Performance Issues in Virtualization: Impact on Cloud Computing Network Efficiency

DESCRIPTION

This lecture explores the performance implications of virtualization in cloud computing environments, focusing on key concepts such as resource sharing, processor sharing, and network performance. It discusses the effects of virtualization on Amazon EC2, including performance profiling and measurement methodologies for network latency, throughput, and packet loss. Key experiments highlight how different instance sizes and availability zones influence TCP/UDP performance, with recommendations for mitigating performance issues. The discussion emphasizes the importance of understanding virtualization effects to optimize application performance.

1 / 28

Télécharger la présentation

Performance Issues in Virtualization: Impact on Cloud Computing Network Efficiency

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Lecture 7: Performance Issues with Virtualization Xiaowei Yang (Duke University)

  2. Recap • What’s cloud computing • Security issues

  3. Today • How virtualization impacts performance (measurement) • The Impact of Virtualization on Network Performance of Amazon EC2 Data Center • Guohui Wang, T. S. Eugene Ng • Performance Profiling in a Virtualized Environment • JiaqingDu, NipunSehrawat, and Willy Zwaenepoel

  4. Virtualization Impacts Network Performance • Cloud computing uses virtualization to provide resource sharing • Time sharing • Processors, NIC, harddisk, performance monitoring unit Guest0 Guest1 Dom0 Driver domain Xen NIC

  5. Measure the impact of virtualization • Processor sharing • Packet round-trip delay • TCP/UDP throughput • Packet loss

  6. Processor sharing • Measurement methodology • CPUTest: loops for a million times • Gettimeofday() at the beginning and end of the loop • Saves timestamps in memory • Dump the saves timestamps to disks

  7. Packet round-trip delay • 10 ping probes per second, 5000 round-trip delay measurements

  8. TCP/UDP throughput • UDPTest • The program itself must be able to read and send data as fast as possible 128KB UDPSend UDPRecv Dom0 Dom0 Xen Xen NIC NIC

  9. TCP/UDP throughput 128KB • TCPTest • Send and Receive window set to 256KB • 0.5ms •  4Gbps TCPSend TCPRecv Dom0 Dom0 Xen Xen NIC NIC

  10. Packet loss • Badabing • Packet loss estimation • Active probes and statistical estimations

  11. Experiments setup: spatial • Across different instances, availability zone • For each availability zone (3 total) • 250 pairs of small instance • 50 pairs of medium instances • TCP/UDP • May congest the network • Limit to 800MB data • Badabing • One minute

  12. Experiments setup: temporal • Over a period of time • Two small instance pairs and one medium in each of the availability zone • Processor sharing, network performance, and packet loss • Round by round for 150 hours • Each round separate for 10 minutes

  13. Results

  14. Processor sharing

  15. How to compute CPU share • Loop > 1ms  off • Loop ~ 3us  on

  16. Distribution of CPU share

  17. Bandwidth measurement results

  18. Bandwidth measurement results

  19. A closer look

  20. Medium instances’ performance

  21. Why? • TCP/UDP sender is scheduled off • UDP > TCP • Sender can send when receiver is scheduled off

  22. End-to-end delays

  23. Why • Queuing? • Unlikely, rare packet loss • <500Mb/s TCP throughput  no congestion • Receiver scheduled off •  no reply until it’s on again

  24. Packet loss estimation

  25. Why? • Measurement tool not considering virtualization does not fit • Badabing detects loss episodes • Loss episode • A packet loss within some time of now • One way delay is larger than a threshold •  Large variation leads to a high loss estimate

  26. Badabing overestimates loss

  27. Implications • Delay = queuing + transmission + propagation + scheduled off • Affect the fidelity of network testing if using small instances • May cause performance problems for some applications •  yet to be validated

  28. Discussion • Easy fix: using medium or large instances • I/O sharing • Better way to share networks? • Ways to detect whether you are sharing with another instance • Try it on other instances?
