) = = [pre@len(src)]pre + [len(dst)]pre ) void safe_cat( char *dst, int size, char *src ) { … strcpy(dst, src); … } assume assert char* strcpy( char *dst, char *src ) requires ( string(src) alloc(dst) > len(src)) mod dst ensures ( len(dst) = = [len(src)]pre return = = [dst]pre )

  31. Step 1: Inliner void safe_cat( char *dst, int size, char *src ) requires ( string(src)  string(dst) alloc(dst) == size) mod dst ensures ( len(dst) = = [pre@len(src)]pre + [len(dst)]pre ) void safe_cat( char *dst, int size, char *src ) { … strcpy(dst, src); … } assert char* strcpy( char *dst, char *src ) requires ( string(src) alloc(dst) > len(src)) mod dst ensures ( len(dst) = = [len(src)]pre return = = [dst]pre ) assume

  32. Step 2: Compute Pointer Information • Required for reasoning about pointers • Every base address is abstracted by an abstract location • Relationships between base addresses is computed (points-to) • Global analysis • Scalable • Imprecise • Flow insensitive • (Almost) Context insensitive

  33. Global Points-To safe_cat( char *dst, int size, char *src ) { … strcpy(dst, src); … } dst src main() { char s[10], t[20],r; char *p1, *p2; … p1= r + i; safe_cat(s,10,p1); p2 = r + j; safe_cat(t,10,p2); … } s t r p2 p1

  34. Procedural Points-to (PPT) • “Project” pointer information on visible variables of the procedure • Introduce abstract locations for formal parameters • Allow destructive updates through formal parameters (well behaved programs) • Can decrease precision in some procedures

  35. PPT dst src safe_cat( char *dst, int size, char *src ) { … strcpy(dst, src); … } Param #1 Param # 2

  36. Step 3: Static Analysis • Prove linear inequalities on string indices • Abstract string properties using constraint variables • Use abstract interpretation to conservatively interpret program statements • Verify safety preconditions

  37. ‘x’ 0x5050510 0x5050518 0 Back to Semantics base asize offset dst 0x480580 0x5058510 4 0 size 0x480584 4 125 src 0x480588 0x6000009 4 9 130 0x6000000 245 ‘y’ 0x6000009 0x6000A00 0

  38. ‘x’ 0x5050510 0x5050518 0 Abstract Representation dst 0x480580 dst 0x5058510 size 0x480584 125 src 0x480588 size 0x6000009 src n1 0x6000000 n2 ‘y’ 0x6000009 Base address relationship 0x6000A00 0

  39. Constraint Variables • For every abstract location a.offset src src.offset = 9

  40. Constraint Variables • For every integer abstract location a.val size size.val = 125

  41. Constraint Variables • For every abstract location a.is_nullt a.len a.asize n1.len n1.asize n1 0

  42. Abstract Representation dst.offset < n1.len dst size size.val+ dst.offset = n1.asize src n1.is_nullt = true n1 n2 n2.is_nullt = true

  43. n1.is_nullt = true dst.offset < n1.len size.val + dst.offset = n1.asize dst.offset n1.len n1.asize 0 size.val What does it represent? dst ? size ? ?

  44. dst.offset = n1.len size.val = n1.asize - dst.offset + n1.len Abstract Interpretation dst.offset < n1.len size.val = n1.asize - dst.offset dst = dst + strlen(dst);

  45. offset(dst) + i  asize(base(dst)) dst.offset + i.val  n1.asize dst i offset(dst) asize(base(dst)) dst.offset i n1.asize n1 base(dst) dst Verify Safety Condition dst = dst + i concrete semantics abstract semantics

  46. The Assume-Operation • Use two copies of constraint variables • Set modified values to ⊤ • Meet the post

  47. Procedure’sPointer info PreModPost Pointer Analysis Inliner C2IP Cfiles Cfiles Cfiles C’files Integer Procedure Potential Error Messages Integer Analysis CSSV Implementation contracts Procedure name

  48. Used Software • ASToolKit [Microsoft] • Core C [TAU - Greta Yorsh] • GOLF [Microsoft - Manuvir Das] • New Polka [Inria - Bertrand Jeannet]

  49. Applications • Verified string library from Airbus with 6 false alarms • Could be avoided by analyzing correlated conditions • Found 8 real errors in another string intensive application with 2 false alarms • In one case safety depends on correctness • Could be avoided by defensive programming • 1 - 206 CPU seconds per procedure • No optimizations • Very few false alarms

  50. Related Work Non-Conservative • Wagner et. al. [NDSS’00] • LCLint’s extension [USENIX’01] • Eau Claire [IEEE Oakland 02] Conservative • Polyspace verifier • Dor, Rodeh and Sagiv [SAS’01]
