Understanding Packet Delays in Audio Streaming

This tutorial explores the delays experienced by packetized audio transmissions. It begins with an example where the first packet arrives at the receiver at t=8. We analyze the delays for packets 2 through 8, identifying their respective delays as 7, 9, 8, 10, 9, 8, and 8 slots. The tutorial further investigates which packets will not arrive in time for audio playout beginning at t=8, 9, and 10, identifying packet losses. Finally, it concludes by calculating the minimum playout delay required to ensure that all packets arrive in time, determined to be 11 time units.

olisa
Télécharger la présentation

Understanding Packet Delays in Audio Streaming

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Multimedia Tutorial

  2. Consider the figure below. A sender begins sending packetized audio periodically at t =1.The first packet arrives at the receiver at t = 8.

  3. What are the delays (from sender to receiver, ignoring any playout delays) of packets 2 through 8? Note that each vertical and horizontal line segment in the figure has a length of 1, 2, or 3 time units. The delay of packet 2 is 7 slots. The delay of packet 3 is 9 slots. The delay of packet 4is 8 slots. The delay of packet 5 is 10 slots. The delay of packet 6 is 9 slots. The delay of packet 7 is 8 slots. The delay of packet 8 is 8 slots.

  4. b) If audio playout begins at t = 8, which of the first eight packets sent will not arrive in time for playout? • Packets 3, 4, 5, 6, 7, and 8 will not be received in time for their playout if playout begins at t = 8. c) If audio playout begins at t = 9, which of the first eight packets sent will not arrive in time for playout? • Packets 3, 5 and 6 will not be received in time for their playout if playout begins at t=9. Playout > packet delay Otherwise the packet will not arrive in time

  5. d) If audio playout begins at t = 10, which of the first eight packets sent will not arrive in time for playout? • Packet 5 will not be received in time for their playout if playout time begins at t = 10. e) What is the minimum playout delay at the receiver that results in all of the first eight packets arriving in time for their palyout? • The minimum playout delay at the receiver that results in all of the first eight packets arriving in time for their palyout is 11. The minimum playout delay = largest delay +1
