Servo Packages

DESCRIPTION

Servo Packages. Solder 1.5K resistor brown green red (only applicable if you have the 5V Reg ). Solder A 3x4 header. Solder t he rest. Solder 1K Resistor (R27). Solder Led Long Lead Toward +. Solder 1K Resistor To (R17). Solder .1uf (104) To (C7). Solder 15pf (150) to (C3,C4).

1 / 17

Télécharger la présentation

Servo Packages

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Servo Packages

  2. Solder 1.5K resistor brown green red(only applicable if you have the 5V Reg)

  3. Solder A 3x4 header

  4. Solder the rest

  5. Solder 1K Resistor (R27)

  6. Solder Led Long Lead Toward +

  7. Solder 1K Resistor To (R17)

  8. Solder .1uf (104) To (C7)

  9. Solder 15pf (150) to (C3,C4)

  10. Solder 12MHz crystal to (Q1)

  11. Add Flux To (U100, U101, U104) Pads

  12. Solder LV273s

  13. Flux And Solder ATtiny4313

  14. Solder 2x3 header (ISP)

  15. Solder 2 pin terminal

  16. Solder 5v reg

  17. Finished…Now
