1. Flight Test Engineering An introduction Into to Flight Test Engineering

2. Why Flight Test ? • Adequate replication on the ground of flight conditions is often impractical • Particular flight conditions may be insufficiently well defined to be simulated • Almost all aircraft incorporate many system whose interactions are complex • Discrepancies between actual flight behavior and predicted. Flight test data is essential to improve accuracy of the models and simulation. Flight Test is required to prove that the man/machine combination can achieve the desired “performance”. Into to Flight Test Engineering

3. Nature of Flight Test Expensive • Requires instrumentations, infrastructure, special maintenance of test vehicle, test area, specific weather conditions and qualified people. • Involving many parties. Inherently Hazardous • New configuration; unproven system; at the edge and beyond of flight envelope. • Explore the most critical configuration and failure cases of system. • Extensive preparation and careful planning. • Minimize flight hour • Crew readiness • Hazard assessment • Safety review Into to Flight Test Engineering

4. General Approach of Flight Testing Testing in operationally representative condition in a controlled, incremental manner with critical parameters monitored via appropriate instrumentation. • Starting from less hazardous and gradually towards more hazardous case • Comparison between test results and prediction • Explore aircraft envelope to ensure that aircraft meets requirements at the most critical conditions. • Testing in a known and controlled condition (suitable weather, low air traffic density, flight test instrumentation, safety equipments and dedicated test support) Into to Flight Test Engineering

5. Type of Flight Test • Experimental Flight Test • Research and Development purposes • Development and Certification Flight Test • Demonstration for the purpose of showing compliance with design objective and/or airworthiness requirement. • Must be performed using representative aircraft, proven instrumentation and test maneuver as per requirements. • Production Flight Test and Flight Test After Maintenance • Testing of series aircraft to ensure correct installation/maintenance within the established limitation Into to Flight Test Engineering

6. Development & Certification Flight Test Program Meet Design Requirement? Initial aircraft configuration Final Aircraft configuration Development Flight Test yes no Design Changes Meet Requirement? Approved Aircraft Limits, Procedures and Manual Certification Flight Test yes no 1 2 Type Certificate Revised Limits Design Changes Into to Flight Test Engineering

7. Production Flight Test Program Function Properly? Production Flight Test Program yes Type Certificate Series Production no Troubleshooting / Maintenance no • Acceptance Flight Test Program • Authority • Customer Accepted? Deliver to customer yes Into to Flight Test Engineering

8. General Design Design Office Applicable Spec./ Airworthiness Reg./ Certification Basis SE • Flight Test Requirements • Describe the test data & • measurement requirement • Data and Measurement Req. • Design Office • Test Aircraft • Basic Readiness • Instrumentation • Readiness • FLM, FTIS-FTC • Overall Flight Test Plan • Draft Flight Test Manual • Project FT Flight Test Project Proj. Leader FTC Flight Test Aircraft Limitations Design Office & Project FT • Predictions • Theoretical • Experimental Labs. • Design Office & Labs. • Short term plan • Flight Test Plan Monthly • Project FT Agreed FT Plan Authority Test Safety Review Board FTC, AD, TD, LM, • FT Aircraft • Airworthiness • CoA • SE - Authority • FT Preparation • Test Aircraft • FTIS & Calibration • FTC FT Execution FTC FT Report FTC FT Result FTC Flight Test Process Into to Flight Test Engineering

9. Flight Test Operation Information Flow Test Aircraft Post flight inspection Quality Assurance refuel Test aircraft configuration Test aircraft status Test Aircraft Readiness Test Crew Check in dispatch Test Aircraft Engineer Flight Test Operations Post flight briefing Test aircraft status Next test • Configurations • Weight & Balance • Weather Briefing FTIS Engineer FTIS status Data, video, voice establishment Test crew + aircraft engineers • Take off • Test Execution • Landing FTIS Recalibration Telemetry Mission Operation Control Room Test area transmission data Preflight Briefing Specialist Engineer Test procedures Specialist + FT controller + Data processing Data Processing Eng. Parameter list MOCS real time Flight Test Crew • Telemetry System • Data Processing System • Data Monitor & Display System Crew briefing Aviation Safety Safety Standard Authority Witness Individual/bilateral preparation Post Test Activity Test Operation Readiness Review and final check Into to Flight Test Engineering

10. IAe Flight Test Center - Main Tasks • Provide flight testing services to the corporate Activities starting from flight test program preparation, to flight test operation execution and finishing at flight test data analysis and reporting Flight Test Program Preparation Flight Test Operation/Execution Data Analysis, Reporting and post flight activity • Safety assessment • Human factor assessment • Flight Simulations • Flight Test Instrumentation & Data link system design & establishment • Flight Test Engineering methods development • Test Aircraft readiness, maintenance • Program planning • Test crew training • Data Reduction • Data Analysis • Data Reporting & Documentation • Flight Test Instrumentation Calibration • Flight Test Operations • Mission Operation Control Systems • Test Infrastructures and Safety Into to Flight Test Engineering

11. IAe - FTC Organization Into to Flight Test Engineering

12. Test Pilot • understands the test aircraft in detail. • clearly understands the aircraft mission (specific operational requirements, the detail specification) • formal study with practical application at an established test pilot school • proficient in the required flight skills to obtain accurate data. • has well developed observation and perception powers to recognize problems and adverse characteristics. • has the ability to analyze test results, understand them, and explain the significance of the findings Into to Flight Test Engineering

13. Flight Test Engineer The FTE has general knowledge of the same items for which the test pilot is mainly responsible. Additionally, the FTE possesses sound knowledge of: • Instrumentation requirements. • Planning and coordination aspects of the flight test program. • Data acquisition, reduction, and presentation. • Technical report writing. Into to Flight Test Engineering

14. FTE Tasks • Determination of measuring parameters • Preparation Ground and Flight Test Program • Technical preparation of the tests • Monitoring of important parameters during flight testing, either from telemetry or from a workstation in the aircraft • Evaluation of ground and flight tests • Preparation of Test Reports • Analysis and discussion the test results and design changes if any Management of certain tests Into to Flight Test Engineering

15. Persyaratan FTE-IAe • Pendidikan formal: Lulusan S1 dari jurusan Aeronautika, Teknik Mesin, Teknik Fisika, Teknik Elektro dari perguruan tinggi yang mempunyai reputasi bagus. • Mempunyai dasar penguasaan teori yang baik dalam bidang matematika dan fisika. • Menguasai bahasa Inggris dengan baik minimal secara pasif. • Familiar dengan komputer dan menguasai piranti lunak standar untuk penulisan laporan (operating system, word processing, spread sheet, data base). • Mempunyai kesehatan fisik yang baik (setara dengan First Class DGCA Medical Certificate) • Mempunyai kecakapan berkomunikasi secara lisan dan tulisan. • Mempunyai motivasi yang tinggi dan kecerdasan emosional yang baik. • Menyukai dunia penerbangan Into to Flight Test Engineering
