  1. Embrace the Future of Data Center Networking Now Bethany MayerSenior Vice President and General Manager HP Networking

  2. “To remain static is to lose ground.” David Packard

  3. Legacy data center networks are at a breaking point Complex Constrained Manual

  4. FlexFabric – the future of data center networking Up to 75% simpler Up to 2X fabric scaling Months to minutes Simple Scalable Automated HP Virtual Application Networks

  5. New innovations for data center networks Simple Scalable Automated Virtual Services Router Unify the virtual and physical fabric Leading programmable interface FlexFabric Virtual Switch 5900v with EVB/VEPA OpenFlow 1.3 SDN visibility & orchestration IMC SDN Manager FlexFabric 5900 Series Switch with EVB/VEPA HP FlexFabric 12900 Switch HP FlexFabric 11900 Switch HSR 6800 Router

  6. FlexFabric Virtual Switch 5900v with EVB/VEPA Delivers standards-based automated VM network policy management • Unifies physical & virtual data center fabric • Advances networking beyond basic hypervisor vSwitch • Simplifies operations with separation of switch & server functions Single policy & management for physical & virtual Zero dedicated management appliances • 1Compared with Cisco Nexus 1010 Virtual Services Appliance

  7. FlexFabric11900 switch series Delivers leading 40 GbE End-of-Row scaling for server-to-server traffic flows • Industry’s first TRILL/SPB for scalability • Industry’s first OpenFlow 1.3-enabled for SDN • Cost-effective scale-out for Hadoop environments Up to 34% higher 40 GbE density3 Up to 31% lower cost per 40 GbE port2 50%lower latency1 • 1FlexFabric 11908 compared with Nexus 7010 with F2 modules 2FlexFabric 11908 compared with Nexus 7010 with M2 modules3FlexFabric 11908 compared with Nexus 7009 with M2 modules

  8. FlexFabric 12900 switch series Sets new benchmark for core data center fabric scaling • Ideal for large-scale cloud deployments • First core OpenFlow-enabled switch for SDN • Industry’s first TRILL/SPB for scalability Up to 3X40 GbE density2 Up to 2Xswitching capacity1 400%lower power per port2 • 1FlexFabric 12916 compared with Nexus 7018 with F2 modules2FlexFabric 12910 compared with Nexus 7010 with M2 modules

  9. HSR 6800 router series – breakthrough performance Delivering robust routing services • Comprehensive routing, firewall and VPN • High-density WAN router – 32 10 GbE ports • Carrier-class reliability with IRF – 687 µs recovery Up to 7Xhigher routing performance2 Up to 5X higher firewall scaling2 Up to 4900X faster failure recovery 1 1NetworkTest report reference 2 HSR 6808 vs. Cisco ASR 1000 Series

  10. Virtual Services Router Industry’s first Network Function Virtualization (NFV) technology • Deployment flexibility across branch, data center and cloud • Agile services delivery for faster time to revenue • Virtualized router for multi-tenant, hosted public clouds 50% less power & rack space1 Up to 87% operating cost reduction1 10X faster time to revenue1 1Compared to physical routers

  11. IMC Virtual Application Networks SDN Manager Delivers the industry’s first comprehensive SDN management tool • One application for managing SDN & traditional networks • Configuration, monitoring & policy mgmt for all SDN layers • SDN Controller & OpenFlow switch management IMC SDN Manager SDN Architecture Application Control Infrastructure 3X faster troubleshooting1 At least 50% less management complexity1 10X acceleration of SDN deployments1 1HP Internal Research

  12. Complete software-defined networks vision Deliver open programmable interfaces to automate orchestration of network services Business Applications Virtual Cloud Network Sentinel Security Load balancing WAN bursting UC & C for Lync Control Layer Application Layer SDN Controller SDN Controller 3rd Party Controllers VAN SDN Controller WAN Open standard-based programmatic access to infrastructure Virtual Switches Infrastructure Infrastructure Layer Network Device Network Device Data Center HP 3rd Party Ecosystem Campus/Branch

  13. Data Center Network Modernization Conrad Menezes Vice President, Network & Information Security

  14. Data Center Network Modernization Conrad Menezes Vice President, Network & Information Security

  15. Our data center network reached saturation • Older switching infrastructure • Backups and near-real-time data replication • Private cloud scaling • Big data exploding • Over 250K TPS for Shop Your Way rewards program • Dynamic pricing introduced new requirements

  16. Solution through collaboration with HP WAN Routing Routing 12500 12500 DWDM DWDM 12500 12500 Core Core 5800 5800 IRF IRF IRF IRF Access Access Scaled DWDM to 3.2 Tbps 40 GbE Bandwidth Open Standards

  17. Scalable data center solution highlights Bandwidth I/O Scaling Carrier-class Reliability Private Cloud – 1000s of VMs Petabytes of Big Data 1M+ TPS for Shop Your Way Dynamic pricing – multiple times/day

  18. Key takeaways • Keep it simple • Don’t play the numbers game • Do your own testing • Build to scale with long-term investment protection –Software Defined Networking

  19. Delivering the future of data center networks now • FlexFabric reduces complexity up to 75% • FlexFabric unifies physical & virtual data center • FlexFabric 12900 doubles the data center capacity • VSR delivers Network Function Virtualization • Largest installed base of 20M+ OpenFlowswitches • First unified SDN & traditional network management Simple Scalable Automated

  20. Thank you
