  1. TED 5000 notes alexcronin 8/16/2010

  2. PV monitoring systems • TEP/UA solar test yard “DIY” • SOLON test yard “DIY” • Inverter Based systems • SunnyBoy • Fronius • PV Powered • Enphase • Fat Spaniel • Draker Laboratories • Energy Re-commerce • The Energy Detective “TED”

  3. TED 5000 www.theenergydetective.com

  4. TED 5000 www.theenergydetective.com CTs MTU

  5. Main CTs Solar CTs MTU1 MTU2

  6. Solar CTs

  7. Cable modem Router Gateway

  8. (communication on AC powerline) Gateway (communication on ethernet) CT---MTU Router (communication on TCP/IP) PC (wget or browser)

  9. Old Fridge New Fridge
