  1. 006-i CHAPTER -Wy: Dynamic derivation

  2. 1:7 W+200mm Radius 150mm Aluminium tape Wye 3.000mm Cover bottom Cover top 1 • Draw the template of the cover bottom and cut toward “EXTERNAL”.

  3. Cover top Wye 3.000mm Cover bottom 2 • Copy the template and to cut on the contrary: toward the “INTERIOR”.

  4. Wye =3.000mm 3 • Cut the walls and make the female before of to glue.

  5. Wye Bent Aluminium tape 4 • Detail of the internal deflector.

  6. Wye Glue 5 • Glue all the sides cut at 45º

  7. Aluminium tape Wye Exterior face 6 • Unite the four sides with aluminum tape for the exterior.

  8. Wye Interior face 7 • Rotate the duct in position with the interior face up.

  9. Wye 2 1 8 • Close the piece follow the order.

  10. Wye Internal deflector 3 9 • Place the wall of the deflector.

  11. Position internal deflector Internal deflector Wye 4 10 • Adapt the internal deflector in the correct position.

  12. Wye 5 11 • Place the external wall of the elbow part.

  13. Wye Glue Triangle clips panel Aluminium tape 12 • Finish off of the internal deflector.

  14. Wye 6 13 • Place the internal wall of the elbow part.

  15. Pressing Aluminium tape Silicon inside Wye 14 • To press, to tape, to clip and to make the male.

  16. Wye 3.000mm • Samples of application: wye of “SHORT ENTRANCE” (1)

  17. Wye 3.000mm • Samples of application: wye of “LONG ENTRANCE” (1)

  18. Wye 3.000mm • Samples of application: wye of “LONG ENTRANCE” (2)
