  1. Packet Tracer 6Building a VoIP NetworkPart 1 Eric Kwok Technical Manager

  2. Session 1 Agenda • Resources for VoIP • VoIP support in PT • Simulation Mode

  3. VoIP Sample in PT

  4. VoIP Endpoint Devices in PT VoIP Adapter Analog Phone IP Communicator Cisco 7960

  5. Voice VLANSupported Catalyst 2950(T)/2960 Voice VLAN not Support Router Switch Module in PT NM-ESW-161 HWIC-4ESW Switches support Cisco 3560 Voice VLAN 24 Ports PoE Switch#show power inline Available:370.0(w) Used:6.3(w) Remaining:363.7(w) Interface Admin Oper Power Device Class Max (Watts) --------- ------ ---------- ------- ------------------- ----- ---- Fa0/1 auto on 6.3 IP Phone 2 15.4 Fa0/2 auto off 0.0 n/a n/a 15.4 Fa0/3 auto off 0.0 n/a n/a 15.4 Fa0/4 auto off 0.0 n/a n/a 15.4 Fa0/5 auto off 0.0 n/a n/a 15.4 Fa0/6 auto off 0.0 n/a n/a 15.4 Fa0/7 auto off 0.0 n/a n/a 15.4 Fa0/8 auto off 0.0 n/a n/a 15.4

  6. Observing VoIP Packet Flow

  7. Making Calls Receive and Playback Voice Packets Send Voice Packets Make Calls Enable Sound

  8. VoIP Supported for Network Devices Cisco 2811 CME built-in Cisco 2901/2911 IOS 15 UCK9

  9. IOS 15 UCK9 activation 2911(config)#teleph? % Unrecognized command 2911(config)#license boot module c2900 technology-package uck9 ACCEPT? [yes/no]: yes % use 'write' command to make license boot config take effect on next boot %IOS_LICENSE_IMAGE_APPLICATION-6-LICENSE_LEVEL: Module name = C2900 Next reboot level = uck9 and License = uck9 %LICENSE-6-EULA_ACCEPTED: EULA for feature uck9 1.0 has been accepted. UDI=CISCO2911/K9:FTX15240JBR; StoreIndex=2:Evaluation License Storage 2911#reload Proceed with reload? [confirm] 2911(config)#telephony-service 2911(config-telephony)#? auto Define dn range for auto assignment auto-reg-ephone Enable Ephone Auto-Registration createcreatecnf for ethernetphone

  10. CLI Support CME Support • Router(config)#telephony-service • Router(config-telephony)#? • auto Define dn range for auto assignment • auto-reg-ephoneEnable Ephone Auto-Registration • create create cnf for ethernet phone • exit Exit from telephony config mode • ip Define IP address and port for Telephony-Service/Fallback • keepalive Define keepalive timeout period to unregister IP phones • max-dn Maximum directory numbers supported • max-ephones Define max number of IP phones • no Negate or set default values of a command • R1# show run • ip dhcp pool its • network 1.0.0.0 255.0.0.0 • default-router 1.1.1.1 • option 150 ip 1.1.1.1 DHCP Support

  11. End of Session 1
