  1. Team BAM! Scott Amack, Everett Bloch, Maxine Major Format String Attacks

  2. Overview • What is a Format String Attack? • About Format Strings • Anatomy of an Attack • History • Current Events • Demo • Conclusions

  3. What are Format String Attacks? • A class of software vulnerability discovered around 1999 • Uses C format functions to crash programs or execute harmful code • Problem stems from unchecked user input in format functions

  4. Format Strings • Used in format functions: printf(), sprintf(), fprintf(), etc • Format functions take a variable amount of arguments, of which one is called the format string printf(“<format string>”, arg1, arg2, … , argn);

  5. Format Strings • % is an escape character, it pops the respective argument from the stack and evaluates its value based on the following specifier and prints • %s – ptr to ASCIIZ string • %d – integer value • %x – hexadecimal value, up to 8 digits • %p – hexadecimal value, more robust than %x • %n – write to memory the number of characters previously output • Memory location is referenced by argument • Usage: printf(“Hello%n”, &i); //i = 5 • %% - prints %, does not pop any values

  6. Format Strings • Arguments are pushed onto the stack when printf is called • Arguments are popped off in their respective order when called from the format string (using “%”) • The first to be popped is the argument that comes after the format string • No limit to number of pops, if printf pops out of its bounds program crashes

  7. Format Strings • printf (”i = %d, a = %d address of a = %x\n", i, a, &a); • The printf function parses the format string one character at a time, printing everything that is not “%” to stdout

  8. Format Strings • An argument can be referenced directly using the $ symbolUsage: %<number>$<specifier> • <number> - the arguments location in the stack, first argument is 1 • <specifier> - s, d, x, n, etc printf ("%2$d\n", 6, 5); prints “5”, because 5 is the second argument on the stack

  9. Format Strings • Some specifiers can specify the minimum number of characters to output Usage : printf(“%25d”, i); • print at least 25 characters to stdout • result is padded with blank space • does not truncate

  10. Format String Attack • Becomes possible when user input is the format string • OK: printf(“%s”, user_input); • Exploitable: printf(user_input); • The user can input format specifiers that will be evaluated by printf

  11. Format String Attack • Multiple issues of %x or %p prints out a stack trace of the printf function • traversing the stack • used to locate format string in the stack • %n can be used to overwrite memory based on the currently popped value • Multiple issues of %s, or an excessive stack traversal can kill the process

  12. Format String Attack Strategy Format string: <addr><NOP><shell-code><stack traversal + padding><%n> ex) addr = 0x08a5ffbc “\xbc\xa5\xff\xbc;;;;;;;;;;;;;;;;;;;;execl("/bin/bash", "bash", 0);%11$41002x%n” • addr– address of what we want to overwrite, normally printf return address. Little endian representation • NOP – a small NOP sled that leads to shell-code (optonal) • shell-code – the attacks payload, simple code that starts the actual exploit with printf privileges (optional) • stacktraversal - %x’s or %<number>$x, pop us to the format string location • padding – use %<number>x so number of characters output equals the address we desire to write with %n, <NOP> can act as padding also • %n writes the current number of characters to the address specified by <addr> <NOP> and <shell-code> are optional because sometimes the address to overwrite, <addr>, is something other than the printf return function.

  13. Format String Attack Uses • Overwrite printf return address to execute shell-code • Overwrite C library hooks such as __malloc_hook, __realloc_hook, and __free_hook, to jump to your code when ever those functions are called • Overwrite __atexit address to jump to your code whenever the exit() function is called

  14. History • First format string bugs noted in 1990, at the University of Wisconsin while testing the C-shell, bugs were referred to as "interaction effects" • First identified as an attack vector in September 1999 in a security audit of an FTP daemon ProFTPd by TymmTwillman • Wasn’t until June of 2000 that the full dangers of format string vulnerabilities as exploits were made public

