Presentation Transcript

  1. Bioremediation

  2. Bioremediation Defined • Any process that uses microorganisms, fungi, green plants or their enzymes to break down harmful chemicals and pollutants in order to return the environment to its original natural condition. • “Bioremediation is not only about genetics and enzymology but also about physiology and ultimately ecology.”—de Lorenzo V: Systems biology approaches to bioremediation. Curr Opin Biotechnol 2008, 19:579-589.

  3. Alleviating Pollution • Ex situ or in situ intervention • Natural attenuation • Example: phytoremediation (hyperaccumulators) store heavy metals in vacuoles • Sebertiaacuminata 20% dry weight is nickel. • Plants on side of freeways are taking up lead from gas exhaust • Bio-stimulation • Add nutrients (nitrate/sulfate) that cause blooms of naturally occurring microbial bioremediators. • Example: bacteria that metabolize polycyclic aromatic hydrocarbons or polychlorinated biphenyls • Bio-augmentation • Genetically Modified Bioremediators • Alter organisms to manufacture proteins for desired metabolism • Yellow poplar tree given enzyme mercuric reductase thrives in mercury soil, cadmium, TCE • Bacteria gene breaks down TNT is linked to jellyfish gene that glows. Bacteria spread on soil glows green near explosives • Chakrabarty first patented oil eater bacterium. Combined 4 plasmids in one bacterial cell gave it the ability to degrade four components of crude oil.

  4. Why do we even need it? • We can’t seem to stop polluting • Inorganics • Uranium, technicium, sulfur, slfuric acid • Explosives • RDX, TNT • Polyaromatic hydrocarbons • creosote • Chlorinated hydrocarbons • Trichlorethylene, PCBs, pentachlorophenol • Petroleum hydrocarbons • Gas, gas additives (MTBE), deisel • From mid-1980’s up to 90’s numerous attempts were made to design GMO for environmental release for pollutants and heavy metals (USGS). • Failures to program: bacteria doesn’t behave in a predictable fashion from the lab.

  5. Case Study 1

  6. Case Study 1 cont… • Most failures at bioremediation are due to failure of introduced organisms to thrive in the natural environment or a failure to access the contaminant. This could be due to: • Lack of nutrients • Predation or parasitism • Competition (GEM’s tend to compete poorly with indigenous populations). • Immobility of introduced bacteria • Contaminant concentrations below threshold for organism survival • Organisms may feed on alternative substrates (E. coli and Pseudomonas diverge genetically from initial inoculum in field trials). • A few examples of failed bioremediation attempts: • Inoculation of soil with aliphatic hydrocarbon degrading bacteria did not enhance degradation of fuel oil • Venosa AD, Wrenn BA (1996) Selective enumeration of aromatic and aliphatic hydrocarbon degrading bacteria by a most‑probable number procedure. Can. J. Microbiol.42: 252‑258 • A Pseudomonas sp. shown in lab cultures to degrade 1,4-dichlorophenol failed to degrade the compound when added to surface soils • Sayler GS, Ripp S (2000) Field applications of genetically engineered microorganisms for bioremediation processes. Curr Opin Biotechnol 11:286-289

  7. Case study 2:degradation of crude oil by halophilic Archaea

  8. Defining bioremediation by natural attenuation • what is the environment? what is the pollutant? • are bacterial, Archaeal, and/or plant species present that degrade the pollutant of interest? • what conditions (nutrient, temperature, pH, salt etc) are necessary for that activity?

  9. Defining bioremediation by natural attenuation:hydrocarbon degradation in the Arabian Gulf hypersaline coast • what is the environment? what is the pollutant? • the hypersaline coast of the Arabian coast • crude oil (hydrocarbons) West, Ian. 2008. Qatar - sabkhas, evaporites and some other desert features: an introduction. http://www.soton.ac.uk/~imw/Qatar-Sabkhas.htm

  10. Defining bioremediation by natural attenuation:hydrocarbon degradation in the Arabian Gulf hypersaline coast • what is the environment? what is the pollutant? • the hypersaline coast of the Arabian coast • crude oil (hydrocarbons) • are bacterial, Archaeal, and/or plant species present that degrade the pollutant of interest? 2 Haloferax strains 1 Halobacterium strain 1 Halococcus strain environmental samples grow on minimal mineral plates with crude oil vapor as sole carbon/energy source (Al-Mailem et al., 2010 Extremophiles)

  11. Defining bioremediation by natural attenuation:hydrocarbon degradation in the Arabian Gulf hypersaline coast • are bacterial, Archaeal, and/or plant species present that degrade the pollutant of interest? C18 hydrocarbon autoclaved control Haloferax isolate Halobacterium isolate Halococcus isolate gas-liquid chromatography to measure hydrocarbon degradation (Al-Mailem et al., 2010 Extremophiles)

  12. Defining bioremediation by natural attenuation:hydrocarbon degradation in the Arabian Gulf hypersaline coast • what conditions (nutrient, temperature, pH, salt etc) are necessary for that activity? • increased salt increased hydrocarbon degradation Haloferax isolate Haloferax isolate Halococcus isolate Halobacterium isolate Haloferax isolate (Al-Mailem et al., 2010 Extremophiles)

  13. How could this hydrocarbon degradation activity by Haloarchaea be improved? • General strategies for improving microbial bioremediation: stimulation or augmentation • Some existing bio-engineering tools • University of Minnesota Biocatalysis/Biodegradation Database (UMBBD): enzymes, pathways, reactions, compounds from hundreds of bacterial species of interest (Gao et al., 2010) • MetaRouter: tracks possible breakdowns from a starting point using all possible reactions (Pazos et al., 2005) • in silico modeling of altered strains: ex. Optstrain (Pharkya et al. 2004), DESHARKY (Rodrigo et al. 2008)

  14. How could this hydrocarbon degradation activity by Haloarchaea be improved? • How could systems level knowledge help design stimulation or augmentation strategies? • need to know network topology of the pathway being added or altered as well as the influence of the environment on that pathway • understand coupling of pathways to better integrate the engineered or altered pathway into the rest of the host system • understand demands created by the new flux on resources needed for growth/survival: energy, carbon, redox balance, transcriptional and translation capacity • is it possible to compensate by altering regulation by TFs etc, or by adding or deleting other pathways? • understand effect of environment on pathway flux • understand role of noise in pathway regulation • if cooperation between multiple microbial species is used, then systems analysis can evaluate impact of biodegradative flux on the multispecies consortia
