  1. Assignment 2 Observations Mausam

  2. The SAT Encoding • Induced Subgraph Isomorphism • NP complete problem • Applications: similarities between chemical compounds; protein-interaction networks, social networks, circuit design.. • Variables • X(i,j) denotes that ith node (in smaller graph) mapped to jth node (in larger graph) • Self edge: If node i has a self-edge and node j doesn’t • remove X(i,j) • Self-edge: If node j has a self-edge and node i doesn’t • remove X(i,j)

  3. The SAT encoding • Each node maps to exactly one other node • X(i,1)  X(i,2)  X(i,3)…  X(i,n) • Pairs of  X(i,1)   X(i,2);  X(i,1)   X(i,3) … • Each node in larger graph maps to at most one node • Pairs of X(1,j)X(2,j); X(1,j)X(3,j); … • Disallowed pairs of mappings • If edge(i1,i2) and no edge(j1,j2): X(i1,j1)X(i2,j2); • If no edge(i1,i2) and edge(j1,j2): X(i1,j1)X(i2,j2); • If edge(i1,i2) and edge(j2,j1): X(i1,j1)X(i2,j2); • Overall – O(nm) vars, O(n2m2) clauses

  4. Fun optimizations U S Yes. A mapping is: M(A) = S, M(B) = Q, M(C) = R The edges from P to other nodes don‘t matter since no node in G got mapped to P. • Degree trick: Can B ever map to P/S/R? • No: Indegree of B is greater than indegree of P/S/R • Remove X(B,P), X(B,S), X(B,R) • Common neighbor constraint: Can A-U and C-T? • They both don’t have an edge • They both have outdegrees 1 • No: because AC have common neighbor 1; UT 0 • X(A,U)X(C,T) • … A C P R T B Q

  5. Observations • People solved ~100+80 node problems… • For an NP hard problem that’s not too bad, is it? • Paresh’s observations • adding redundant clauses helps miniSAT for tough problems.

  6. Best Competitors • Kim Wallmark • Alan Ludwig • HaroonBarri

  7. Assignment 3 Discussion Mausam

  8. BlackJack: State Space • MinSum: the minimum sum of the player's hand so far. • NumAces: the number of Aces in the player's hand so far. • dMinSum: the minimum sum of the dealer's hand so far. • dNumAces: the number of Aces in the dealer's hand so far. • isTwoCards: a Boolean that represents that the player's hand has just two cards so far. • isBlackJack: a Boolean that represents that the player got a BlackJack. • pair: has value between 0 and 10. Zero indicates that the player doesn't have a pair. Any other value i indicates that the player has two cards of value i. • turn: a Boolean to indicate whether it is player's turn or dealer's.

  9. BlackJack: Action Space • Stand: Turn = 0 • Hit: get a new card with prob… update minSum, numAces, isTwoCard, pair • Double: get a new card, update minSum, numAces, etc.; • Turn = 1. • Allowed when isTwoCard = 1 • Default: run default dealer policy. • Allowed with turn = 1 • Split: tricky! • Allowed with pair > 0; isTwoCard = 1

  10. Equations

  11. BlackJack Split (say only three cards) • Q((c,c), SPLIT) • 2p1p1V(c,1) • p1p2V(c,1) + p1p2V(c,2) • p1p3V(c,1) + p1p3V(c,3) • p2p1V(c,1) + p2p1V(c,2) • 2p2p2V(c,2) • p2p3V(c,3) + p2p3V(c,3) • p1p3V(c,1) + p1p3V(c,3) • p2p3V(c,3) + p2p3V(c,3) • 2p3p3V(c,3) • (c,c) • [(c,1) & (c,1)] p1p1 • [(c,1) & (c,2)] p1p2 • [(c,1) & (c,3)] p1p3 • [(c,2) & (c,1)] p2p1 • [(c,2) & (c,2)] p2p2 • [(c,2) & (c,3)] p2p3 • [(c,3) & (c,1)] p3p1 • [(c,3) & (c,2)] p3p2 • [(c,3) & (c,3)] p3p3 2p1(p1+p2+p3) = 2p1

  12. Equations

  13. Value of Terminal States • If isTwoCards = 1, minSum=11, numAces = 1 • Return 1.5 • If minSum>21 • Return -1 • If minSum < 21 and dMinSum > 21 • Return 1 • … • …

  14. Can you solve it with Expectimax? • No • Because there is possibility of infinite loop • Values are well-formed • Loop of size n becomes less probable as n increases • (see beginning example from lecture on MDPs) • EXCEPTION: Q(1010, split) for p> 0.5 • Solution: use Value Iteration/Policy Iteration

  15. Optimizations • Dealer’s policy is fixed. So, run the Markov chain ahead of time to generate a table • Pr(dealer gets 17|first card=c) • Pr(dealer gets 18|first card=c) • Pr(dealer gets 19|first card=c) • Pr(dealer gets 20|first card=c) • Pr(dealer gets 21|first card=c) • Pr(dealer busts|first card=c) • Remove dMinSum, dNumAces, turn. • Add dFirstCard • Remove Default action • Change the equations for double/stand based on computed probabilities

  16. Comments • numAces – not required. Convert to hasAce • Only first ace is relevant. After that each ace = 1 • Handle infinite splits by allowing say, 10 splits • Should work fine in practice • Modification: have the bet amount in state space • Needn’t multiply by 2 in equations for doubling • Need to use this info when computing terminal rewards

  17. Difference in solutions? • In real BJ: Dealer and player BJ is a push • In our BJ: player wins • ??? • In real BJ: there is a 4/6/8 card deck • In our BJ: infinite cards • You can easily modify code to handle 1st case • 2nd case: Monte carlo sampling!

  18. Should you play our BlackJack? • Expected reward before game starts • SUM[Pr(game)*expected reward of the game] • Deal three cards… and use V(s) to compute exp reward • My expected reward: $0.058 • Yes! We should play the game

  19. Discussion Mausam

  20. Followup Courses • 546 Machine Learning/Data Mining • 515 Probabilistic Graphical Models • 517 Natural Language Processing • ??? AI/Statistics for Big Data • 571 Robotics • 579 Intelligent control • 574 Special Topics in AI • 528 Computational Neuroscience • 510 Human computer Interaction

  21. Final Exam • 50% objective • True/false • Multiple choice • Fill in the blanks • Match the following… • 25% short answer questions • 1 word – 5 line responses… • opinions/strengths/weaknesses/etc… • 25% Problem solving • Problem modeling; short calculations…

  22. Why do an exam? • Goal: revise and analyze the whole course • Expected preparation time • ~1 day • Go over lecture slides • Read parts of the notes that are unclear…

  23. What worked • Programming Assignments • You hated them • You loved them • You learned through them • Written Assignments(?) • Forced us to be regular • Classes • I absolutely enjoyed the interaction! • Emails/bulletin boards • Videos(?)

  24. What didn’t work • Programming environment • People didn’t know unix • People didn’t know Java! • Packed • Once someone got behind, it got tough to recover • Workload

  25. Thanks • To all of you • who contributed to helping each other through newsgroup and other questions • who asked terrific questions in class • who gave regular feedback on class, assignments, grading, organization