  15. History • wu-ftpd 2.* • free FTP daemon • one of the first commercial programs exploited using format string attacks • discovered by security.is • had multiple format string vulnerabilities • vulnerabilities persisted for over 6 years • when attempting to log in, username string passed as a format string • exploit impact gave remote root to attacker, on ftp server • vulnerabilities corrected by forcing user input to be an argument referenced by the format string

  16. Format String Attacks • Information about vulnerabilities: Mitre has a Common Vulnerability and Exposure Database that currently lists 588 of these type of vulnerabilities in current software. http://www.cve.mitre.org/

  17. Recent Format String Attacks • January 2013 EMC Alphastor 4.0 800 Alphastor is software that provides media management and device sharing services for backup servers. The rrobotd.exe file is vulnerable to format string input via a vsnsprintf function. This accepts incoming commands and therefore is vulnerable to a format string attack.

  18. Recent Format String Attacks • September 2012 Mcrypt : A program used to encrypt files in UNIX • If you ran the program with the following command:$ mcrypt --no-openpgp "%s.nc“It could cause this type of attack because of how the input string was handled. • Key thing to note is the %s in the filename.

  19. Recent Format String Attacks • August 2012 Microsoft Windows XP, Vista, 7, Server 2003, Server 2008 • Attacker can send a crafted response to the print spooler and remotely execute code. • Denial of Service is also possible making printer services unavailable.

  20. Recent Format String Attacks • June 2012 VMWare Workstation 8.x and VMWare player 4.x • An OVF file which helps automate distribution of virtual machines could contain malicious information to exploit this format string vulnerability. • This exploit could allow malicious code to be executed.

  21. Format String Attacks Demo What we can do with format string attacks: 1. crash the program (DOS) 2. View the stack 3. View memory at arbitrary locations 4. Overwrite memory at arbitrary locations 5. Code execution

  22. Format String Attacks DEMO

  23. Conclusions • Format functions can be used as an attack vector for format string attacks • Format function has no bounds checking; it may pop as many times as system allows. • Be sure that the format string references the variable(s). printf(“%s\n”, variablename); • Format string attacks seem simple, but are still a very viable method of attack.

  24. Recap • What is a Format String Attack? • About Format Strings • Anatomy of an Attack • History • Current Events • Demo • Conclusions

  25. References • Wikipedia http://en.wikipedia.org/wiki/Format_string_attack • Hanebutte, Oman. Software Vulnerability Mitigation A Proper Subset of Software • Maintenance. Journal of Software Maintenance and Evolution: Research and Practice: 2003. • scut / team teso. Format String Vulnerabilities: 2001. • http://www.google.com/url?sa=t&rct=j&q=&esrc=s&source=web&cd=6&cad=rja&ved=0CF8QFjAF&url=http%3A%2F%2Fcrypto.stanford.edu%2Fcs155old%2Fcs155-spring08%2Fpapers%2Fformatstring-1.2.pdf&ei=zq8tUYCbCNHyigKqgYHwCQ&usg=AFQjCNG3QiG2k0n39PsNfLIcyjkiZJjuow&bvm=bv.42965579,d.cGE • https://www.owasp.org/index.php/Format_string_attack • http://en.wikipedia.org/wiki/Uncontrolled_format_string • http://www.openwall.com/lists/oss-security/2012/09/06/8 • http://www.cve.mitre.org/cgi-bin/cvekey.cgi?keyword=format+string • http://archives.neohapsis.com/archives/bugtraq/2012-06/0192.html • http://www.vmware.com/security/advisories/VMSA-2012-0015.html • http://cxsecurity.com/issue/WLB-2013010167 • http://technet.microsoft.com/en-us/security/bulletin/ms12-054 • http://www.youtube.com/watch?v=E9gx0MflQm4 • http://www.youtube.com/watch?v=wLSYkYmfqJ8 • http://www.youtube.com/watch?v=GfEGzZoZY7g
