Technology/Products

1. Technology/Products

2. North American Technical Center Activities Support North American customers and DENSO groups through the following activities: • Local Product Design and Development • (Thermal Components and Systems, Body Electronics; Infotainment; and Powertrain Components) • System Engineering Across Product Lines • Application Engineering • Production Engineering • Material Engineering • Engineering Administration • Technical Planning • Research and Development for North American Unique Needs • Vehicle System and Component Testing

3. North American Technical Center Test Chambers Note: Information on this slide is for internal and customers use only.

4. North American Technical Center Note: Information on this slide is for internal and customers use only.

5. Analytical • EDS (Energy Dispersive Spectrometer) • FT-IR (Fourier Transform – Infrared) • DMA (Dynamic Mechanical Analysis) • TGA (Thermo-Gravimetric Analysis) • DSC (Differential Scanning Calorimeter) • Karl Fischer Moisture Analyzer • GC-MS (Gas Chromatograph – Mass Spectrometer) • GC-FID (Gas Chromatograph – Flame Ionization Detector • XRF (X-Ray Fluorescence) • UV-Vis (UV-Visible Analyzer) • Carbon-Sulfur Analyzer • Potentiostat/Galvanostat • EPMA (Electron Probe Micro Analyzer) • IC (Ion Chromatograph) Microscopy • Metallography • Polarization Microscopy/Microtome • Optical/Digital Microscopy • Measuring Microscopy • SEM (Scanning Electron Microscope) Environmental • SST (Salt Spray Corrosion Tester) • CASS Corrosion Tester • CCT (Cyclic Corrosion Tester) • Depth Measurement Microscope Material Lab Capabilities Mechanical / Physical • Tension/Compression Tester • Impact Tester (Izod/Charpy) • MFR (Melt Flow Rate) • Creep Testers (x6) • Hardness (Wallace/Shore/Rockwell/Vickers) • Fatigue Tester Note: Information on this slide is for internal and customers use only.

6. Responsibilities in the Evaluation Stage

7. Automotive Fields Safety Environment Sensing technologies for driving assist systems, actuator & computer for antilock brake system (ABS) / electronic stability control (ESC), adaptive front-lighting system (AFS), airbag sensors & electronic control units, periphery monitoring system, instrument cluster, rain sensor for automatic windshield wiper, etc. Hybrid and electric vehicle components, gasoline engine management system, diesel engine management system, starter, alternator, radiator, etc. Comfort & Convenience Car air-conditioning system, air conditioner for buses, air purifier, Car navigation system, electronic toll collection system (ETC), remote security system, remote touch controller, smart key, advanced vehicle operation system (AVOS), etc.

8. ● Climate Control Products Automatic air conditioner, car heater, rear cooling unit, compressor, sensors, etc. ● Powertrain Related Products Engine management system, electronically-controlled diesel system, starter, alternator, radiator, etc. ● Body Electronics Products Instrument cluster, windshield wiper remote keyless entry system, IC flasher, horn, etc. Automotive Products ● Driving Control andSafety Cruise control system, airbag sensing system,vehicle stability control, antilock braking system, traction control system, active safety,etc.

9. Environmentally Friendly Products Preserving Clean Air Promoting Recycling • HVAC Unit • Starter • Alternator • Power Window Motor • Monolithic Carrier • Air Flow Meter • Fuel Injector • Spark Plug • Stop/Start Starter • High Pressure Fuel Injector • Oil Control Valve • Variable Displacement Compressor Reducing Hazardous Substances • Instrument Cluster • Air Conditioning Panel • Cooling Fan Motors • Windshield Wiper System • Power Seat Motor • Radiator Tank

10. North American Manufactured Eco-Products Preserving Clean Air Monolithic Carrier The monolithic carrier acts to reduce or oxidizes harmful emissions such as hydrocarbons, carbon monoxide, and nitrogen oxides. Air Flow Meter This air flow meter measure the flow rate of air into the intake manifold, resulting in the correct air-fuel ration for efficient combustion.

11. North American Manufactured Eco-Products Preserving Clean Air Fuel Injector This fuel injector’s atomizing capability dispenses fuel in precise quantities and allows for better mixing with air, increasing fuel efficiency. Spark Plug Tough metal alloys applied to the tip of the plug assure proper ignition even during idling, with less fuel consumption and less noise.

12. North American Manufactured Eco-Products Preserving Clean Air Stop/Start Starter Stop/start systems cut the engine when the vehicle is at a stop or in other idle traffic situations, helping to improve fuel efficiency by approximately three to five percent and to reduce CO2 emissions. High Pressure Fuel Injector The high-pressure fuel injector, developed for gasoline direct-injected engines, allows for more precise controlling of combustion and emissions, which translates to improved fuel economy.

13. North American Manufactured Eco-Products Preserving Clean Air Oil Control Valve The oil control valve controls the direction of the oil flow and activates the variable camshaft timing valve, providing more fuel savings and power. Variable Displacement Compressor The variable displacement compressor can alter refrigerant displacement to control air conditioner cooling capability, making it highly fuel-efficient.

14. North American Manufactured Eco-Products Promoting Recycling HVAC Unit The plastic case on this HVAC )heating, ventilation and air conditioning) unit is molded with 20% in-house recycled material. A titanium-based process provides corrosion resistance for the evaporator rather than hexavalent chromium, an environmentally hazardous substance. Lead solder was eliminated from processing operations by a raw material switch from copper to aluminum. Starter The variable displacement compressor can alter refrigerant

15. North American Manufactured Eco-Products Promoting Recycling Alternator A redesigned segment conductor produces a smaller, lighter alternator with higher efficiency and lower noise. Power Window Motor The power window motor is engineered to be the most compact, and is available in multiple output torque levels and three versions of control: standard, sensor and smart.

16. North American Manufactured Eco-Products Reducing Hazardous Substances Instrument Cluster & Air Conditioning Panel The instrument cluster and air conditioning panel are manufactured without the anti-corrosive hexavalent chromium, an environmentally hazardous substance that can leak into the underground water table if a product containing the metal is not disposed properly.

17. North American Manufactured Eco-Products Reducing Hazardous Substances Cooling Fan Motors The fan motor is manufactured with lead-free electrical brushes. Power Seat Motor The power seat motor is engineered to optimize material usage while maintaining performance and size advantages for today’s innovative, lightweight seat system.

18. North American Manufactured Eco-Products Reducing Hazardous Substances Windshield Wiper System The wiper motor is manufactured with lead-free electrical brushes. Radiator Tank (plant-derived resin) The plant-derived resin radiator tank, which is made from castor oil, is green all the way around. Compared to conventional products, it releases less CO2 emissions into the environment during its life cycle because it is partially made from material extracted from plants, which absorb CO2 through the photosynthesis process. It also helps conserve oil, a fossil fuel which is being depleted.
