Interface Control

Types of Interfaces • Physical • Electrical • Logical
Seven Layer Model • Physical • Data Link • Network • Transport • Session • Presentation • Application
Physical • Physical connectors • Electrical signals
Data Link • Point to point data delivery • Sets up – takes down data link connection
Network • Network routing interface
Higher Layers • User – user • Transport • Session • Presentation • Application
Physical RS 232 2 prong connector SAE screws Electrical 110 v, 60 Hz, ac 600 ohm, balanced RS 422 Logical Half duplex Touchtone signaling Standards
