  1. Ion beam Analysis Joele Mira from UWC and iThemba LABS Tinyiko Maluleke from US Supervisor: Dr. Alexander Kobzev

  2. Contents • Descriptions of Van de Graaf • Rutherford back-scattering (RBS) • RBS and Elastic recoil detection (ERD) • RBS and Proton induced X-ray emission (PIXE) • Conclusion SA-JINR Summer School 2008

  3. VAN DE GRAAFF ACCELERATOR • The EG-5 accelerator, accelerate ions to energy between 0.9-3.5 MeV • Beam intensity of 30μA for H and 10 μA for He. • Energy spread of 0.5 keV. • Energy precision of 2 keV. • 6 beam lines. SA-JINR Summer School 2008

  4. Introduction to RBS • The use of RBS is to provide information on concentration vs depth for heavy element in a light material. • A beam of 2-3 MeV He+ ions are directed at different angles on a sample surface. • The ion loses energy due to collision with electrons. • The ion will scatter elastically with the atomic nucleus and lead to a kinematic factor K, SA-JINR Summer School 2008

  5. Experimental setup for RBS SA-JINR Summer School 2008

  6. RBS spectrum SA-JINR Summer School 2008 6

  7. SA-JINR Summer School 2008

  8. Elastic Recoil Detection (ERD) • ERD is a complimentary technique to RBS • It is used to measure concentration of H atoms in the thin layers, and in the near surface region of material. • The incident beam is directed at a grazing angle onto the sample surface. • The recoiling atoms are ejected and detected at forward angle. • A thin foil is placed in front of the detector to stop elastically scattered incident ion beam and all atoms with mass heavier than the beam. SA-JINR Summer School 2008

  9. Experimental setup SA-JINR Summer School 2008

  10. RBS spectrum RBS SPECTRUM SA-JINR Summer School 2008 10

  11. ERDA spectrum ERDA Spectrum SA-JINR Summer School 2008 11

  12. Proton Induced X-ray Emission (PIXE) • Occurs when a sample is bombarded with the beam, the proton interact with the electrons in the atoms of the sample, creating an inner shell vacancy • The X-ray is emitted when an electron from outer shell fills the hole left by an electron. • The energy of the X-rays emitted are characteristic of the element from which they originate. • The number of emitted X-rays is proportional to the amount of the corresponding element within the sample. SA-JINR Summer School 2008

  13. Experimental setup for RBS and PIXE SA-JINR Summer School 2008 13

  14. RBS and PIXE RBS Spectrum SA-JINR Summer School 2008 14

  15. PIXE PIXE Spectrum SA-JINR Summer School 2008 15

  16. PIXE Elements content & concentrations in aerosol SA-JINR Summer School 2008 16

  17. Conclusion • The use of ion beam analysis is non-destructive, high accuracy and easy to interpret the experimental results. • The use of these models allow the determination of different elements from Hydrogen to heavy elements concentrated in samples. • It also allow the analysis of very thin sample of about 10 nm. • Ion beam analysis is applied in various fields such as microelectronics, environmental monitoring etc. SA-JINR Summer School 2008

  18. Thanks for your attention!! SA-JINR Summer School 2008
