  1. Windows programming Graphic Library SNPL

  2. Application program initialization Kernel Exchange Message Basic Structure Windows Programming 1.part of initialization 2.part of exchange message for communicate with kernel SNPL

  3. WinMain WndProc WinMain and WndProc • Manage initial function and initial message Part of initialize kernel SNPL

  4. Using Visual c++ 1.File New 2.Project 3.Win32 Application 4.Project name 5.a typical”Hello world”application 6.finish Ok 7.Fileview 8.source files 9.example.cpp SNPL

  5. Compile and Run 1.F7 compile 2.Ctrl+F5 run SNPL

  6. WinMain MakeWindow INITIAL transferwindow Graphic Library Executive Make windows and show screen in monitor Start Program Initialize shape of graph Be transmitted from message to WndPro SNPL

  7. RECTANGLE ticxy Hvlabel plot draw Header File Draw rectangle Draw tic Draw label outside x , y axis of coordinates The value of coordinates get and then mark with a point Draw line between point and point SNPL

  8. Using Graphic Library 1.WinMain 2.#include “graph.h” 3. INITIAL() 4.set variable 5.Set function in graph.h 6.F7 compile 7.ctrl+F5 run Application program SNPL
