  1. Research Progress 15 November 2011

  2. Outline • Database creating progress • MIDI file format • Using in Music analysis process • Next task

  3. Database Creating Progress • Have finished implementing of file reading and creating database file • Database that provide information of notes with ground truths

  4. MIDI File Format • MIDI file data (represented in Hexadecimal base) • Data consists of • Header chunk • Track chunk • <header_chunk> + <track_chunk> [+ <track_chunk> ...]

  5. MIDI File Format : Header Chunk Header chunk of MIDI file • header_chunk = "MThd" + <header_length> + <format> + <n> + <division>

  6. MIDI File Format :Header Chunk Chunk ID

  7. MIDI File Format : Header Chunk Chunk size

  8. MIDI File Format : Header Chunk Chunk ID and chunk size value is always the same

  9. MIDI File Format : Header Chunk Format type • Format type • 0 = single track • 1 = multiple tracks, synchronous • 2 = multiple tracks, asynchronous

  10. MIDI File Format : Header Chunk Number of tracks

  11. MIDI File Format : Header Chunk Time division • Represents either ticks per beat or frames per second

  12. MIDI File Format : Track Chunk Track chunk ID • track_chunk = "MTrk" + <length> + <track_event> [+ <track_event> ...]

  13. MIDI File Format : Track Chunk Track chunk ID

  14. MIDI File Format : Track Chunk Chunk size

  15. MIDI File Format : Track Chunk Track event data • Track events are used to describe all of the musical content of a MIDI file • Consists of delta time and events

  16. MIDI File Format : Track Chunk • There are three types of events: • MIDI Channel Events • Meta Events • System Exclusive Events

  17. MIDI File Format : Track Event Delta time

  18. MIDI File Format : Track Event Meta Event Delta time

  19. MIDI File Format : Track Event Meta Event Key Signature Delta time

  20. MIDI File Format : Track Event Meta Event Length Key Signature Delta time

  21. MIDI File Format : Track Event Meta Event Length Key Signature Key Delta time

  22. MIDI File Format : Track Event Meta Event Length Scale Key Signature Key Delta time

  23. Next Task • Implement the music analysis program
