  1. The Solid State Crystals and symmetry Unit cells and packing Types of solid Phase diagrams

  2. Solids tend to be regular • At equilibrium an atom will tend to occupy the position of lowest energy (highest stability) • One position will be more stable than any others • If one atom occupies this position then all the other atoms will occupy the same position • All atoms occupy the same position and a regular lattice evolves • Amorphous solids have no regular structure and tend to be metastable or unstable

  3. Four solids

  4. Probing crystal structures • Light is scattered by objects that are larger than the wavelength • Crystal lattices are too small for visible light • X-rays have wavelengths on the order of the interatomic distance in crystals • X-rays suffer diffraction by crystals like visible light diffracted by blinds • X-ray diffraction is the most powerful structural tool developed

  5. Diffraction and interference • Diffraction arises by interference of electromagnetic radiation • Constructive interference – the waves are in phase – increase in intensity • Destructive interference – the waves are out of phase – loss of intensity • X-ray beams diffract from a crystal to give a pattern of spots where constructive interference has occurred on a sea of destructive interference

  6. The crystal lattice and Bragg scattering • X-rays are scattered by the electrons in the atoms • The array of atoms in the crystal is like a diffraction grating for X-rays as a set of slits is for visible light • Diffraction only occurs under conditions of constructive interference • The Bragg equation gives the conditions

  7. The Bragg condition • Waves reflected from adjacent layers must be in phase • The path length difference must then be a whole number of wavelengths

  8. X-ray diffraction and data collection • A crystal or powder is swept through the range of angles of θ and the positions where there are reflections are tabulated • Analysis of the d spacings gives information about the type of crystal lattice • Deeper analysis of the reflection intensities gives a complete description of the structure and positions of all of the atoms

  9. Symmetry and crystal structure • Symmetry underlies chemistry • Arrangements of atoms in crystals • Determination of spectra • Mixtures of orbitals in bonds • Symmetry operators relate the positions of the atoms in the unit cell

  10. Common symmetry elements • Translation • Rotation • Reflection • After application of a symmetry operation to a set of atoms related by symmetry, the system appears unchanged

  11. Translation Reflection Rotation Symmetry operations

  12. Packing of spheres and simple structures • Atoms and simple molecules can be treated like spheres • The crystal lattice can be derived from packing together spheres • There are limited possibilities

  13. Cubic packing • In simple cubic the atoms stack directly on top of each other • Not close packed (very uncommon) • Body-centered cubic: denser packing achieved by putting a layer in the depression of the first • Not close packed (quite common)

  14. Close packing • Two arrangements achieve a higher density • Hexagonal close-packed- abab • Face-centered cubic – abcabc • Both are common for metallic elements

  15. Summary of packing arrangements

  16. Building patterns with unit cells • A floor is made from a mosaic of tiles • A wall is made from stacking of bricks • A crystal is made from stacking unit cells • In each case one unit contains all of the information required to describe the structure completely without any gaps or deficiencies

  17. Building lattices with unit cells • Consider a cube

  18. Counting atoms in a unit cell • The ratio of the atoms in a unit cell must equal the composition of the compound • Count atoms as follows:

  19. Primitive and body-centered cells • Alternate views of the primitive and body-centered cell • Primitive: • 8 atoms on the corners each contribute 1/8th to the contents – overall cell contents = 1 • BCC: • 8 atoms on the corners contribute 1 • 1 atom in center contributes 1 • Overall contents = 2; composition AB

  20. Face-centered cube • Two views of the FCC lattice • Also viewed along 3-fold axis which is perpendicular to the close-packed layers • Contents: • 8 at corners = 1 • 6 on faces = 3 • Total contents = 4

  21. Calculations with unit cells • Calculating unit-cell size from atom size • In FCC cell, the atoms touch along the diagonal • Length of diagonal = 4r • Length of edge =

  22. Estimate density • If we know the unit cell size we can calculate the unit cell volume • If we know the unit cell contents we know the total mass of the cell • Density = mass/volume

  23. Simple ionic compounds • In general, anions are larger than cations • Lattices can be described by close packing of anions with cations occupy regular “holes” in the anion lattice

  24. Sodium chloride • Chloride ions form FCC lattice • Sodium ions occupy octahedral holes • Composition check: • Cl: • 8 on corners = 1 + • 6 on faces = 3 • Total = 4 • Na: • 12 on edges = 3 • 1 in center = 1 • Total = 4

  25. Covalent networks • Ionic lattices are characterized by high coordination numbers and non-directional bonding • Covalent lattices have low coordination numbers and highly directional bonding • The bonds are formed from hybridized atomic orbitals to use the valence bond model

  26. Diamonds are forever • The diamond lattice is a very common covalent lattice • It is a three dimensional tetrahedral net • Bonds are made from sp3 hybrid orbitals • Very strong covalent bonds make the lattice extremely stable

  27. Compounds also have diamond lattice • In GaAs, the Ga and As atoms alternate in the diamond lattice • GaAs is an important semiconductor and laser material • Many other similar materials

  28. Diamond and graphite • Infinite covalent lattices in different dimensions • Diamond 3D • Graphite 2D • Graphite is more stable than diamond, but can be transformed into diamond by application of high pressure

  29. Summing it up: phase diagrams • Phase diagrams summarize the states of a substance as a function of the pressure and temperature • They reveal: • The areas where one phase is stable • The lines where two phases are in equilibrium • The points where three phases are in equilibrium

  30. Phase diagram for water • A piece of ice at 1 atm pressure will convert to liquid at 0ºC and into gas at 100ºC • Below at pressure of 6 x 10-3 atm the ice converts directly into a gas (sublimation) • At the triple point the three phases are in equilibrium – a single temperature and pressure • Beyond the critical point is the region of supercritical fluid: • Cannot be condensed no matter what the pressure (critical temperature) • Cannot be vaporized no matter what the temperature (critical pressure)

  31. Phase diagrams explain well known phenomena • The slope of the solid-liquid phase boundary for water is negative, while for CO2 it is positive • A sample of ice under pressure melts • A sample of liquid CO2 under pressure solidifies • At 1 atm pressure: • Ice melts on heating • Solid CO2 sublimes (dry ice)
