  1. Waves

  2. What are waves? • There are many different kinds of wave: • Light waves • Sound waves • Waves on water • Seismic waves • Waves along a rope, or a slinky

  3. There are two sorts of waves • Transverse waves • Longitudinal waves

  4. Transverse waves • Most waves are transverse • The vibrations in transverse waves go from side to side • The energy is travelling in one direction, with the vibrations moving at a 90o angle to the direction the wave is travelling

  5. Transverse Waves After a great performance at a drum and bugle corps contest, the audience decides to start a wave in the stands. Each person rises and sits at just the right time so it looks like a wave. This is a transverse wave because, as the wave moves across the stands, folks are moving up and down. wave direction

  6. Longitudinal Waves • Longitudinal waves have vibrations moving in the same direction that the wave is travelling in • Examples of longitudinal waves are: Sound waves (in solids, liquids and gases) Shock waves (e.g. seismic waves ) A slinky (when plucked)

  7. Ouch! Longitinal Waves (cont.) C = Compression (high kid density) R = Rarefaction (low kid density) The compression (the pulse) moves up the line, but each kid keeps his place in line. C Ouch! R C Ouch! C R

  8. Examples of different waves Transverse waves: • All electromagnetic radiation, e.g. light • Ripples on water • Waves on strings • A slinky that is waved up and down Longitudinal waves: • Sound • Shock waves • A slinky when plucked

  9. What do waves do? All waves carry energy

  10. What sort of energy is being carried? • Heat energy is carried by light, infra red and microwaves • X-rays and gamma rays carry energy which can damage cells • Sounds carry energy in the form of vibrations. Loud sounds can make an object vibrate (move) • Waves on water can move things, and can even be used to generate electrical energy • Televisions, radios, fibre optics and speech are all ways in which energy travels (and also information)

  11. What does a wave look like? A wave can be drawn as a wavy line:

  12. What are the main parts of a wave? • Wavelength () • Amplitude • Frequency (f) • This is the distance from the crest of one wave to the crest of the next wave • This is the height of a wave from the mid-point (where there is no displacement) to a peak • This is the number of complete waves per second, passing a certain point. It is measured in Hertz (Hz)
