  1. AQUARIUS ENGINEERS PVT. LTD. PRESENTS CONCRETE PUMPING SOLUTION FOR HIGH RISE AND LONG DISTANCE PUMPING WITH 1407 D HR CONCRETE PUMP……………. …Sharing knowledge

  2. 1407 D HR AQUARIUS 1407 D HR IS MARKET LEADER IN IT’S CLASS, IT IS SUITABLE FOR HIGH RISE AND LONG DISTANCE PUMPING WITH LOW MAINTAINANCE COST AND WITH HIGH FUEL EFFICANCY………….. …Sharing knowledge

  3. …Sharing knowledge

  4. SAVE FUEL with AQUARIUS 1407D HR Very Comfortable Operations up to 200 meter Vertical Or 800 meter Horizontal. Practically Achieved 165 meter vertical and 800 meter long distance Concrete Pumping. Does BIG Work; Eats lesser Fuel. 6 to 7 liter per Hour with 135 kw Big Engine …Sharing knowledge

  5. PROJECT DETAIL CLIENT:-DELHI METRO RAIL CORPORATION LTD,NEW DELHI PROJECT:- AIRPORT METRO EXPRESS LINE (AMEL),DELHI IGI AIRPORT TO NEW DELHI RLY STATION. CONTRACTOR:- RELIANCE SUB CONTRACTOR:- KALINDEE RAIL NIRMAN (ENGINEERS) LTD. CONTACT PERSON:- MR. SULABH RAWAT (Chief Project Manager) 09990299912 MR.ARIF KHAN(Chief Engineer) 09313210834 OUR CUSTOMERS NAME:- (1)KALINDEE RAIL NIRMAN (ENGINEERS) LTD. MACHINE 1407D, SR. NO. 2108250514 (2) N.S. CONCRETE PVT. LTD. MACHINE 1407 D HR, SR. NO. 2110250727 CONTACT PERSON:- MR. ANOOP ARORA (OWNER) Mb. No.09971690103 …Sharing knowledge

  6. PROJECT SUMMERY M/s Kalindee Rail Nirman Engineers Ltd. has requirement of a Concrete pump who has able to pump the concrete 800 mtr horizontal practically, to complete the project of Delhi Metro’s Airport Express Line, Track concrete (inside the tunnel), with in a very short and bounded time period due to Common Wealth Game in Delhi. . In this connection M/s N. S Concrete has purchased the AQUARIUS machine 1407 D HR & given to M/s Kalindee Rail Nirman on hire basis. …Sharing knowledge

  7. ACHIEVMENT With the help and support of M/s Aquarius Machine and Aquarius Service team efforts, customer has achieved great success. Airport Exp. Line Project completed before it’s time. Practically achieved 800 mtr horizontal pumping without any problem. The persons of M/s N.S. Concrete Pvt. Ltd. and M/s Kalindee Rail Nirman (Engineers) Ltd. both were happy with machine’s performance and service support . Due to the high achievement of machine performance and service support they have issued performance and appreciation certificates also. AQUARIUS MOTO CUSTOMER SATISFACTION AQUARIUS TEAM IS ALWAYS READY FOR SUPPORT ……… …Sharing knowledge

  8. PERFORMANCE CERTIFICATE REECIVED FROM MR. ANOOP ARORA (OWNER) OF M/S N.S.CONCRETE, GURGAON, DELHI NCR. …Sharing knowledge

  9. PERFORMANCE CERTIFICATE REECIVED FROM MR. SULABH RAWAT (CPM) OF M/S KALINDEE RAIL NIRMAN (ENGINEERS) LTD., DELHI NCR. …Sharing knowledge

  10. APPRICIATION CERTIFICATE REECIVED FROM MR. SULABH RAWAT (CPM) OF M/S KALINDEE RAIL NIRMAN (ENGINEERS) LTD., DELHI NCR. …Sharing knowledge

  11. 1407 D AQUARIUS 1407 D Upper Pump with 200mtr horizontal+30 meter Downward Pipeline 800 mtr Horizontal pipe length 1407 D HR Concrete Pipe Line Diagram (New Delhi Site) 1407 HRD Inside the Tunnel With 800 meter Horizontal pipe line Metro Tunnel Successfully Pumped the concrete with 800mtr Horizontal pipe line in Delhi Metro Air Port to New Delhi Railway Station Tunnel Work. …Sharing knowledge

  12. Concrete Pipe Line Diagram (Shivaji Stadium Site) Double stage pumping 1407 D AQUARIUS 1407 D Upper Pump with 250mtr horizontal+30 meter Downward Pipeline 800 mtr Horizontal pipe length 1407 D HR 1407 HRD Inside the Tunnel With 800 meter Horizontal pipe line Metro Tunnel Successfully Pumped the concrete with 800mtr Horizontal pipe line in Delhi Metro Air Port to New Delhi Railway Station Tunnel Work. …Sharing knowledge

  13. Slurry Mix Design a) Cement - 150Kg b) Fly Ash - 300Kg c) Natural Sand -75Kg d) Water - 140Litre e) Admixture - 1.5litre f) Water / Cement Ratio - 0.31 NOTE: - This slurry was very good & very thick like honey. …Sharing knowledge

  14. M - 35 Concrete Mix Design with fly ash (Rich Concrete) a) Cement - 380Kg b) Fly Ash - 100Kg c) Natural Sand - 622Kg d) 20mm - 650Kg e) 10mm - 434Kg d) Water - 172Liter e) Admixture - 5.760liter f) Water / Cement Ratio - 0.35 g) Slump – 190-200mm (In the Plant) M- 35 Concrete Mix Design without fly ash a) Cement - 410Kg b) Fly Ash - Nil c) Natural Sand - 755Kg d) 20mm - 644Kg e) 10mm - 430Kg d) Water - 164Liter e) Admixture – 4.700liter f) Water / Cement Ratio - 0.40 g) Slump – 190-200mm (In the Plant) …Sharing knowledge

  15. ACTUAL SITE PHOTOGRAPHS 1407D HR INSIDE THE TUNNEL CONCRETE FLOW AT END WITH 800 MTR HORIZONTAL LINE …Sharing knowledge

  16. FOR ANY QUARY PLEASE FELL FREE TO CONTACT. AQUARIUS ENGINEERS PVT. LTD. H.O. “AQUARIUS”,Sheelavihar Colony , Off Karve Road, Pune 411038. INDIA Tel.:+912025445227 Fax:+912025445228 E-mail: info@aquariusengineers.biz Web:www.aquariusengineers.biz Delhi Office.: AQUARIUS ENGINEERS PVT. LTD. D- 155,First Floor ,Okhla Industrial Area ,Phase I ,Behind Honda Showroom ,New Delhi 110020.INDIA Tel.:+011-32928709 Fax:+011-41716963 E-mail: delhi@aquariusengineers.biz Web:www.aquariusengineers.biz Mfd.by: Putzmeister India Pvt. Ltd. 190,191,Kundaim Industrial Estate, Ponda , Goa 403115 India. Tel.:+91 0832 239 6334 Fax.:+91 0832 239 6253 …Sharing knowledge

  17. THANK YOU …Sharing knowledge
